X2-212/90
High‑performance compact 12" vertical line array loudspeaker system
- DVN3125 12-Inch Neodymium Woofer
- Higher Output, Lower Distortion
- Mid-Band Hydra (MBH) Superior Box Coupling
- Advanced PDH Pin Diffraction Hydra Controlled Linear HF Performance
- Integrated Rigging System (IRS) Quick Setup
The X2 System provides high SPL capability, extended HF response, and linear LF output for more performance than previously possible in an extremely compact cabinet.
Specifications
| HF Transducer | Two 3-Inch ND6A |
| Speaker Type | Full-Range, Line-array |
| Frequency Response (-3 dB)¹ | 52 Hz - 19 kHz |
Specifications |
|
| Coverage (Nominal -6 dB) H | 90° |
| LF Transducer | 12-Inch DVN3125 |
| Enclosure Material | EVCoat-coated birch plywood |
| Sensitivity 1 W/1 m | 101dB |
| Height | 342.9mm (13.5") |
| Width | 723.9mm (28.5") |
| Depth | 536.6mm (21.13") |
| Weight Net | 42.18kg (92.99 lbs) |
| Passive Power Handling | 2000W peak |
Videos
X-Line Advance line-array loudspeaker system from Electro-Voice
6 gigs/week, 300+ gigs/year. X2 performing flawlessly.
X2 Rocks the Gampel Open Air
Walking on Cars concert in Dublin boasts large Electro-Voice X-Line Advance system
X-Line Advance overview – Powa Productions, Australia
X-Line Advance Compact Vertical Line-Array Loudspeaker Systems
Recommended Amplifiersffs
For optimal sound system performance, Electro-Voice recommends the following amplifiers for X2-212/90.
Dynacord TGX SeriesLearn More |
Dynacord IPX SeriesLearn More |
|
|---|---|---|
| Two-Channel | ||
| Multi-Channel | ✔ | ✔ |
| DSP | ✔ | ✔ |
| Direct Drive | ✔ | ✔ |
| OMNEO (Dante, OCA) | ✔ | ✔ |
| Installation | ✔ | ✔ |
| Live Sound |
