RE320
Variable‑d dynamic vocal & instrument microphone
- Variable-D™ pattern control minimizes positional and off-axis tonal shifts
- Integrated humbucking coil and integral pop filters provide virtually noiseless performance
- Unique dual-voicing switch selects from two response curves
A professional-grade dynamic microphone designed specifically for recording and sound reinforcement applications requiring extremely low noise and the best possible tonal and transient response. Ideal for capturing a wide variety of vocal and instrument sources, the RE320 delivers unparalleled detail, dynamic response, and pleasing natural tone.
Specifications
| Generating Element: | Dynamic N/Dym Magnet Structure |
| Frequency Response: | 30 Hz - 18,000 Hz (kick curve) 45 Hz - 18,000 Hz (general curve) |
| Polar Pattern: | Cardioid |
Specifications | |
| Impedance: | 150 ohms balanced |
| Sensitivity, Open Circuit Voltage, 1 kHz: | 2.5 mV/pascal |
| Hum Pickup Level, typical (60 Hz/1 millioersted field): | -130 dBm |
| Polarity: | Pin 2 will be positive referenced to Pin 3 with positive pressure on diaphragm |
| Case Material: | Steel |
| Dimensions: | Length = 216.7 mm (8.53 in) Widest Diameter = 54.4 mm (2.14 in) Body Diameter = 49.2 mm (1.94 in) |
| Finish: | Semi-Gloss Black |
| Net Weight: | 681 g (1 lb, 8 oz) |
| Shipping Weight: | 1503 g (3 lb, 5 oz) |
| Accessories Furnished: | 81715 stand clamp |
| Optional Accessories: | WSPL-2 Foam Wind Screen 309A Isolation Mount |
