ELX115
Altavoz bidireccional de 15 pulg. pasivo
- Woofer de 15 pulg. y transductor de compresión de titanio de alta frecuencia de 1,5 pulg.Rango de frecuencia de 50 Hz a 20 kHz Sensibilidad SPL de 95 dB; SPL máx. de 134 dBGestión de potencia continua de 400 W y máxima de 1.600 WCarcasa de madera reforzada compatible con montaje en poste o apilado con subwoofers Live X
El ELX115 supone un salto de calidad con respecto al ELX112 gracias a un woofer de 15 pulg. que ofrece un mayor rango de bajas frecuencias y una mayor potencia acústica para salas de mayor tamaño.
Specifications
| Frequency Range (-10 dB) | 50 - 20000kHz |
| Minimum Impedance | 7.4Ω |
| Nominal Impedance (Passive) | 8Ω |
Specifications |
|
| HF Transducer | DH-1K, 39mm (1.5") Titanium Diaphragm Compression Driver |
| Speaker Type | Full-Range, mid-high, two-way |
| Woofer Size | 15inch |
| Powered or Passive | Passive |
| Frequency Response (-3 dB)¹ | 75 - 18000Hz |
| Max. SPL/1m (calc)² | 134dB (Half Space) |
| Coverage (Nominal -6 dB) H | 90° |
| Coverage (Nominal -6 dB) V | 50° |
| LF Transducer | (1) EVS-15K, 381mm (15") Woofer |
| System Power Handling (Continuous/Program/Peak) | 400//1600Watts |
| Crossover Frequency | 17000Hz |
| Connector Type | Parallel Neutrik® NL4 |
| Enclosure Material | 9-ply plywood |
| Grille | 18GA Steel with Black Powdercoat |
| Available Color | Black |
| Height | 708mm (27.87") |
| Width | 432mm (17.01") |
| Recommended High-Pass Frequency | 40Hz |
| Depth | 382mm (15.04") |
| Internal Crossover | Yes |
| Weight Net | 21.9kg (48.28 lbs) |
| Family | ELX |
| Case Material | 9-ply, 15mm Plywood, Internally Braced, with Textured Paint |
| Axial Sensitivity (SPL, 1 W @ 1 m) | 95dB |
Videos
ELX Loudspeaker Overview
Electro-Voice at NAMM 2012
EV @ NAMM 2011
In Search of Excellent Audio & Video
Recommended Amplifiersffs
For optimal sound system performance, Electro-Voice recommends the following amplifiers for ELX115.
Dynacord C‑SeriesLearn More |
Dynacord L‑SeriesLearn More |
|
|---|---|---|
| Two-Channel | ✔ | ✔ |
| Multi-Channel | ||
| DSP | ✔ | ✔ |
| Direct Drive | ✔ | ✔ |
| OMNEO (Dante, OCA) | ||
| Installation | ✔ | |
| Live Sound | ✔ |
