X2-212/120
High‑performance compact 12" vertical line array loudspeaker system
- Integrated Rigging System - (IRS)
- Mid-Band Hydra Line Source Technology - (MBH)
- Pin Diffraction Hydra - (PDH)
- Proprietary Electro-Voice FIR-Drive settings
- Compatible with all grids and dollies currently available for 90-degree versions
- New IRIS-Net speaker settings, EASE files, EDS documents, and LAPS 3.3 are available
The high-performance X2-212/120 is two-way vertical line-array loudspeaker element providing 120-degree horizontal coverage, expanding the flexibility of the X-Line Advance family.
It is ideal for use as a wide-coverage system for live sound using all 120-degree elements, or as the near-field element in a combined line array positioned below 90-degree elements, bi-amplified only.
The X-Line Advance family is designed for a wide variety of applications where wide bandwidth, vertical and horizontal directivity control, and high efficiency are required in a compact, cost-effective package.
Specifications
| Freq. Response (-3 dB) |
52 Hz - 19 kHz1 | |||
| Horizontial Coverage | 120° | |||
| Vertical Coverage | Array dependent | |||
Specifications |
||||
| Recommended High-Pass Freq. |
50 Hz |
| Max Calculated SPL | 145 db Peak2 |
| Configuration | Bi-amp |
| LF Transducer | DVN3125, 12-in (305 mm) driver |
| LF Axial Sensitivity | 101 db (1 W/1 m)4 |
| LF Power Handling | 500 W Continuous, 2000 W Peak |
| LF Impedance | 8 Ω (nominal), 6.1 Ω (min) |
| HF Transducer | 2 x ND6A, 3-in (76.2 mm) diaphragm compression driver |
| HF Axial Sensitivity | 111 db (1 W/1 m)4 |
| HF Power Handling | 150 W Continuous, 600 W Peak3 |
| HF Impedance | 8 Ω (nominal), 6.0 Ω (min) |
| Connectors | Dual NL8 type connector |
| Enclosure | 13-ply weather resistant plywood with EVCoat |
| Grille | 16 GA powder coated galvanneal |
| Suspension | IRS — Integrated Rigging System |
| Dimensions (H x W x D) | 13.5 in x 28.77 in x 12.04 in (342.9 mm x 730.8 mm x 534.4 mm) |
| Net Weight | 93 lb (42.2 kg) |
| Shipping Weight | 107 lb (48.5 kg) |
| 1 Full-space anechoic array performance with FIR-Drive preset. 2 Full-space measurement of HF section of 4 elements. SPL adjusted for 1m distance. 3 AES 2-1984 and ANSI S4.26-1984 power test. 4 Full-space anechoic measurement of a single element. |
|
Videos
X-Line Advance line-array loudspeaker system from Electro-Voice
6 gigs/week, 300+ gigs/year. X2 performing flawlessly.
X2 Rocks the Gampel Open Air
X-Line Advance overview – Powa Productions, Australia
X-Line Advance Compact Vertical Line-Array Loudspeaker Systems
Recommended Amplifiersffs
For optimal sound system performance, Electro-Voice recommends the following amplifiers for X2-212/120.
Dynacord TGX SeriesLearn More |
Dynacord IPX SeriesLearn More |
|
|---|---|---|
| Two-Channel | ||
| Multi-Channel | ✔ | ✔ |
| DSP | ✔ | ✔ |
| Direct Drive | ✔ | ✔ |
| OMNEO (Dante, OCA) | ✔ | ✔ |
| Installation | ✔ | ✔ |
| Live Sound |
