ETX-18SP
18" powered subwoofer
- 18-inch DVX woofer for extended low-frequency response
- 1800 W Class-D power amplifier with integrated FIR-Drive DSP
- 135 dB peak SPL
- Special DSP preset for true cardioid performance across the full operating bandwidth
- Combo pole cup (insert and threaded) for use with the ETX Powered Loudspeaker full range models
- Removable casters
Specifications
| Frequency Response (-3 dB) | 33 Hz – 150 Hz1 |
| Frequency Range (-10 dB) | 28 Hz – 180 Hz1 |
| Maximum SPL | 135 dB peak2 |
| Power Rating | 1800 W |
| LF Transducer | DVX3180A 457 mm (18 in) |
| Low Pass Frequency | Adjustable: 80 Hz, 100 Hz, 120 Hz, 150 Hz |
Specifications | |
| Connectors | (2) XLR/TRS Combo Jack and (2) XLR link Output |
| Enclosure | 18mm Plywood with EVCoat |
| Grille | 16AWG steel with powdercoat |
| Dimensions (H x W x D) | 550 mm x 675 mm x 910 mm (22 in x 27 in x 36 in) |
| Dimensions (H x W x D) without casters | 550 mm x 675 mm x 777 mm (22 in x 27 in x 31 in) |
| Net Weight | 51.8 kg (114.2 lb) |
| Shipping Weight | 58.9 kg (129.9 lb) |
| Power Consumption | 100 - 240 V~, 50 - 60 Hz, 1.6 - 0.8 A³ |
² Maximum SPL is measured at 1 m using broadband pink noise at maximum amplifier output. ³ Current rating is 1/8 power.
