便携式无源反送扬声器
产品
 |
 | |
TX1122FM |
TX1152FM | |
| 频响范围（- 10分贝） | 55 - 20000 | 45 - 20000 |
| 悬吊安装 | No | No |
| 最小阻抗 | 6.4 | 6.2 |
| 标称阻抗（无源） | 8 | 8 |
| 高频传感器 | DH3 | DH3 |
| 扬声器类型 | Monitor | Monitor |
| 低音尺寸 | 12 | 15 |
| 有源或无源 | Passive | Passive |
| Frequency Response (-3 dB)¹ | 70 - 20000 | 65 - 20000 |
| Max. SPL/1m (calc)² | 132 | 133 |
| 覆盖率（标称- 6分贝）H | 90 | 90 |
| 覆盖率（标称- 6分贝）V | 50 | 50 |
| 低频传感器 | SMX2121 | SMX2151 |
| 额定功率 | 2000 | 2000 |
| 系统功率处理（连续/曲目/峰值） | 500 | 500 |
| 旋转角 | No | No |
| 分频频率 | 1600 | 1750 |
| 外壳材料 | Ply Wood and MDF with EVCOAT | Plywood and MDF with EVCOAT |
| 灵敏度1 W/1 m | 99 | 100 |
| 可选颜色 | 黑色 | 黑色 |
| 高度 | 440 | 475 |
| 宽度 | 364 | 439 |
| 推荐高通频率 | 60 | 45 |
| 深度 | 573 | 655 |
| 内置分频频率 | Yes | Yes |
| 净重 | 19.8 | 23.5 |
| 家族 | Tour X | Tour X |
| 输入连接 | Parallel Neutrik® NL4 | Parallel Neutrik® NL4 |
| 更多 | 更多 |
Show more specs
下载
Technical Documentations
Certification/Regulatory
Engineering Data Sheet
Manual
| Name | Language & Download |
|---|---|
| Tour-X Series User & Installation Manual | EN |
White Paper
| Name | Language & Download |
|---|---|
| Audio 101 - Basic Audio Terminology | EN |
| Audio 101 - Loudspeaker Basics | EN |
| EASE Data Explanation | EN |
| PA Bible 02: Power Handling Capacity | EN |
| PA Bible 06: The Constant Directivity White Horn White Paper | EN |
| PA Bible 11: Portable Sound Systems for the Small Club | EN |
| The EV PA Bible | EN |
| The PA Bible Chapter Zero | EN |
