Specifications
| Frequency Response (-3dB) | 90 Hz-18 kHz¹ |
| Frequency Range (-10 dB) | 75 Hz-20 kHz¹ |
| Max Calculated SPL | 138 dB Cont., 144 dB Peak² |
Specifications | |
| Horizontal Coverage | 90° |
| Vertical Coverage | Array Dependant, Software Definable |
| Rigging | Fully Captive Aluminum, 1° increments, 16 elements with 8 to 1 Safety Factor |
| LF Power Handling | 200W Cont., 800W Peak |
| HF Power Handling | 80W Cont., 320W Peak |
| LF to HF Crossover Frequency | 1760 Hz³ |
| LF Passband | 1 x 8 inch DVN2080, 16 ohms |
| HF Passband | 2 x ND2S-8, 16 ohms |
| Connectors | Gland nut with 30 ft cable |
| Enclosure | 13-ply birch plywood with fiberglass and EVCoat |
| Grille | Stainless steel with powder coat paint and hydrophobic cloth |
| Environmental Specifications | IEC 60529, IP55 |
| Dimensions (H x W x D) | 9.90 in x 20.30 in x 14.52 in (251 mm x 516 mm x 369 mm) |
| Net Weight | 38 lb (17.2 kg) |
| Shipping Weight | 41 lb (18.4 kg) |
