ELX115

Altifalante passivo bidireccional de 15 polegadas

  • Woofer de 15 polegadas e altifalante de compressão de alta frequência em titânio de 1,5 polegadasGama de frequências 50 Hz – 20 kHz Sensibilidade SPL 95 dB; SPL máx.134 dBProcessamento de potência contínuo de 400 W e pico de 1600 WCaixa de madeira robusta — montagem em poste ou empilhada com subwoofers Live X

Com um avanço poderoso em relação ao ELX112, o ELX115 inclui um woofer de 15 polegadas que proporciona uma resposta de baixas frequências ampliada para um som superior em salas grandes.

Specifications

Frequency Range (-10 dB) 50 - 20000kHz
Minimum Impedance 7.4Ω
Nominal Impedance (Passive)

HF Transducer DH-1K, 39mm (1.5") Titanium Diaphragm Compression Driver
Speaker Type Full-Range, mid-high, two-way
Woofer Size 15inch
Powered or Passive Passive
Frequency Response (-3 dB)¹ 75 - 18000Hz
Max. SPL/1m (calc)² 134dB (Half Space)
Coverage (Nominal -6 dB) H 90°
LF Transducer (1) EVS-15K, 381mm (15") Woofer
Coverage (Nominal -6 dB) V 50°
System Power Handling (Continuous/Program/Peak) 400//1600Watts
Crossover Frequency 17000Hz
Connector Type Parallel Neutrik® NL4
Enclosure Material 9-ply plywood
Grille 18GA Steel with Black Powdercoat
Available Color Black
Height 708mm (27.87")
Width 432mm (17.01")
Recommended High-Pass Frequency 40Hz
Depth 382mm (15.04")
Internal Crossover Yes
Weight Net 21.9kg (48.28 lbs)
Family ELX
Case Material 9-ply, 15mm Plywood, Internally Braced, with Textured Paint
Axial Sensitivity (SPL, 1 W @ 1 m) 95dB

Recommended Amplifiers

For optimal sound system performance, Electro-Voice recommends the following amplifiers for ELX115.
