ELX200-15
15" passive loudspeaker
- 1200 W (peak), 130 dB peak SPL system that is reliability verified with over 500 hours of abuse testing and endurance testing to 4x typical industry practices.
- 1.4 inch DH-1L (1 inch exit) titanium compression driver for extended transparent high-frequency response.
- High-output EVS-15M woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction.
- EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading.
- Professional-grade hardware: three M10 threaded mounting points for forged eyebolts, integrated pole-mounts and the proven ZLX three-handle design for easy lifting.
The ELX series is designed to deliver an unprecedented combination of sound quality, portability and durability at its price point. All-new custom components—tested to levels far exceeding the industry norm—make ELX200 a robust workhorse capable of handling real-world abuse and professional applications beyond the capability of competitors’ products in its category.
Every aspect of ELX200 is designed for ideal results as part of the whole - the acoustical, electrical and mechanical components all work together seamlessly. The full-range models feature a low profile form factor designed with a high-spec composite enclosure to balance weight, manageability, as well as structural integrity. The proprietary features that have made the other members of the EV portable speaker family a goto for best-in-class performance are also present: Signal Synchronized Transducers (SST) waveguide concept.
EV's industry-leading quality and testing procedures yield efficient transducer design and meaningful specs, resulting in components that deliver accurate, linear response at the system’s highest output levels. Translation: loud and clear all the way up to the limit. Unified in one of the strongest full-range composite enclosures ever built by EV. The ELX200 is established as the new benchmark for toughness - both acoustically and physically; maximum efficiency with maximum toughness.
Specifications
Suspension | (3) M10 suspension points |
Minimum Impedance | 7.0Ω |
HF Transducer | DH-1L 1-inch titanium compression driver |
Specifications |
Speaker Type | Full-Range |
Woofer Size | 15inch |
Powered or Passive | Passive |
Frequency Response (-3 dB)¹ | 77 Hz - 16 kHz |
Frequency Range (-10 dB)¹ | 52 Hz - 19 kHz |
Max. SPL/1m (calc)² | 130dB |
Coverage (Nominal -6 dB) H | 90° |
Coverage (Nominal -6 dB) V | 60° |
LF Transducer | EVS-15M 381 mm (15 in) |
Power Rating | 1200W |
Crossover Frequency | 1.6 kHz |
Connector Type | Dual NL4 |
Enclosure Material | Polypropylene composite |
Grille | 18 AWG steel with powdercoat |
Available Color | Black or White |
Height | 710mm (27.95") |
Recommended High-Pass Frequency | 42Hz |
Width | 423mm (16.65") |
Depth | 384mm (15.12") |
Weight Net | 18.7kg (41.23 lbs) |
Shipping Weight | 21.4kg (47.18 lbs) |
Family | ELX200 |
Nominal Impedance | 8Ω |
Axial Sensitivity (SPL, 1 W @ 1 m) | 95dB |
Power Handling (Continuous / Peak) | 300W/1200W |
