Wired Broadcast Microphones
- Most commonly used microphones in Radio and TV studio production
- Most commonly used microphones in Radio and TV field production
- World famous Variable-D pattern control technology
- Excellent voice tone
- Multi-stage isolation and pop filters
Building on a long legacy of outstanding performance and reliability, Electro-Voice studio and field production microphones have earned their place at the top of the broadcast industry. From the announce booth to the recording studio and out into the field, EV radio and television mics are the number-one choice for anyone who makes their living with their voice. Led by the legendary RE20 and RE27N/D Variable-D™ vocal microphones, our broadcast line sets the standard that professionals everywhere depend on.
Models
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 | |
635A |
635L |
635L/B |
635N/D-B |
RE20 |
RE20-BLACK |
RE27N/D |
RE320 |
RE50B |
RE50L |
RE50N/D-B |
RE50N/D-L |
RE92L | |
| Connector Type | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR | 3-pin XLR |
| Maximum SPL (1% THD) | 135dB | ||||||||||||
| Height | 5.94" (151mm) | 9.57" (243mm) | 9.57" (243mm) | 5.94" (151mm) | 8.54" (217mm) | 8.54" (217mm) | 8.54" (217mm) | 8.53" (216.7mm) | 7.76" (197mm) | 9.53" (242mm) | 7.76" (197mm) | 9.53" (242mm) | 0.41" (10.5mm) |
| Frequency Response (-3 dB) | 80 - 13,000 Hz | 80 - 13,000 Hz | 80 - 13,000 Hz | 80 - 13,000 Hz | 45 - 18,000 Hz | 45 - 18,000 Hz | 45 - 20,000 Hz | 30 - 18,000 Hz (kickcurve), 45 - 18,000 Hz (generic curve) | 80 - 13,000 Hz | 80 - 13,000 Hz | 80 - 13,000 Hz | 80 - 13,000 Hz | 40 - 20,000 Hz |
| Weight Net | 6oz (170g) | 11.43oz (324g) | 11.43oz (324g) | 6oz (170g) | 26oz (737g) | 26oz (737g) | 25.01oz (709g) | 24.02oz (681g) | 9.49oz (269g) | 10.79oz (306g) | 9.49oz (269g) | 11.29oz (320g) | 5.64oz (160g) |
| Family | Field Production | Field Production | Field Production | Field Production | RE Series Broadcast | RE Series Broadcast | RE Series Live Performance | RE Series Broadcast | RE Series Broadcast | RE Series Broadcast | RE Series Broadcast | RE Series Broadcast | RE Series Installation |
| Diameter (Max) | 1.42" (36mm) | 1.42" (36mm) | 1.42" (36mm) | 1.42" (36mm) | 2.13" (54mm) | 2.13" (54mm) | 2.13" (54mm) | 1.94" (49.2mm) | 1.93" (49mm) | 1.93" (49mm) | 1.93" (49mm) | 1.93" (49mm) | 0.94" (24mm) |
| Case Material | Steel | Zinc | Zinc | Steel | Steel | Steel | Steel | Metal | Aluminum | Aluminum | Aluminum | Aluminum | Metal |
| Open Circuit Voltage | 1.4mV/Pascal | 1.4 mV/PascalmV/Pascal | 1.4 mV/PascalmV/Pascal | 2.8mV/Pascal | 1.5mV/Pascal | 1.5mV/Pascal | 2.5mV/Pascal | 2.5mV/Pascal | 1.6mV/Pascal | 1.8 mV/PascalmV/Pascal | 2.2mV/Pascal | 2.2 mV/PascalmV/Pascal | 5.6mV/Pascal |
| Finish | Fawn Beige | Fawn Beige | Semi-gloss Black | Non-reflective black | Fawn Beige | Fawn Beige | Satin Nickel | Semi gloss black | Semi-Gloss Camera Black | Semi-Gloss Black | Semi-Gloss Camera Black | Semi-Gloss Black | Non-reflective black |
| Element | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic | Dynamic N/Dym Magnet Structure | Dynamic | Dynamic | Dynamic | Dynamic | Condenser (back-electret) |
| Power Requirement | Passive | Passive | Passive | Passive | Passive | Passive | Passive | None | Passive | Passive | Passive | Passive | 24 - 52 V Phantom |
| Impedance, Low-Z balanced | 150Ω | 150Ω | 150Ω | 150Ω | 150Ω | 150Ω | 150Ω | 150Ω | 150Ω | 150Ω | 150Ω | 150Ω | 250Ω |
| Polar Pattern | Omni | Omni | Omni | Omni | Cardioid | Cardioid | Cardioid | Cardioid | Omni | Omni | Omni | Omni | Cardioid |
| Wired/Wireless | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | |||
| Mic Type | Handheld | Handheld | Handheld | Handheld | Vocal/Instrument | Vocal/Instrument | Vocal/Instrument | Instrument/Vocal | Handheld | Handheld | Handheld | Handheld | Lavalier |
| Current Consumption | 6 mA | ||||||||||||
| Specials | external preamp | ||||||||||||
| Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More |
Show more specs
Downloads
| Name | Language | Size | Date |
|---|---|---|---|
| ProSound Loudspeakers and Electronics Catalog | EN | 15.43MB | Apr 2, 2019 |
| Microphone Catalog 2020 | EN | 10.97MB | Jul 3, 2020 |
| Name | Size | Date |
|---|---|---|
| Broadcast Mics, Studio Mics, EC Declaration of Conformity | 462KB | Oct 30, 2020 |
| Environmental Compliance Document | 148KB | Oct 3, 2017 |
| RE320 EC Declaration of Conformity | 571KB | Dec 18, 2019 |
| Name | Language | Size | Date |
|---|---|---|---|
| 635A Engineering Data Sheet | EN | 304KB | Mar 11, 2014 |
| 635L & 635L/B Engineering Data Sheet | EN | 216KB | Apr 23, 2015 |
| 635N/D 635N/D-B Engineering Data Sheet | EN | 53KB | Mar 21, 2012 |
| RE20 Engineering Data Sheet | EN | 311KB | Mar 21, 2012 |
| RE27N/D Engineering Data Sheet | EN | 81KB | Mar 21, 2012 |
| RE320 Engineering Data Sheet | EN | 548KB | Aug 7, 2012 |
| RE50/B Engineering Data Sheet | EN | 521KB | Mar 21, 2012 |
| RE50L Engineering Data Sheet | EN | 532KB | Oct 5, 2015 |
| RE50N/D-L Engineering Data Sheet | EN | 526KB | Oct 5, 2015 |
| RE50ND Engineering Data Sheet | EN | 88KB | Jan 10, 2013 |
| RE50ND Engineering Data Sheet | EN | 642KB | May 3, 2012 |
| RE92L Engineering Data Sheet | EN | 284KB | Nov 13, 2015 |
| Name | Language | Size | Date |
|---|---|---|---|
| RE320 flyer español | ES | 634KB | Sep 27, 2012 |
| Name | Language | Size | Date |
|---|---|---|---|
| PL20 & RE20 Service Data | EN | 270KB | Sep 19, 2005 |
| RE20 Service Data | EN | 579KB | May 3, 2012 |
| Name | Size | Date |
|---|---|---|
| Skerik 20 | 4.84MB | Nov 2, 2015 |
| Avishai Cohen 04 | 3.64MB | Nov 2, 2015 |
| IMG 0718 | 179KB | Nov 2, 2015 |
635A beige-trans
635ND B-trans1
EV RE20 Black Front
EVLongMics 635L B cv1
EVLongMics 635L cv1
EVLongMics RE50L cv1
EVLongMics RE50ND-L cv1
RE20 Classic Front
RE27ND-trans
RE320-trans
RE50B-trans
RE50ND B-trans
RE92L mic-trans
EV RE20 Black 309A NoCable
EV RE20 Black 309A wCable
EVLongMics 635L B fr
EVLongMics 635L cv2-
EVLongMics 635L fr
EVLongMics 635L XLR
EVLongMics 635LB cv2
EVLongMics 635LB XLR
EVLongMics RE50L cv2
EVLongMics RE50L fr
EVLongMics RE50L XLR
EVLongMics RE50ND-L cv2
EVLongMics RE50ND-L fr
EVLongMics RE50ND-L XLR
RE20 Classic 309A NoCable
RE20 Classic 309A wCable
| Name | Language | Size | Date |
|---|---|---|---|
| Warranty conditions for Electro-Voice products in North America | EN | 160KB | Sep 14, 2020 |
| General Terms & Conditions of Deliver for Export Business | EN | 57KB | Nov 26, 2014 |
| Allgemeine Lieferbedingungen | DE | 184KB | Nov 30, 2016 |
| Name | Language | Size | Date |
|---|---|---|---|
| Audio 101 - Basic Audio Terminology | EN | 2.74MB | Dec 13, 2012 |
| Audio 101 - Loudspeaker Basics | EN | 3.02MB | Dec 13, 2012 |
| Audio 101 - Microphone Basics | EN | 4.25MB | Dec 13, 2012 |
| Microphone Facts- Axial Response | EN | 1.36MB | May 3, 2012 |
| Microphone Facts- Non-Directional Microphones | EN | 1.06MB | May 3, 2012 |
| Microphone Facts- The 635 is Dead, Long Live the 635A! | EN | 1.88MB | May 3, 2012 |
| PA Bible 03: Microphone Types | EN | 462KB | Dec 26, 2007 |
| PA Bible 08: Microphone Techniques | EN | 604KB | Dec 26, 2007 |
| PA Bible 15: Barrier Miking | EN | 254KB | Dec 26, 2007 |
| The EV PA Bible | EN | 1.14MB | Dec 26, 2007 |
| The PA Bible Chapter Zero | EN | 1.14MB | Jun 11, 2018 |
| Variable-D & Beyond - Classic EV Microphone Design & Evolution | EN | 206KB | Dec 16, 2011 |
