ETX portable powered loudspeakers

The fully loaded flagship

State-of-the-art components
deliver breathtaking sonic power and clarity and maximum reliability: 1800 W (subs) & 2000 W (full-range) Class-D power amplifiers with integrated DSP produce high SPLs utilizing high-sensitivity, low-distortion transducers (including DVX & SMX series woofers and precision DH3-B HF titanium compression drivers).
Lightweight, ergonomic, durable, and compact
18-mm, 13-ply plywood enclosures finished with EVCoat. Eight mounting points for permanent installations (full-range models). Custom die-cast aluminum pole cups, handles and hardware.
EV’s FIR-Drive
utilizes the latest Finite Impulse Response (FIR) filter technology to optimize transducer linearity. Advanced limiter algorithms provide independent peak and thermal transducer protection.
Complete full-function QuickSmartDSP
control via a single-knob interface. LCD screen for easy system set-up and monitoring: location/application EQ presets (e.g. tripod, mounted, suspended, live, music, speech), limiter status, delay settings, input level controls/meters and master volume control to ensure optimal gain structure. Parametric EQ allows for more precise configuration. EV-exclusive Cardioid Control Technology feature for subwoofers allows output to be steered towards the audience with up to 35 dB reduction on stage when multiple subs are deployed.
EV-patented Signal Synchronized Transducers (SST)
waveguide design provides precise and consistent coverage across all system configurations. Waveguides are custom-designed and optimized per model.

The series combines intelligent FIR-Drive technology with innovative industrial design to deliver stunning performance and unbeatable versatility in the most demanding applications. EV-engineered components ensure superior sound quality and the utmost reliability. Building upon the legendary heritage of Electro-Voice audio engineering, ETX are designed to be the most advanced professional-grade portable loudspeakers available today.

Models

ETX-10P
10" powered loudspeaker

ETX-12P
12" powered loudspeaker

ETX-15P
15" powered loudspeaker

ETX-35P
15" powered 3‑way loudspeaker

ETX-15SP
15" powered subwoofer

ETX-18SP
18" powered subwoofer


	ETX-10P 10" powered loudspeaker	ETX-12P 12" powered loudspeaker	ETX-15P 15" powered loudspeaker	ETX-35P 15" powered 3‑way loudspeaker	ETX-15SP 15" powered subwoofer	ETX-18SP 18" powered subwoofer
Suspension	(8) M10 suspension points	(8) M10 suspension points	(8) M10 suspension points	(8) M10 suspension points
HF Transducer	DH3-B 1.25-in titanium compression driver	DH3-B 1.25-in titanium compression driver	DH3-B 1.25-in titanium compression driver	DH3-B 1.25-in titanium compression driver
Speaker Type	Full-Range, two-way	Full-Range, two-way	Full-Range, two-way, powered speakers	Full-Range, three-way, powered speakers	Subwoofer	Subwoofer
Woofer Size	10inch	12inch	15inch	15inch	15inch	18inch
MF Transducer				EVS-6C 6.5-in midbass driver
Powered or Passive	Powered	Powered	Powered	Powered	Powered	Powered
Frequency Range (-10 dB)¹	65 Hz – 20 kHz ()	43 Hz – 20 kHz	40 Hz – 20 kHz	38 Hz – 20 kHz	32 Hz – 180 Hz	28 Hz – 180 Hz
Max. SPL/1m (calc)²	134dB	135dB	135dB	136dB		135dB
Coverage (Nominal -6 dB) H	90°	90°	90°	60°
LF Transducer	SMX2100 254 mm (10 in)	SMX2120 300 mm (12 in)	SMX2150 380 mm (15 in)	SMX2151 380 mm (15 in)	DVX3159A 380 mm (15 in)	DVX3180A 457 mm (18 in)
Coverage (Nominal -6 dB) V	60°	60°	60°	40°
Power Rating	2000W	2000W	2000W	2000W	1800W	1800W
Crossover Frequency	1700Hz	1600Hz	1500Hz	700 Hz, 2900Hz
Connector Type	(2) XLR/TRS combo jack and (1) XLR link output	(2) XLR/TRS combo jack and (1) XLR link output	(2) XLR/TRS combo jack and (1) XLR link output	(2) XLR/TRS combo jack and (1) XLR link output	(2) XLR/TRS Combo Jack and (2) XLR link Output	(2) XLR/TRS Combo Jack and (2) XLR link Output
Enclosure Material	18-mm, 13-ply birch plywood with EVCoat	18-mm, 13-ply birch plywood with EVCoat	18-mm, 13-ply birch plywood with EVCoat	18-mm, 13-ply birch plywood with EVCoat	18-mm, 13-ply birch plywood with EVCoat	18mm Plywood with EVCoat
Grille	16AWG steel with powdercoat	16AWG steel with powdercoat	16AWG steel with powdercoat	16AWG steel with powdercoat	16AWG steel with powdercoat
Height	20.71" (526mm)	24.13" (613mm)	27.2" (691mm)	40.28" (1023mm)	18.54" (471mm)	21.65" (550mm)
Width	12.99" (330mm)	15" (381mm)	16.97" (431mm)	18.46" (469mm)	22.68" (576mm)	26.57" (675mm)
Depth	14.37" (365mm)	15.75" (400mm)	17.6" (447mm)	16.77" (426mm)	32.48" (825mm)	35.83" (910mm)
Frequency Response (-3 dB)	85 Hz – 20 kHz ()	55 Hz – 20 kHz	48 Hz – 20 kHz	48 Hz – 20 kHz	37 Hz – 150 Hz	33 Hz – 150 Hz
Weight Net	44.75lbs (20.3kg)	52.03lbs (23.6kg)	61.07lbs (27.7kg)	91.93lbs (41.7kg)	91.93lbs (41.7kg)	114.2lbs (51.8kg)
Shipping Weight	50.49lbs (22.9kg)	59.08lbs (26.8kg)	69.45lbs (31.5kg)	103.18lbs (46.8kg)	103.18lbs (46.8kg)	129.85lbs (58.9kg)
Power Consumption³	100 – 240 V~, 50 – 60 Hz, 1.6 – 0.8 A ()	100 – 240 V~, 50 – 60 Hz, 1.6 – 0.8 A	100 – 240 V~, 50 – 60 Hz, 1.6 – 0.8 A	100 – 240 V~, 50 – 60 Hz, 1.6 – 0.8 A		100 – 240 V~, 50 – 60 Hz, 1.6 – 0.8 A
Family	ETX	ETX	ETX	ETX	ETX	ETX
Maximum SPL	134 peakdB ()	135 peakdB	135 dB peakdB	136 peakdB	134 dB peakdB	135 dB peakdB
Low Pass Frequency					Adjustable: 80 Hz, 100 Hz, 120 Hz, 150 Hz	Adjustable: 80 Hz, 100 Hz, 120 Hz, 150 Hz
