Wired Music & Performance Microphones
Produkte
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 | |
Co9 |
ND44 |
ND46 |
ND66 |
ND68 |
ND76 |
ND76S |
ND86 |
ND96 |
PL-33 |
PL-35 |
PL-37 |
PL-80a |
PL-80c |
RE20 |
RE20-BLACK |
RE27N/D |
RE320 |
RE420 |
RE520 |
RE920 | |
| Connector Type | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin, XLR-type | 3-pin, XLR-type | TA4F |
| Maximum SPL (1% THD) | 132dB | 149 dB SPL (1% THD)dB | 150 dB SPL (1% THD)dB | 148dB | |||||||||||||||||
| Height | 173mm (6.81") | 139mm (5.47") | 144.1mm (5.67") | 143mm (5.63") | 143mm (5.63") | 182.5mm (7.19") | 182.5mm (7.19") | 182.5mm (7.19") | 170mm (6.69") | 217mm (8.54") | 217mm (8.54") | 217mm (8.54") | 216.7mm (8.53") | 192mm (7.56") | 192mm (7.56") | 158mm (6.22") | |||||
| Weight Net | 11.82oz (335g) | 6.84oz (194g) | 10.9oz (309g) | 6.31oz (179g) | 13.19oz (374g) | 11.39oz (323g) | 11.39oz (323g) | 11.5oz (326g) | 11.39oz (323g) | 12.84oz (364g) | 8.32oz (236g) | 6.21oz (176g) | 11.75oz (333g) | 26oz (737g) | 26oz (737g) | 25.01oz (709g) | 24.02oz (681g) | 11.5oz (326g) | 11.71oz (332g) | 19.05oz (540g) | |
| Frequency Response (-3 dB) | 45 - 18,000 Hz | 45 - 18,000 Hz | 45 - 20,000 Hz | 30 - 18,000 Hz (kickcurve), 45 - 18,000 Hz (generic curve) | 50 Hz-20 kHz | 40 Hz-20 kHz | 80 - 18,000 Hz | ||||||||||||||
| Shipping Weight | 17.21oz (488g) | 20.6oz (584g) | 16.4oz (465g) | 24.8oz (703g) | 21.09oz (598g) | 20.21oz (573g) | 21.2oz (601g) | 21.2oz (601g) | 23.7oz (672g) | ||||||||||||
| Family | ND Series | ND Series | ND Series | ND Series | ND Series | ND Series | ND Series | ND Series | PL Series | PL Series | PL Series | PL Series | PL Series | RE Series Broadcast | RE Series Broadcast | RE Series Live Performance | RE Series Broadcast | RE Series Wired Live Performance | RE Series Wired Live Performance | RE Series Live Performance | |
| Finish | Cobalt | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Textured Satin Black | Textured Satin Black | Textured Satin Black | Textured Satin Black | Textured Satin Black | Fawn Beige | Fawn Beige | Satin Nickel | Semi gloss black | Black polyurethane paint | Black polyurethane paint | Non-reflecting Black |
| Open Circuit Voltage | 3.2mV/Pascal | 2.4mV/Pascal | 2.4mV/Pascal | 10mV/Pascal | 0.8mV/Pascal | 2.4mV/Pascal | 2.4mV/Pascal | 2.4mV/Pascal | 3.3mV/Pascal | 0.63mV/Pascal | 2.2mV/Pascal | 6mV/Pascal | 2.2mV/Pascal | 2.2mV/Pascal | 1.5mV/Pascal | 1.5mV/Pascal | 2.5mV/Pascal | 2.5mV/Pascal | 5.6 mV/Pascal (-45 dBV/Pa)mV/Pascal | 5.6 mV/Pascal (-45 dBV/Pa)mV/Pascal | 1.3mV/Pascal |
| Polar Pattern | Cardioid | Tight Cardioid | Supercardioid | Cardioid | Supercardioid | Cardioid | Cardioid | Supercardioid | Supercardioid | Supercardioid | Supercardioid | Cardioid | Supercardioid | Supercardioid | Cardioid | Cardioid | Cardioid | Cardioid | Cardioid | Supercardioid | Cardioid |
| Diameter (Max) | 53mm (2.09") | 48.5mm (1.91") | 56mm (2.2") | 21mm (0.83") | 60.8mm (2.39") | 50.5mm (1.99") | 50.5mm (1.99") | 50.5mm (1.99") | 50.5mm (1.99") | 54mm (2.13") | 54mm (2.13") | 54mm (2.13") | 49.2mm (1.94") | 49.5mm (1.95") | 49.5mm (1.95") | 24mm (0.94") | |||||
| Mic Type | Handheld | Instrument | Instrument | Instrument | Instrument | Handheld | Handheld | Handheld | Handheld | Instrument | Instrument | Instrument | Handheld | Handheld | Vocal/Instrument | Vocal/Instrument | Vocal/Instrument | Instrument/Vocal | Handheld | Handheld | Instrument |
| Maximum SPL | > 140dB | > 140dB | 146dB | > 140dB | > 140dB | > 140dB | > 140dB | > 140dB | |||||||||||||
| Element | Dynamic | Dynamic | Dynamic | Condenser | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic | Condenser (self-biased) | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic N/Dym Magnet Structure | Self-biased condenser | Self-biased condenser | Condenser (back-electret) |
| Power Requirement | Passive | Passive | 48 VDC Phantom | Passive | Passive | Passive | Passive | Passive | Passive | Passive | 11 to 52 VDC | Passive | Passive | Passive | Passive | Passive | None | 48 VDC phantom power | 48 VDC phantom power | 5 VDC (via optional bodypack) | |
| Case Material | Die cast zinc | Die cast zinc handle, ABS polycarbonate head | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Steel | Steel | Steel | Metal | Zinc die cast, steel wire cloth grille | Zinc die cast, steel wire cloth grille | Metal |
| Wired/Wireless | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired |
| Impedance, Low-Z balanced | 600Ω | 350Ω | 350Ω | 200Ω | 150Ω | 350Ω | 350Ω | 350Ω | 350Ω | 150Ω | 600Ω | 200Ω | 600Ω | 600Ω | 150Ω | 150Ω | 150Ω | 150Ω | 200Ω | 200Ω | 1000Ω |
| Audio Frequency Response | 50 - 18,000 Hz | 80 – 16,500 | 70 – 18,000 | 50 – 20,000 | 20 – 11,000 | 70 – 17,000 | 70 – 17,000 | 70 – 17,000 | 140 – 15,000 | 20 Hz - 10,000 Hz | 50 Hz - 16,000 Hz | 50 Hz - 16,000 Hz | 80 Hz - 16,000 Hz | 80 Hz - 16,000 Hz | |||||||
| Dynamic Range | 107dB | ||||||||||||||||||||
| Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr | Erfahren Sie mehr |
Show more specs
