RE20
广播播音话筒（采用variable-d设计）
- Variable-D设计，最小化近讲效应；真正的心形指向性，在180°偏轴时亦无'声染色"；与录音室电容传声器性能类似；大振膜；哼声抑制线圈；低频衰减开关
RE20 Variable-D是动圈心形话筒，真正达到行业标准，倍受世界各地播音员和音响师的青睐。也可作为高级乐器话筒广泛用于音乐制作。Variable-D设计，内置耐用的爆破音过滤装置，可降低近讲效应，内置防震架，可减少振动引起的噪声。
Specifications
| Connector Type | 3-pin XLR |
| Height | 217 |
| Frequency Response (-3 dB) | 45 - 18,000 Hz |
产品规格 |
|
| Weight Net | 0.737 |
| Family | RE Series Broadcast |
| Wired/Wireless | Wired |
| Mic Type | Vocal/Instrument |
| Diameter (Max) | 54 |
| Element | Dynamic |
| Impedance, Low-Z balanced | 150 |
| Open Circuit Voltage | 1.5 |
| Case Material | Steel |
| Finish | Fawn Beige |
| Power Requirement | Passive |
| Polar Pattern | Cardioid |
Where to Buy
Retail Partners
便携式扬声器&麦克风
* Call for availability
下载
Technical Documentations
Certification/Regulatory
Engineering Data Sheet
| Name | Language & Download |
|---|---|
| RE20 Engineering Data Sheet | EN |
White Paper
| Name | Language & Download |
|---|---|
| Audio 101 - Basic Audio Terminology | EN |
| Audio 101 - Loudspeaker Basics | EN |
| Audio 101 - Microphone Basics | EN |
| Microphone Facts- Axial Response | EN |
| PA Bible 03: Microphone Types | EN |
| PA Bible 08: Microphone Techniques | EN |
| PA Bible 15: Barrier Miking | EN |
| The EV PA Bible | EN |
| The PA Bible Chapter Zero | EN |
| Variable-D & Beyond - Classic EV Microphone Design & Evolution | EN |
