Professional Loudspeakers & Mics
Specifications
| Frequency Range (-10 dB) | 40 Hz - 180 Hz |
| Speaker Type | Subwoofer |
| Woofer Size | 15 |
| Powered or Passive | Powered |
| Frequency Response (-3 dB)¹ | 45 Hz - 150 Hz |
| Max. SPL/1m (calc)² | 133 |
Specifications | |
| LF Transducer | EVS-15C 381 mm (15 in) |
| Power Rating | 1300 |
| Connector Type | (2) XLR/TRS combo jacks and (2) XLR link outputs |
| Enclosure Material | 15 mm, plywood with EVCoat |
| Grille | 18 AWG steel with powdercoat |
| Height | 455 |
| Width | 530 |
| Depth | 551 |
| Weight Net | 26.2 |
| Shipping Weight | 32.6 |
| Power Consumption³ | 1.8 A |
| Family | EKX |
| Maximum SPL | 133 dB peak |
| Low Pass Frequency | Adjustable: 80 Hz, 100 Hz, 120 Hz, 150 Hz |
