PWS-4 PWS-6 and PWS-C
Programmable wall stations
- Modular standard-mount keypads for NetMax
- Convenient control for volume, source, presets, etc.
- Up to three front units in a wall station
- PWS-C connects front units to CAN bus
- Easy daisy-chaining with included connection wire
- Easy labeling, protected by transparent cover
- Integrated status LEDs
- Button and LED configuration via IRIS-Net
- Customizable button behavior (momentary, latching, or radio)
Specifications
| Network Control (IRIS-Net) | Yes |
| Power Consumption | 480 mW (PWS-C), 175 mW (PWS-4), 150 mW (PWS-6) |
| CAN Bus Interface | 10-Pole Terminal Block |
Specifications |
|
| Supply Voltage | 9 - 58 VDC |
| Supply Current | 20 mA @ 24 V DC (PWS-C) |
