Specifications
| Frequency Range (-10 dB) | 80 - 7000kHz |
| Weight Net | 18.96lbs (8.6kg) |
| Depth | 5.25" (133.4mm) |
Specifications |
|
| Weatherized | No |
| Nominal Impedance (Passive) | 8Ω |
| System Power Handling (Continuous/Program/Peak) | 300//1200Watts |
| Max. SPL/1m (calc) | 125dB |
| Sensitivity 1 W/1 m | 100dB |
| Coil Diameter | 2.5" (63.5mm) |
| Efficiency | 5.9% |
| Frame front diameter | 12.19" (309.6mm) |
| Magnet diameter | 7.5" (190.5mm) |
| Mounting bolt circle diameter | 11.56" (293.7mm) |
| Baffle cutout diameter | 11.06" (281mm) |
| Impedance | 8Ω |
| Power Rating | 1200W |
| Speaker Type | Components |
| Available Color | Black |
| Cone Diameter | 12.01" (305mm) |
