EVU Ultra-Compact 2-Way Speaker Systems
- 6.5- and 8-inch woofers allow ultracompact enclosures
- Delay systems
- Under-balcony applications
- Front-fill applications
- Wall-mount applications
- Distributed audio systems
- Asymmetrical enclosure shape provides an appropriate vertical aiming angle for both under-balcony and stage-lip applications
- Sophisticated, 18-dB-octave passive crossover/EQ networks
- Supplied U-bracket
- Rear mounting points accept OmniMount brackets
- Available in black or white (interior use)
Electro-Voice developed the first “constant directivity” waveguides in the 1970s, which, unlike conventional devices of the day, maintained their rated coverage angles over a wide frequency range. EV constant directivity meant that anyone seated in the waveguide’s pattern received the same frequency balance as anyone else, a great boon in providing truly uniform coverage and sound quality across a venue.
Today’s EVU waveguide incorporates the design refinements of over 30 years’ development. Its square mouth makes the EVU 90° x 50° coverage pattern rotatable, so enclosure orientation is independent of the desired horizontal coverage pattern. The six-inch overall mouth size is a good physical and directivity match to the EVU’s 6.5- and 8-inch woofers.
All four EVU systems employ an ICT-1-8 small-format high-frequency compression driver with a 1.3-inch titanium diaphragm, mounted on a six-inch-square, 90° x 50° rotatable waveguide. The systems are shipped to provide a 90° horizontal coverage angle when the long enclosure axis is horizontal.
Models
 |
 |
 |
 | |
EVU-1062/95 |
EVU-1082/95 |
EVU-2062/95 |
EVU-2082/95 | |
| Frequency Range (-10 dB) | 65 - 20000kHz (Half space) | 65 - 20000kHz (Half Space) | 70 - 20000kHz (Half Space) | 60 - 20000kHz (Half-space) |
| Suspension | (6) M8 threaded points | (6) M8 threaded points | Six M8 threaded points | Six M8 threaded points |
| Weatherized | No | No | No | No |
| Minimum Impedance | 6Ω | 6Ω | 6Ω | 6Ω |
| HF Transducer | One 1.3-inch (33 mm) diaphragm ICT-1-8 compression driver | One 1.3-inch (33 mm) diaphragm ICT-1-8 compression driver | One 1.3-inch (33 mm) diaphragm ICT-1-8 compression driver | One 1.3-inch (33 mm) diaphragm ICT-1-8 compression driver |
| Speaker Type | Full-Range, Two-Way | Full-Range, Two-Way | Full-Range, Two-Way | Full-Range, Two-Way |
| Frequency Response (-3 dB)¹ | 110 - 16000Hz () | 110 - 16000Hz () | 100 - 16000Hz () | 100 - 16000Hz () |
| Max. SPL/1m (calc)² | 120dB | 123dB | 125dB | 126dB |
| Coverage (Nominal -6 dB) H | 90° | 90° | 90° | 90° |
| Coverage (Nominal -6 dB) V | 50° | 50° | 50° | 50° |
| LF Transducer | One 6.5-inch (165 mm) ICT-6.5-8 woofer | One 8-inch (203 mm) ICT-8-8 woofer | Two 6.5-inch (165 mm) ICT-6.5-8 woofers | Two 8-inch (203 mm) ICT-8-8 woofers |
| Power Rating | 640W | 700W | 1200W | 1400W |
| System Power Handling (Continuous/Program/Peak) | 160//640Watts () | 175//700Watts () | 300//1200Watts () | 350//1400Watts () |
| Connector Type | 4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire) | 4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire) | 4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire) | 4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire) |
| Enclosure Material | 9-ply hardwood plywood | 9-ply hardwood plywood | 9-ply hardwood plywood | 9-ply hardwood plywood |
| Grille | 18-gauge steel with cloth behind | 18-gauge steel with cloth behind | 18-gauge steel with cloth behind | 18-gauge steel with cloth behind |
| Available Color | Black or white | Black or white | Black or white | Black or white |
| Sensitivity 1 W/1 m | 95dB | |||
| Height | 209mm (8.23") | 247mm (9.72") | 209mm (8.23") | 247mm (9.72") |
| Width | 370mm (14.57") | 409mm (16.1") | 533mm (20.98") | 615mm (24.21") |
| Recommended High-Pass Frequency | 90Hz | 90Hz | 90Hz | 90Hz |
| Depth | 207mm (8.15") | 237mm (9.33") | 207mm (8.15") | 237mm (9.33") |
| Weight Net | 6.53kg (14.4 lbs) | 7.4kg (16.31 lbs) | 11.3kg (24.91 lbs) | 12.8kg (28.22 lbs) |
| Shipping Weight | 9.12kg (20.11 lbs) | 10.3kg (22.71 lbs) | 14.2kg (31.31 lbs) | 16kg (35.27 lbs) |
| Passive Power Handling | 640W peak | 700W peak | 1400W peak | 1400W peak |
| Finish | Textured paint | Textured paint | Textured paint | Textured paint |
| Nominal Impedance | 8Ω | 8Ω | 8Ω | 8Ω |
| Waveguide | 6 in. x 6 in., rotatable | 6 in. x 6 in., rotatable | 6 in. x 6 in., rotatable | 6 in. x 6 in., rotatable |
| Axial Sensitivity (SPL, 1 W @ 1 m) | 92dB | 95dB | 94dB () | 95dB |
