EVID C12.2
12" 2‑way coaxial ceiling loudspeaker
- Full-range power for high ceilings, large spaces
- High sensitivity, high power-handling
- Integrated transformer with automatic saturation compensation for distortion free 70 V, 100 V, or 8 Ω use
- Front-panel mode/wattage selector
- White semi-gloss perforated grille
- Heavy-gauge steel enclosure in black
- 3/8-inch threaded-rod mount points for open ceilings
- Safe, easy installation with included tile bridge and mounting ring
- Complete package, requires no additional accessories
Specifications
| HF Transducer | 1-inch (25 mm) |
| Speaker Type | Ported cabinet, internally damped two-way |
| Frequency Response (-3 dB)¹ | 65 - 20,000 |
| Max. SPL/1m (calc)² | 126 |
| LF Transducer | 12-inch EVID 920-8B |
| System Power Handling (Continuous/Program/Peak) | 100 |
Specifications | |
| Power Rating | 64 |
| Crossover Frequency | 2000 |
| Enclosure Material | Steel enclosure and UL94V-0 rated baffle and bezel |
| Grille | Powder-coated steel |
| Sensitivity 1 W/1 m | 100 |
| Available Color | White (paintable surface) |
| Height | 333 |
| Weight Net | 12.3 |
| Diameter (Max) | 414 |
| Transformer Taps (Transformer Version Only) | 4 (70 V only), 8, 16, 32, 64 W ASC protected |
| Input Formats | 8ω / 70V / 100V |
| Coverage (Nominal -6 dB) | 90 |
| Mounting Systems | Integrated 3-point toggle anchors |
