PL-80a
Premium dynamic vocal microphone
- Incredible vocal power and clarity
- Robust, forgiving, EQ-friendly performance
- Superior off-axis rejection
- Ultra-low handling noise
- Exceptionally cooperative tonal characteriztics
The PL80a is a premium-grade supercardioid dynamic microphone designed to elegantly capture the character of vocals in live sound applications. Its EQ-friendly sonic contour adapts well to any vocal texture, allowing vocals to sit nicely in the mix without sounding harsh. Also available: PL80c with the classic beige PL finish.
Specifications
| Connector Type | 3-pin XLR |
| Family | PL Series |
| Audio Frequency Response | 80 Hz - 16,000 Hz |
Specifications |
|
| Polar Pattern | Supercardioid |
| Wired/Wireless | Wired |
| Mic Type | Handheld |
| Element | Dynamic |
| Impedance, Low-Z balanced | 600Ω |
| Open Circuit Voltage | 2.2mV/Pascal |
| Case Material | Die cast zinc |
| Finish | Textured Satin Black |
| Power Requirement | Passive |
Videos
EV @ Warped Tour: Totally Committed
Comments About EV Microphones & PA Systems on Vans Warped Tour
Electro-Voice at Vans Warped Tour
Motion City Soundtrack @ Warped Tour 2010
PL Series at NAMM 2009
EVID Speaker Line & PA Series @ InfoComm 2009
Downloads
Technical Documentations
Certification/Regulatory
Engineering Data Sheet
| Name | Language & Download |
|---|---|
| PL80A Data Sheet | EN |
Service Policies
| Name | Language & Download |
|---|---|
| Service Policies for China | EN |
White Paper
| Name | Language & Download |
|---|---|
| Audio 101 - Basic Audio Terminology | EN |
| Audio 101 - Loudspeaker Basics | EN |
| Audio 101 - Microphone Basics | EN |
| Microphone Facts- Axial Response | EN |
| Microphone Facts- The New Model 666R Joins the 666 Family | EN |
| PA Bible 03: Microphone Types | EN |
| PA Bible 08: Microphone Techniques | EN |
| PA Bible 15: Barrier Miking | EN |
| The EV PA Bible | EN |
| The PA Bible Chapter Zero | EN |
