RE92Tx

Directional lavalier microphone

  • Back-electret condenser element
  • Cardioid polar pattern
  • Integrated 6-foot (180cm) cable
  • TA4F connector is compatible  with all EV bodypack transmitters
  • Use with TXA for wired XLR applications

The RE92Tx is a miniature professional-quality electret condenser lavalier microphone with a cardioid pickup pattern. Designed for speech, it is an excellent choice for use in presentations, houses-of-worship, broadcast, or theater applications.

Specifications

Weight Net 0.81oz (23g)
Height 0.41" (10.5mm)
Connector Type TA4F

Maximum SPL (1% THD) 135dB
Mic Type Lavalier
Diameter (Max) 0.94" (24mm)
Element Back Electret Condenser
Open Circuit Voltage 5.6mV/Pascal
Case Material Metal
Finish Non-reflecting Black
Current Consumption < 500 uA
Family RE Series Installation
Polar Pattern Cardioid
Wired/Wireless Wireless
