ND86
Dynamic supercardioid vocal microphone
- Excellent acoustic control in even the largest of venues
Reduction of low-frequency room tone through high-pass filtering and boosts & cuts in key high-mid frequencies separate the voice from the stage wash - Large-diaphragm dynamic capsule
Creates a rich and detailed frequency response - Shock-mounted capsule minimizes handling noise
Low frequency bumps and thumps won’t get into the PA - Humbucking coil guards against line hum
Use with confidence near speaker cabinets and EMF-generating equipment racks - Memraflex grille resists denting
Durable tight-mesh grilles withstand extraordinarily rough treatment
The ND86 is a robust, high-performance, large-diaphragm dynamic supercardioid vocal microphone. Designed for excellent acoustic control in even the largest of venues, the ND86 capsule is precisely tuned to deliver present, smooth, and detailed sound, as well as superior isolation from sound on the stage.
Specifications
| Shipping Weight | 21.2oz (601g) |
| Weight Net | 11.5oz (326g) |
| Height | 7.19" (182.5mm) |
Specifications |
|
| Connector Type | 3-pin XLR |
| Maximum SPL | > 140dB |
| Family | ND Series |
| Polar Pattern | Supercardioid |
| Wired/Wireless | Wired |
| Mic Type | Handheld |
| Diameter (Max) | 1.99" (50.5mm) |
| Element | Dynamic |
| Impedance, Low-Z balanced | 350Ω |
| Open Circuit Voltage | 2.4mV/Pascal |
| Case Material | Die cast zinc |
| Finish | Black polyurethane paint |
| Power Requirement | Passive |
| Audio Frequency Response | 70 – 17,000 |
