Designed specifically for horns, drums, and acoustical and electric guitars, the N/D468’s large-diameter voice coil (up to 50% larger than other mics) provides a sound that’s natural yet powerful and articulate. A unique pivoting-head design ensures perfect mic placement, while the supercardioid pattern provides superior off-axis rejection and acoustic isolation in any application.
Specifications
| Connector Type | 3-pin XLR |
| Height | 115 |
| Weight Net | 0.190 |
| Audio Frequency Response | 20 - 22,000 Hz |
| Polar Pattern | Supercardioid |
| Wired/Wireless | Wired |
Specifications | |
| Mic Type | Instrument |
| Diameter (Max) | 52 |
| Element | Dynamic |
| Impedance, Low-Z balanced | 150 |
| Open Circuit Voltage | 3.1 |
| Case Material | Metal |
| Finish | Non-reflecting Black |
| Power Requirement | Passive |
