ZX3

12" passive loudspeaker

  • Versatile performance for mains, fills, or monitors
  • DVX3121A woofer with forced-air cooling
  • 2-inch ND2 titanium/neodymium HF driver
  • Passive crossover
  • Choice of 90º x 50º or 60º x 60º coverage horn
  • High sensitivity, 131 dB maximum SPL
  • Power handling: 600 W continuous, 2400 W peak
  • High-impact polypropylene enclosure
  • Compact monitor-friendly wedge shape
  • Up to four anchor-plate attachments
  • M8 mounting inserts (7)
  • Integrated handle
  • Available in black and white

Specifications

Frequency Range (-10 dB)48 - 20000
WeatherizedYes
FlyingYes
Minimum Impedance6.2
HF Transducer2-inch ND2
Speaker TypeFull-Range

Woofer Size12
Powered or PassivePassive
Frequency Response (-3 dB)¹58 - 15000
Max. SPL/1m (calc)²131
Coverage (Nominal -6 dB) H90/60
Coverage (Nominal -6 dB) V50/60
LF Transducer12-inch DVX3121A
System Power Handling (Continuous/Program/Peak)600//2400
Power Rating2400
LF Power Handling500
HF Power Handling40
Crossover Frequency2000
Enclosure MaterialHigh Impact Polystyrene Composite
GrillePolyester Powder Coated, 18GA Galvanized Steel
Available ColorBlack or white
Sensitivity 1 W/1 m97
Height613
Recommended High-Pass Frequency50
Width397
Depth362
Internal CrossoverYes
Weight Net19.8
FamilyZxZxA
Input Connections2 conductor SJO cable and gland nut
Nominal Impedance8
