EVI-AC
Ev innovation诊断卡
该访问卡是EV-Innovation 扬声器家族特有的配置。这张简便的插入设备允许对音箱内部的换能器和保护电路进行诊断,而不需要在插拔该卡之前断开连接或者拆开音箱。说明手册中描述的DCR 值一般适用于EV-I系列两分频系统(如: EVF-1122S/64)
Specifications
Speaker Type | Full-Range, Two-Way |
Shipping Weight | 0.453 |
