X12-128
双18"超低频扬声器
X-Line新一代X12-128低音单元提供EV有史以来最优质的低频冲击和性能。这确实是一款先进的紧凑型箱体，较之目前其他的低音单元，它能在更小的体积中提供更多的低频输出。除了它的高输出性能外，X12-128 的设计使其能同X-Line新一代线阵列扬声器的任何箱体无缝匹配。其卓越的配置灵活性，便捷的系统设计和设置，使其成为众多大型现场演出和固定安装场所的理想选择。
Specifications
| Speaker Type | Subwoofer |
| Frequency Response (-3 dB)¹ | 33 - 200 |
| Coverage (Nominal -6 dB) H | 360 |
产品规格 |
|
| LF Transducer | 2 x 18-Inch DVF4180 |
| Enclosure Material | EVCoat-coated birch plywood |
| Sensitivity 1 W/1 m | 105 |
| Height | 1101.34 |
| Width | 762.00 |
| Depth | 517.14 |
| Weight Net | 88.45 |
| Passive Power Handling | 16000 |
Videos
X-Line Advance line-array loudspeaker system from Electro-Voice
Walking on Cars concert in Dublin boasts large Electro-Voice X-Line Advance system
X-Line Advance overview – Powa Productions, Australia
X-Line Advance Compact Vertical Line-Array Loudspeaker Systems
Recommended Amplifiersffs
For optimal sound system performance, Electro-Voice recommends the following amplifiers for X12-128.
Dynacord TGX Series更多 |
Dynacord IPX Series更多 |
|
|---|---|---|
| Two-Channel | ||
| Multi-Channel | ✔ | ✔ |
| DSP | ✔ | ✔ |
| Direct Drive | ✔ | ✔ |
| OMNEO (Dante, OCA) | ✔ | ✔ |
| Installation | ✔ | ✔ |
| Live Sound |
