X2-212/90
高性能かつコンパクトな12インチ垂直ラインアレイ・ラウドスピーカー・システム
- DVN3125 12インチ・ネオジム製ウーファー
- 高出力、低歪
- MBH (Mid-Band Hydra) によって、優れたボックス・カップリングを実現
- 先進のPDH (Pin Diffraction Hydra) によって、リニアHFパフォーマンスをコントロール
- IRS (Integrated Rigging System) によって、クイック・セットアップが可能
X2システムは、高SPL能力、HF応答特性の拡張、リニアLF出力によって、極めてコンパクトなキャビネットに内蔵された他のラウドスピーカーよりも優れたパフォーマンスを実現します。
Specifications
| HF Transducer | Two 3-Inch ND6A |
| Speaker Type | Full-Range, Line-array |
| Frequency Response (-3 dB)¹ | 52 Hz - 19 kHz |
Specifications |
|
| Coverage (Nominal -6 dB) H | 90° |
| LF Transducer | 12-Inch DVN3125 |
| Enclosure Material | EVCoat-coated birch plywood |
| Sensitivity 1 W/1 m | 101dB |
| Height | 342.9mm (13.5") |
| Width | 723.9mm (28.5") |
| Depth | 536.6mm (21.13") |
| Weight Net | 42.18kg (92.99 lbs) |
| Passive Power Handling | 2000W peak |
ビデオ
X-Line Advance line-array loudspeaker system from Electro-Voice
6 gigs/week, 300+ gigs/year. X2 performing flawlessly.
X2 Rocks the Gampel Open Air
Walking on Cars concert in Dublin boasts large Electro-Voice X-Line Advance system
X-Line Advance overview – Powa Productions, Australia
X-Line Advance Compact Vertical Line-Array Loudspeaker Systems
推奨パワーアンプ
For optimal sound system performance, Electro-Voice recommends the following amplifiers for X2-212/90.
Dynacord TGX Series続きを読む |
Dynacord IPX Series続きを読む |
|
|---|---|---|
| Two-Channel | ||
| Multi-Channel | ✔ | ✔ |
| DSP | ✔ | ✔ |
| Direct Drive | ✔ | ✔ |
| OMNEO (Dante, OCA) | ✔ | ✔ |
| Installation | ✔ | ✔ |
| Live Sound |
