Sx600

High output 2‑way loudspeaker

  • Very High Sensitivity, 105 dB 1 W/1 m (139 dB Peak SPL)
  • Easy, Versatile, SuperSAM Mounting System included
  • All Weather IEC 529 IP 44 & Mil Spec 810 Environmental Specs
  • Available 600 Watt Internal Transformer (Sx600PIX)
  • EN54-24 Type B certification 1438-CPD-0300
  • Waterproof connection by SJO cable with gland nut

The Sx600 is a high-output, indoor/outdoor speaker system that features a dual-element vertical line array for clarity and intelligibility. The Sx600 handles 600-watts (2400 watts peak), and can be vertically mounted.

Specifications

Frequency Range (-10 dB)70 - 16000
WeatherizedYes
FlyingYes
Minimum Impedance3.5
Nominal Impedance (Passive)4
HF Transducer2-inch DH2T

Speaker TypeFull-Range, Two-Way
MF TransducerND12A
Woofer Size12
Max. SPL/1m (calc)²139
Coverage (Nominal -6 dB) H65
LF TransducerOne 12-inch DL12BFH (LF), one 12-inch ND12 (MB)
Coverage (Nominal -6 dB) V65
Power Rating2400
System Power Handling (Continuous/Program/Peak)600//2400
Crossover Frequency1800
Enclosure MaterialHigh Density Polymer (Composite)
Available ColorBlack
Sensitivity 1 W/1 m105
Height1163
Width429
Recommended High-Pass Frequency90 @Q=1.6
Internal CrossoverYes
Depth312
Weight Net36.3
FamilySx
Axial Sensitivity (SPL, 1 W @ 1 m)105
Passive Power Handling2400
Chassis Size304.8
Input ConnectionsSJO cable/gland nut
Directivity Index11.3
