ETX-18SP
18" powered subwoofer
- 18-inch DVX woofer for extended low-frequency response
- 1800 W Class-D power amplifier with integrated FIR-Drive DSP
- 135 dB peak SPL
- Special DSP preset for true cardioid performance across the full operating bandwidth
- Combo pole cup (insert and threaded) for use with the ETX Powered Loudspeaker full range models
- Removable casters
Specifications
| Power Rating | 1800 W |
| LF Transducer | DVX3180A 457 mm (18 in) |
| Low Pass Frequency | Adjustable: 80 Hz, 100 Hz, 120 Hz, 150 Hz |
Specifications | |
| Connectors | (2) XLR/TRS Combo Jack and (2) XLR link Output |
| Enclosure | 18 mm, 13-ply birch plywood with EVCoat |
| Grille | 16AWG steel with powdercoat |
| Dimensions (H x W x D) | 550 mm x 675 mm x 910 mm (22 in x 27 in x 36 in) |
| Dimensions (H x W x D) | without casters 550 mm x 675 mm x 777 mm (22 in x 27 in x 31 in) |
| Net Weight | 51.8 kg (114.2 lb) |
| Shipping Weight | 58.9 kg (129.9 lb) |
| Power Consumption | 100 - 240 V~, 50 - 60 Hz, 1.6 - 0.8 A³ |
² Maximum SPL is measured at 1 m using broadband pink noise at maximum amplifier output. ³ Current rating is 1/8 power.
Similar Products
Compatible Products
Downloads
| Name | Language | Size | Date |
|---|---|---|---|
| ProSound Loudspeakers and Electronics Catalog | EN | 15.43MB | 04.02.2019 |
| Portable speakers catalog 2020 EMEA | EN | 9.22MB | 01.21.2020 |
| Portable speakers catalog 2020 NA | EN | 10.63MB | 05.22.2020 |
| Retail catalog EMEA | EN | 59.07MB | 11.10.2020 |
| Portable speakers catalog 2020 EMEA | PL | 6.77MB | 05.12.2020 |
| Portable speakers catalog 2020 EMEA | FR | 6.76MB | 05.12.2020 |
| Portable speakers catalog 2020 EMEA | ES | 6.76MB | 05.12.2020 |
| Portable speakers catalog 2020 EMEA | EL | 6.78MB | 05.12.2020 |
| Portable speakers catalog 2020 EMEA | DE | 6.76MB | 05.12.2020 |
| Retail catalog EMEA | DE | 29.85MB | 11.10.2020 |
| Name | Size | Date |
|---|---|---|
| Environmental Compliance Document | 148KB | 10.03.2017 |
| Name | Size | Date | |
|---|---|---|---|
| ETX 18SP SIMPLIFIED CAD Drawing | ZIP | 594KB | 04.27.2018 |
| Name | Size | Date | |
|---|---|---|---|
| ETX | ZIP | 414KB | 01.24.2018 |
| Name | Language | Size | Date |
|---|---|---|---|
| ETX18SP Data Sheet | EN | 502KB | 03.05.2014 |
| Name | Language | Size | Date |
|---|---|---|---|
| ETX Powered Loudspeaker Hardware Accessory Manual | EN | 4.76MB | 09.12.2014 |
| ETX Powered Loudspeakers User Manual | EN | 7.6MB | 05.31.2016 |
| Enceintes amplifiées ETX Guide | FR | 8.29MB | 05.31.2016 |
| ETX Powered Loudspeakers Manual | ES | 7.76MB | 05.31.2016 |
| ETX Powered Loudspeakers Manual | PT | 7.78MB | 05.31.2016 |
| ETX Powered Loudspeakers 설치 매뉴얼 | KO | 7.91MB | 05.31.2016 |
| ETX パワードスピーカー マニュアル | JA | 7.99MB | 05.31.2016 |
| ETX 说明书 | ZH | 8.14MB | 05.27.2016 |
| ETX-Aktivlautsprecher Benutzerhandbuch | DE | 7.77MB | 05.31.2016 |
| Name | Size | Date |
|---|---|---|
| ATME College of Engineering 1 | 1.48MB | 12.09.2015 |
