Wall & Surface Mount Speakers
Premium surface‑mount speakers
EVID premium commercial loudspeakers bring best-in-class sonic characteristics and stunning high fidelity to a broad range of sound installation applications, including performance and sports venues, retail environments, conference and meeting rooms, and hospitality settings such as restaurants and bars. EVID loudspeakers, including our ceiling and wall mount models, feature innovative designs that enhance not only the sound of a room but also its looks. EVID 3.2, 4.2, and 6.2 models are available in "T"-designated versions with internal 70 or 100V line transformers. High power and high performance, EVID is the superior solution for today's smaller-format sound system installation needs.
Surface-mount speakers are designed to be installed directly onto flat surfaces like walls or ceilings, offering a versatile solution for integrating audio systems into various environments for outdoor and indoor use. This flexibility ensures that the speakers can be positioned for optimal sound coverage, enhancing the listening experience for patrons and audiences alike. The EVID series includes weather-resistant models, which make the perfect outdoor speakers where durability against the elements is crucial.
Whether you need powerful audio for a bustling retail space or clear, intelligible sound for a conference room, EVID surface-mount speakers offer the perfect blend of form and function to meet your requirements. Shop top-notch wall mount speakers and ceiling speakers for dual cabinet pairs, subwoofer, accessories and more.
Models
 |
|
 |
 |
|
 |
|
 |
|
 |
 | |
EVID-S4.2 |
EVID-S4.2T |
EVID 4.2 |
EVID-S5.2 |
EVID-S5.2T |
EVID-S5.2X |
EVID 6.2 |
EVID-S8.2 |
EVID-S8.2T |
EVID-S10.1D |
EVID-S12.1 | |
| Frequency Range (-10 dB) | 75 Hz – 20 kkHz | 75 Hz – 20 kkHz | 65 - 20000kHz | 60 Hz – 20 kkHz | 60 Hz – 20 kkHz | 55 Hz – 20 kkHz | 62 - 20000kHz | 50 Hz – 20 kkHz | 50 Hz – 20 kkHz | 33 Hz – 500kHz | 40Hz - 140kHz |
| Weatherized | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Minimum Impedance | 6.4Ω | 6Ω | 6Ω | 6Ω | 6Ω | 6Ω | 6Ω | 6Ω | |||
| Nominal Impedance (Passive) | 8Ω | 8Ω | |||||||||
| HF Transducer | 0.75 inch (20 mm) | 0.75 inch (20 mm) | 1-inch | 0.75 inch (20 mm) | 0.75 inch (20 mm) | 0.75 inch (20 mm) | 1-inch | 1 inch (25 mm) | 1 inch (25 mm) | ||
| Speaker Type | Full-Range, Mid-High, Two-Way | Full-Range, Mid-High, Two-Way | Subwoofer | ||||||||
| Frequency Response (-3 dB)¹ | 100 Hz – 20 kHz | 100 Hz – 20 kHz | 85 Hz – 20Hz | 85 Hz – 20Hz | 90 Hz – 20Hz | 70 Hz – 20 kHz | 70 Hz – 20 kHz | ||||
| Max. SPL/1m (calc)² | 103dB | 104.5dB | 115dB | 109dB | 109dB | 108dB | 122dB | 110dB | 110dB | 120dB | 127dB |
| Coverage (Nominal -6 dB) H | 110° | 110° | 120° | 90° | 90° | 90° | 100° | 90° | 90° | ||
| Coverage (Nominal -6 dB) V | 110° | 110° | 80° | 90° | 90° | 90° | 80° | 90° | 90° | ||
| LF Transducer | 4 inch (102 mm) | 4 inch (102 mm) | Two 4-inch | 5.25 inch (133 mm) | 5.25 inch (133 mm) | 5.25 inch (122 mm) | Two 6-inch | 8 inch (203 mm) | 8 inch (203 mm) | Two 10 inch (254 mm) | 12 inch (305 mm) |
| Power Rating | 160W | 60W | 400W | 600W | 360W | ||||||
| System Power Handling (Continuous/Program/Peak) | 100//400Watts | 150//600Watts | |||||||||
| LF Power Handling | Two 4-inchWatts | Two 6-inchWatts | |||||||||
| HF Power Handling | 1-inchWatts | 1-inchWatts | |||||||||
| Connector Type | Captive screws on wall bracket. Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm) | Captive screws on wall bracket. Max. wire size 12AWG (2.5mm). | Captive screws on wall bracket. Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm) | Captive screws on wall bracket. Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm) | Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm) | Captive screws on wall bracket. Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm) | Captive screws on wall bracket. Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm) | Two removable locking 4-pin connector (Euroblock) – Input and output. Max. wire size 12 AWG (2.5 mm). | Spring loaded | ||
| Sensitivity 1 W/1 m | 87dB | 86.5dB | 89dB | 90dB | 90dB | 90dB | 94dB | 94dB | |||
| Available Color | Black or White | Black or White | Black or white | Black or White | Black or White | Black or White | Black or white | Black or White | Black or White | Black or White | Black or White |
| Height | 309.89mm (12.2") | 255mm (10.04") | 255mm (10.04") | 255mm (10.04") | 419mm (16.5") | 390mm (15.35") | 390mm (15.35") | 356mm (14.02") | 413mm (16.26") | ||
| Width | 175.26mm (6.9") | 180mm (7.09") | 180mm (7.09") | 180mm (7.09") | 228mm (8.98") | 250mm (9.84") | 250mm (9.84") | 651mm (25.63") | 584mm (22.99") | ||
| Recommended High-Pass Frequency | 70Hz | 70Hz | 60Hz | 60Hz | 60Hz | 50Hz | 50Hz | 40Hz | |||
| Depth | 118mm (4.65") | 118mm (4.65") | 215.9mm (8.5") | 151mm (5.94") | 151mm (5.94") | 148mm (5.83") | 298mm (11.73") | 223mm (8.78") | 223mm (8.78") | 491mm (19.33") | 303mm (11.93") |
| Internal Crossover | Yes | Yes | |||||||||
| Weight Net | 1.5kg (3.31 lbs) | 1.8kg (3.97 lbs) | 3.9kg (8.6 lbs) | 2.7kg (5.95 lbs) | 3.2kg (7.05 lbs) | 3.2kg (7.05 lbs) | 5.3kg (11.68 lbs) | 5.1kg (11.24 lbs) | 5.8kg (12.79 lbs) | 17.9kg (39.46 lbs) | 17.8kg (39.24 lbs) |
| Shipping Weight | 5kg (11.02 lbs) | 5.4kg (11.9 lbs) | 6.7kg (14.77 lbs) | 7.9kg (17.42 lbs) | 9.5kg (20.94 lbs) | 13kg (28.66 lbs) | 14.8kg (32.63 lbs) | 21kg (46.3 lbs) | 22.4kg (49.38 lbs) | ||
| Environmental Specs | IP54 (per IEC-60529) | IP54 (per IEC-60529) | IP54 (per IEC-60529) | IP54 (per IEC-60529) | IP-65 (per IEC-60529) | IP54 (per IEC-60529) | IP54 (per IEC-60529) | IP-54 (per IEC-60529); IP-65 with port covers | |||
| Nominal Impedance | 8Ω | 8Ω | 8Ω | 8Ω | 8Ω | 8Ω | Stereo Mode: (2) 8ω; Mono Mode: (1) 4Ω | 8Ω | |||
| Transformer | 70V/100V (15W) | 70V/100V (30W) | 70V/100V (60W) | 70V/100V (60W) | |||||||
| Power Handling (Continuous / Peak) | 40 W/160W | 15 W/60W | 90W/360W | 90W/360W | 400W/1600W | 200W/800W | |||||
| Input Connections | Spring Terminal | Spring Terminal | |||||||||
| Transformer Taps (Transformer Version Only) | 70 V: 3.75 W, 70 V/100 V:7.5 W, 15 W,30 W,8ω Bypass | 70 V/100 V: 15 W, 30 W, 60 W, 8ω Bypass | Optional Accessory | ||||||||
| Regulatory Approvals | IP54 | ||||||||||
| Chassis Size | 101.6mm (4") | 152.4mm (6") | |||||||||
| Sensitivity (LF/MF/HF) | 104dB | ||||||||||
| Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More |
Show more specs
Recommended Amplifiers
recommendedamplifiers-p1
recommendedamplifiers-p2
|
Two-channel power amplifiers for fixed install |
Multi-channel power amplifier for commercial installations |
CPS contractor precision series amplifiers |
PA series multi-channel power for fixed install applications |
|
|---|---|---|---|---|
| Two-Channel | ✓ | |||
| Multi-Channel | ✓ | ✓ | ✓ | |
| powerTANK | ✓ | |||
| DSP | ✓ | |||
| Direct Drive | ✓ | ✓ | ✓ | |
| OMNEO (Dante, OCA) | ||||
| Installation | ✓ | ✓ | ✓ | ✓ |
