RE3-HHT520

UHF wireless transmitter featuring RE520 condenser supercardioid microphone

Summary & Images Specs Downloads & Support

Handheld UHF wireless transmitter featuring RE520 condenser supercardioid microphone head for vocal performance and presentations. The RE520’s sound is detailed, full, and vivid, with a tight and clear low end, natural and present midrange, and an exceptionally-detailed high end. The supercardioid pattern provides excellent acoustic isolation.

The transmitter pairs perfectly with the RE3-RX diversity receiver. Setup is quick and simple using the RE3 clear frequency scan and sync functions, and the radio link between the robust handheld transmitter and diversity receiver delivers rock-solid system performance.

Components of the set:

RE520-RC3 microphone head
Microphone stand adapter
Two AA batteries
Engineering Data Sheet
Warranty card
Declaration of conformity

BAND DETAILS
Band name5L5H6M8MT
Bandwidth limits (MHz)488 – 524560 – 596653 – 663823 – 832
863 – 865
803 - 806
Tuning bandwidth36 MHz36 MHz10 MHz11 MHz3 MHz
Selectable frequencies14401440400440120
Transmit output power (mW)10 and 5010 and 5010 and 201010 and 50
CoverageGlobalGlobalGlobalSelect EuropeThailand only

Let's talk

Dynacord & Electro-Voice, together with our certified partners, are ready to help support you through planning, purchase, and setup. Services available through our network of highly-qualified associates and partners may include:

  • System Design
  • Installation
  • Programming & Commissioning

Find your local contact
