Wired Music & Performance Microphones
Models
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 | |
Co9 |
ND44 |
ND46 |
ND66 |
ND68 |
ND76 |
ND76S |
ND86 |
ND96 |
PL-33 |
PL-35 |
PL-37 |
PL-80a |
PL-80c |
RE20 |
RE20-BLACK |
RE27N/D |
RE320 |
RE420 |
RE520 |
RE920 | |
| Connector Type | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin, XLR-type | 3-pin, XLR-type | TA4F |
| Maximum SPL (1% THD) | 132dB | 149 dB SPL (1% THD)dB | 150 dB SPL (1% THD)dB | 148dB | |||||||||||||||||
| Height | 173mm (6.81") | 139mm (5.47") | 144.1mm (5.67") | 143mm (5.63") | 143mm (5.63") | 182.5mm (7.19") | 182.5mm (7.19") | 182.5mm (7.19") | 170mm (6.69") | 217mm (8.54") | 217mm (8.54") | 217mm (8.54") | 216.7mm (8.53") | 192mm (7.56") | 192mm (7.56") | 158mm (6.22") | |||||
| Weight Net | 11.82oz (335g) | 6.84oz (194g) | 10.9oz (309g) | 6.31oz (179g) | 13.19oz (374g) | 11.39oz (323g) | 11.39oz (323g) | 11.5oz (326g) | 11.39oz (323g) | 12.84oz (364g) | 8.32oz (236g) | 6.21oz (176g) | 11.75oz (333g) | 26oz (737g) | 26oz (737g) | 25.01oz (709g) | 24.02oz (681g) | 11.5oz (326g) | 11.71oz (332g) | 19.05oz (540g) | |
| Frequency Response (-3 dB) | 45 - 18,000 Hz | 45 - 18,000 Hz | 45 - 20,000 Hz | 30 - 18,000 Hz (kickcurve), 45 - 18,000 Hz (generic curve) | 50 Hz-20 kHz | 40 Hz-20 kHz | 80 - 18,000 Hz | ||||||||||||||
| Shipping Weight | 17.21oz (488g) | 20.6oz (584g) | 16.4oz (465g) | 24.8oz (703g) | 21.09oz (598g) | 20.21oz (573g) | 21.2oz (601g) | 21.2oz (601g) | 23.7oz (672g) | ||||||||||||
| Family | ND Series | ND Series | ND Series | ND Series | ND Series | ND Series | ND Series | ND Series | PL Series | PL Series | PL Series | PL Series | PL Series | RE Series Broadcast | RE Series Broadcast | RE Series Live Performance | RE Series Broadcast | RE Series Wired Live Performance | RE Series Wired Live Performance | RE Series Live Performance | |
| Finish | Cobalt | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Black polyurethane paint | Textured Satin Black | Textured Satin Black | Textured Satin Black | Textured Satin Black | Textured Satin Black | Fawn Beige | Fawn Beige | Satin Nickel | Semi gloss black | Black polyurethane paint | Black polyurethane paint | Non-reflecting Black |
| Open Circuit Voltage | 3.2mV/Pascal | 2.4mV/Pascal | 2.4mV/Pascal | 10mV/Pascal | 0.8mV/Pascal | 2.4mV/Pascal | 2.4mV/Pascal | 2.4mV/Pascal | 3.3mV/Pascal | 0.63mV/Pascal | 2.2mV/Pascal | 6mV/Pascal | 2.2mV/Pascal | 2.2mV/Pascal | 1.5mV/Pascal | 1.5mV/Pascal | 2.5mV/Pascal | 2.5mV/Pascal | 5.6 mV/Pascal (-45 dBV/Pa)mV/Pascal | 5.6 mV/Pascal (-45 dBV/Pa)mV/Pascal | 1.3mV/Pascal |
| Element | Dynamic | Dynamic | Dynamic | Condenser | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic | Condenser (self-biased) | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic N/Dym Magnet Structure | Self-biased condenser | Self-biased condenser | Condenser (back-electret) |
| Mic Type | Handheld | Instrument | Instrument | Instrument | Instrument | Handheld | Handheld | Handheld | Handheld | Instrument | Instrument | Instrument | Handheld | Handheld | Vocal/Instrument | Vocal/Instrument | Vocal/Instrument | Instrument/Vocal | Handheld | Handheld | Instrument |
| Impedance, Low-Z balanced | 600Ω | 350Ω | 350Ω | 200Ω | 150Ω | 350Ω | 350Ω | 350Ω | 350Ω | 150Ω | 600Ω | 200Ω | 600Ω | 600Ω | 150Ω | 150Ω | 150Ω | 150Ω | 200Ω | 200Ω | 1000Ω |
| Power Requirement | Passive | Passive | 48 VDC Phantom | Passive | Passive | Passive | Passive | Passive | Passive | Passive | 11 to 52 VDC | Passive | Passive | Passive | Passive | Passive | None | 48 VDC phantom power | 48 VDC phantom power | 5 VDC (via optional bodypack) | |
| Case Material | Die cast zinc | Die cast zinc handle, ABS polycarbonate head | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Die cast zinc | Steel | Steel | Steel | Metal | Zinc die cast, steel wire cloth grille | Zinc die cast, steel wire cloth grille | Metal |
| Maximum SPL | > 140dB | > 140dB | 146dB | > 140dB | > 140dB | > 140dB | > 140dB | > 140dB | |||||||||||||
| Diameter (Max) | 53mm (2.09") | 48.5mm (1.91") | 56mm (2.2") | 21mm (0.83") | 60.8mm (2.39") | 50.5mm (1.99") | 50.5mm (1.99") | 50.5mm (1.99") | 50.5mm (1.99") | 54mm (2.13") | 54mm (2.13") | 54mm (2.13") | 49.2mm (1.94") | 49.5mm (1.95") | 49.5mm (1.95") | 24mm (0.94") | |||||
| Polar Pattern | Cardioid | Tight Cardioid | Supercardioid | Cardioid | Supercardioid | Cardioid | Cardioid | Supercardioid | Supercardioid | Supercardioid | Supercardioid | Cardioid | Supercardioid | Supercardioid | Cardioid | Cardioid | Cardioid | Cardioid | Cardioid | Supercardioid | Cardioid |
| Audio Frequency Response | 50 - 18,000 Hz | 80 – 16,500 | 70 – 18,000 | 50 – 20,000 | 20 – 11,000 | 70 – 17,000 | 70 – 17,000 | 70 – 17,000 | 140 – 15,000 | 20 Hz - 10,000 Hz | 50 Hz - 16,000 Hz | 50 Hz - 16,000 Hz | 80 Hz - 16,000 Hz | 80 Hz - 16,000 Hz | |||||||
| Wired/Wireless | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired |
| Dynamic Range | 107dB | ||||||||||||||||||||
| Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More |
Show more specs
Downloads
Technical Documentations
Certification/Regulatory
| Name | Language & Download |
|---|---|
| COBALT CO9 Mic EU Declaration of Conformity (2022-May) | EN |
| COBALT CO9 Mic UKCA Declaration of Conformity (2022-May) | EN |
| ND-Series Wired Mics EU Declaration of Conformity (2023-Sep) | EN |
| ND-Series Wired Mics UKCA Declaration of Conformity (2023-Sep) | EN |
| PL-Series Wired Mics EU Declaration of Conformity (2023-Sep) | EN |
| PL-Series Wired Mics UKCA Declaration of Conformity (2023-Sep) | EN |
| RE-SERIES & 635x Broadcast Mics EU Declaration of Conformity (2023-Sep) | EN |
| RE-SERIES & 635x Broadcast Mics UKCA Declaration of Conformity (2023-Sep) | EN |
| RE320 Mic EU Declaration of Conformity (2023-Sep) | EN |
| RE320 Mic UKCA Declaration of Conformity (2023-Sep) | EN |
| RE420-RE520 EU Declaration of Conformity (2023-Sep) | EN |
| RE420-RE520 UKCA Declaration of Conformity (2023-Sep) | EN |
| RE92x Wired Mics EU Declaration of Conformity (2023-Sep) | EN |
Engineering Data Sheet
| Name | Language & Download |
|---|---|
| Cobalt Co9 Engineering Data Sheet | EN DE ES FR |
| RE420 Engineering Data Sheet | EN DE ES FR JA KO TH ZH |
| RE520 Engineering Data Sheet | EN DE ES FR JA KO TH ZH |
| ND76-RC3 Engineering Data Sheet | DE |
| ND86-RC3 Engineering Data Sheet | DE |
| ND96-RC3 Engineering Data Sheet | DE |
| Co9R Engineering Data Sheet | EN |
| ND44 Engineering Data Sheet | EN |
| ND46 Engineering Data Sheet | EN |
| ND66 Engineering Data Sheet | EN |
| ND68 Engineering Data Sheet | EN |
| ND76 Engineering Data Sheet | EN |
| ND76S Engineering Data Sheet | EN |
| ND86 Engineering Data Sheet | EN |
| ND96 Engineering Data Sheet | EN |
| PL33 Engineering Data Sheet | EN |
| PL35 Engineering Data Sheet | EN |
| PL37 Engineering Data Sheet | EN |
| PL80A Data Sheet | EN |
| PL80c Engineering Data Sheet | EN |
| RE20 Engineering Data Sheet | EN |
| RE27N/D Engineering Data Sheet | EN |
| RE320 Engineering Data Sheet | EN |
| RE920Tx Engineering Data Sheet | EN |
Service Policies
White Paper
| Name | Language & Download |
|---|---|
| Audio 101 - Basic Audio Terminology | EN |
| Audio 101 - Loudspeaker Basics | EN |
| Audio 101 - Microphone Basics | EN |
| Microphone Facts- Axial Response | EN |
| Microphone Facts- The New Model 666R Joins the 666 Family | EN |
| PA Bible 03: Microphone Types | EN |
| PA Bible 08: Microphone Techniques | EN |
| PA Bible 15: Barrier Miking | EN |
| PA Bible 19: Condenser Microphones | EN |
| The EV PA Bible | EN |
| The PA Bible Chapter Zero | EN |
| Variable-D & Beyond - Classic EV Microphone Design & Evolution | EN |
Marketing Materials
Brochure
| Name | Language & Download |
|---|---|
| ND Series Microphones Brochure | Download |
Catalog
PR Image
| Name | Language & Download |
|---|---|
| Warped Tour 2009 042 | Download |
| Skerik 20 | Download |
| Avishai Cohen 04 | Download |
| IMG 0718 | Download |
| MG 5164 WARPED | Download |
| MG 4543 WARPED | Download |
| MG 5256 WARPED | Download |
| MG 5387 WARPED | Download |
| MG 5541 WARPED | Download |
| MG 8942 WARPED | Download |
| MG 9226 WARPED | Download |
| Electro-Voice ND66 Guitar | Download |
| ev 90years ndseries singer jan17 4c fullrights Original 27451 | Download |
| ev ndseries band feb16 4c fullrights Original 26671 | Download |
| ev ndseries band jan17 4c fullrights Original 27444 | Download |
| ev ndseries musician nov15 4c fullrights Original 27432 | Download |
| ev ndseries singer feb16 4c fullrights Original 26665 | Download |
| ev ndseries singer jan17 4c fullrights Original 27457 | Download |
| ND44 App-02 Original 25736 | Download |
| ND44 mounted on snare | Download |
| ND44 mounted on tom | Download |
| ND46 App-02 Original 25737 | Download |
| ND46 on floor tom-stand mounted | Download |
| ND46 on guitar amp | Download |
| ND66 Alt Application 3 | Download |
| ND66 Alt Application 4 | Download |
| ND66 Alt Application 5 | Download |
| ND66 App-02 Original 25739 | Download |
| ND66 on Hat Alt | Download |
| ND68 App-01 Original 25741 | Download |
| ND68 Application 1 | Download |
| ND68 Application 2 | Download |
| ND76 Singer | Download |
| ND86 App-01 Original 25742 | Download |
Product Image
