RE92Tx
指向性lavalier小型マイク
- バックエレクトレット・コンデンサー・エレメント
- カーディオイド極性パターン
- 統合型6ピン (180 cm) ケーブル
- TA4Fコネクターは、全てのEVボディパック・トランスミッターと対応
- ワイヤードXLR用途向けにTXAと組み合わせて使用
RE92Txは、カーディオイド・ピックアップ・パターンを採用したプロクオリティのエレクトレット・コンデンサーLavalier小型マイクです。
スピーチ用に設計されており、プレゼンテーション、礼拝所、放送、シアター用途で使用するのに優れた選択肢です。
Specifications
Connector Type | TA4F |
Maximum SPL (1% THD) | 135dB |
Height | 10.5mm (0.41") |
Specifications |
Weight Net | 0.81oz (23g) |
Family | RE Series Installation |
Polar Pattern | Cardioid |
Wired/Wireless | Wireless |
Mic Type | Lavalier |
Diameter (Max) | 24mm (0.94") |
Element | Back Electret Condenser |
Open Circuit Voltage | 5.6mV/Pascal |
Case Material | Metal |
Finish | Non-reflecting Black |
Current Consumption | < 500 uA |
ビデオ
Where to Buy
Retail Partners
Portable Speakers & Microphones
* Call for availability
ダウンロード
Technical Documentations
Certification/Regulatory
Name | Language & Download |
---|---|
RE92x Wired Mics EU Declaration of Conformity (2023-Sep) | EN |
Engineering Data Sheet
Name | Language & Download |
---|---|
RE92TX Engineering Data Sheet | EN |
Service Policies
Name | Language & Download |
---|---|
Service Policies for Asia/Pacific Rim | EN |
White Paper
Name | Language & Download |
---|---|
Audio 101 - Basic Audio Terminology | EN |
Audio 101 - Microphone Basics | EN |
Audio 101 - Wireless Microphone Basics | EN |
Microphone Facts- Axial Response | EN |
PA Bible 03: Microphone Types | EN |
PA Bible 08: Microphone Techniques | EN |
PA Bible 15: Barrier Miking | EN |
The EV PA Bible | EN |
The PA Bible Chapter Zero | EN |
