ND96

Dynamic supercardioid vocal microphone

Summary & Images Specs Where to buy Downloads & Support
  • Push vocals through the mix
    Structural and acoustical functions allow the signal to be pushed through incredibly loud ambient volumes without risking feedback
  • Large-diaphragm dynamic capsule
    Creates a rich and detailed frequency response
  • Vocal presence emphasis switch
    A selectable voice presence booster reduces certain low-mid frequency areas and emphasizes key upper-midrange vocal presence areas for a more profound vocal edge when driving the voice higher in the mix
  • Shock-mounted capsule minimizes handling noise
    Low frequency bumps and thumps won’t get into the PA
  • Humbucking coil guards against line hum
    Use with confidence near speaker cabinets and EMF-generating equipment racks
  • Memraflex grille resists denting
    Durable tight-mesh grilles withstand extraordinarily rough treatment

The ND96 is a robust, high-performance, large-diaphragm dynamic supercardioid vocal microphone. Designed for excellent acoustic control on very loud stages, the ND96’s special structural and acoustical designs create performance characteristics allowing the microphone’s gain before feedback in a mix to be significantly louder than most microphones.

Specifications

Connector Type 3-pin XLR
Height 6.69" (170mm)
Weight Net 11.39oz (323g)

Shipping Weight 21.2oz (601g)
Family ND Series
Polar Pattern Supercardioid
Wired/Wireless Wired
Mic Type Handheld
Diameter (Max) 1.99" (50.5mm)
Element Dynamic
Impedance, Low-Z balanced 350Ω
Open Circuit Voltage 3.3mV/Pascal
Case Material Die cast zinc
Finish Black polyurethane paint
Power Requirement Passive
Audio Frequency Response 140 – 15,000
Maximum SPL > 140dB
