ND86
动圈超心形人声话筒
- 出色的声学控制，即便是超大型的场馆应用
- 通过高通滤波减少房间的低频特性，以及通过对关键高-中频段的提和切分离人声和舞台音染
- 大振膜动圈话筒头
- 实现饱满、细节的频率响应
- 防震话筒头降低手持噪音
- 防止低频噪声进入扩声系统
- 哼声抑制线圈防止线路嗡嗡声
- 无须担心在音箱和产生EMF的设备机柜旁使用
- Memraflex 网罩防止碰撞
- 耐用的紧密网罩可以承受非常粗鲁的使用
ND86是一款高品质且耐用的大振膜动圈超心形人声话筒。ND86拾音器经过精确调试，提供真实、平滑和细节的声音，同时出色的隔离来自舞台的其他声音，即便是在超大型的舞台也能实现出色的声音控制。
Specifications
| Connector Type | 3-pin XLR |
| Height | 182.5 |
| Weight Net | 0.326 |
产品规格 |
|
| Shipping Weight | 0.601 |
| Family | ND Series |
| Open Circuit Voltage | 2.4 |
| Case Material | Die cast zinc |
| Finish | Black polyurethane paint |
| Power Requirement | Passive |
| Audio Frequency Response | 70 – 17,000 |
| Maximum SPL | > 140 |
| Polar Pattern | Supercardioid |
| Wired/Wireless | Wired |
| Mic Type | Handheld |
| Diameter (Max) | 50.5 |
| Element | Dynamic |
| Impedance, Low-Z balanced | 350 |
Videos
ND Series Microphones on Tour with Don Broco
ND Series Microphones
ND86 Dynamic Supercardioid Vocal Microphone
