ND76
Dynamic cardioid vocal microphone
- Excellent all-around vocal performance
Crisp, clear and balanced - Large-diaphragm dynamic capsule
Creates a rich and detailed frequency response - Shock-mounted capsule minimizes handling noise
Low frequency bumps and thumps won’t get into the PA - Humbucking coil guards against line hum
Use with confidence near speaker cabinets and EMF-generating equipment racks - Memraflex grille resists denting
Durable tight-mesh grilles withstand extraordinarily rough treatment
The ND76 is a robust, high-performance, large-diaphragm dynamic cardioid vocal microphone. Designed to be a workhorse for excellent all-around voice applications, the ND76 capsule is precisely tuned to deliver crisp, clear, and balanced vocal presence, as well as superior isolation from sound on the stage.
Specifications
| Shipping Weight | 21.09oz (598g) |
| Weight Net | 11.39oz (323g) |
| Height | 7.19" (182.5mm) |
Specifications |
|
| Connector Type | 3-pin XLR |
| Polar Pattern | Cardioid |
| Wired/Wireless | Wired |
| Mic Type | Handheld |
| Diameter (Max) | 1.99" (50.5mm) |
| Element | Dynamic |
| Impedance, Low-Z balanced | 350Ω |
| Open Circuit Voltage | 2.4mV/Pascal |
| Case Material | Die cast zinc |
| Finish | Black polyurethane paint |
| Power Requirement | Passive |
| Audio Frequency Response | 70 – 17,000 |
| Maximum SPL | > 140dB |
| Family | ND Series |
