Live Sound Systems
Models
 |
|
 |
|
 |
 |
 |
 |
 |
 |
 |
 |
 | |
X1-212/90 |
X1-212/120 |
X2-212/120 |
X2-212/90 |
XLE181 |
Q1212 |
Q44 |
Q66 |
Q99 |
X12-128 |
XCS312 |
XLD281 |
Xsub | |
| Frequency Range (-10 dB) | 56 - 16,500kHz | 40 - 100kHz | 56-16,500kHz | 35 - 500kHz | |||||||||
| Suspension | : IRS — Integrated Rigging System | ||||||||||||
| Weatherized | No | No | No | ||||||||||
| Flying | Yes | Included | Yes | ||||||||||
| Nominal Impedance (Passive) | 16Ω | ||||||||||||
| HF Nominal Impedance | 16Ω | 8Ω | 16Ω | ||||||||||
| HF Transducer | Two 2" ND2R | Two 3-Inch ND6A | 2 x 2-in ND2S | 2 x 2-in ND2S | |||||||||
| Speaker Type | Full-Range, Line-array | Full-Range, Line-array | Full-Range, Line-array | Full-Range, Line-array | Full-Range, two-way, line arrays | Subwoofer | Line Arrays, Subs | Full-Range, Line Arrays | Subwoofer | ||||
| MF Nominal Impedance | 16Ω | ||||||||||||
| MF Transducer | 1 x 8-in DVN2080 | ||||||||||||
| Frequency Response (-3 dB)¹ | 57 Hz - 16 kHz | 52 Hz - 19 kHz | 65 - 16,000Hz | 33 - 200Hz | 45 - 100Hz | 65-16,000Hz | 40 - 400Hz | ||||||
| LF Nominal Impedance | 16Ω | 4Ω | 16Ω | 4Ω | |||||||||
| Max. SPL/1m (calc)² | 128/137dB () | 136dB () | 128/137dB () | 141dB | |||||||||
| Coverage (Nominal -6 dB) H | 90° | 120° | 120° | 90° | 120° | 360° | 200° | 120° | 360° | ||||
| LF Transducer | 12" SMX2121 | 12-Inch DVN3125 | 1 x 8-in DVN2080 | 2 x 18-Inch DVF4180 | 3 x 12-in DVX3120A | 1 x 8-in DVN2080 | 2 x 18-in EVX-180B | ||||||
| Coverage (Nominal -6 dB) V | Array dependent° | 8° () | |||||||||||
| System Power Handling (Continuous/Program/Peak) | 200Watts | 1200Watts | |||||||||||
| LF Power Handling | 400 W continuous, 1600 W peakWatts | 200 W continuous, 800 W peakWatts () | 1000 W continuous, 4000 W peakWatts () | 200 W continuous, 800 W peakWatts () | 1200 W continuous, 4800 W peakWatts () | ||||||||
| HF Power Handling | 120 W continuous, 480 peakWatts | 80 W continuous, 320 W peakWatts () | 80 W continuous, 320 W peakWatts () | ||||||||||
| Crossover Frequency | 100Hz | ||||||||||||
| Connector Type | Dual NL8 type connector | ||||||||||||
| Enclosure Material | EVCoat-coated birch plywood | EVCoat-coated birch plywood | EVCoat®-coated plywood | EVCoat-coated birch plywood | EVCoat®-coated birch plywood | EVCoat®-coated plywood | Plywood, textured epoxy paint | ||||||
| Grille | 16 GA powder coated galvanneal | Powder-coated steel | Powder-coated steel | Powder-coated steel | Powder-coated steel | ||||||||
| Sensitivity 1 W/1 m | 98dB | 101dB | 99/112dB () | 105dB | 100dB () | 99/112dB () | 104dB () | ||||||
| Available Color | Black | Black | Black | Black | |||||||||
| Height | 342.9mm (13.5") | 342.9mm (13.5") | 251mm (9.88") | 88.1mm (3.47") | 88.1mm (3.47") | 88.1mm (3.47") | 88.1mm (3.47") | 1101.34mm (43.36") | 508mm (20") | 251mm (9.88") | 494.3mm (19.46") | ||
| Width | 723.9mm (28.5") | 723.9mm (28.5") | 516mm (20.31") | 483mm (19.02") | 483mm (19.02") | 483mm (19.02") | 483mm (19.02") | 762.00mm (30") | 726mm (28.58") | 726mm (28.58") | 1244.6mm (49") | ||
| Recommended High-Pass Frequency | 50Hz | 40Hz | 33Hz | ||||||||||
| Depth | 536.6mm (21.13") | 536.6mm (21.13") | 369mm (14.53") | 421.5mm (16.59") | 421.5mm (16.59") | 421.5mm (16.59") | 421.5mm (16.59") | 517.14mm (20.36") | 677mm (26.65") | 369mm (14.53") | 740.4mm (29.15") | ||
| Weight Net | 41.73kg (92 lbs) | 42.18kg (92.99 lbs) | 17.24kg (38.01 lbs) | 17.1kg (37.7 lbs) | 12.6kg (27.78 lbs) | 14.8kg (32.63 lbs) | 16.3kg (35.94 lbs) | 88.45kg (195 lbs) | 67.13kg (148 lbs) | 21.8kg (48.06 lbs) | 92kg (202.83 lbs) | ||
| Frequency Response (-3 dB) | 10 Hz - 40 kHz () | 10 Hz - 40 kHz () | 10 Hz - 40 kHz () | 10 Hz - 40 kHz () | |||||||||
| Shipping Weight | 48kg (105.82 lbs) | ||||||||||||
| Slew Rate | 30V/µs | 25V/µs | 26V/µs | 27V/µs | |||||||||
| Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω | 1100Watts | 400Watts | 500Watts | 800Watts | |||||||||
| LF2 Power Handling | 500 W continuous, 2000 W peak () | 200 W continuous, 800 W peak () | |||||||||||
| Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω | 550Watts | 200Watts | 250Watts | 400Watts | |||||||||
| Intermodulation Distortion (SMPTE) | 0.1% | 0.1% | 0.1% | 0.1% | |||||||||
| Electronics Type | Amplifier | Amplifier | Amplifier | Amplifier | |||||||||
| Passive Power Handling | 2000W peak | 2000W peak | 2000W peak () | 2000W peak | 800W peak | 16000W peak | 6000W peak | 800W peak | 4800W peak | ||||
| Peak SPL @ 10m | 129dB () | 121dB () | 129dB () | 132dB () | |||||||||
| DIM 30 | 0.05% | 0.05% | 0.05% | 0.05% | |||||||||
| Continuous Rated Power (1 kHz, THD 1%) 2Ω | 1800Watts | 650Watts | 900Watts | 1250Watts | |||||||||
| Signal-to-Noise Ratio (A-weighted) | 110dB | 106dB | 107dB | 109dB | |||||||||
| Continuous Rated Power (1 kHz, THD 1%) 8Ω | 750Watts | 270Watts | 380Watts | 550Watts | |||||||||
| Input Impedance (Balanced) | 20kΩ | 20kΩ | 20kΩ | 20kΩ | |||||||||
| Input Connections | 2 Neutrik® NL8 | 2 Neutrik® NL8 | 2 Neutrik® NL8 | 2 Neutrik® NL8 | |||||||||
| Environmental Specs | IEC 529 IP24, MIL STD 810 | IEC 529 IP24, MIL STD 810 | |||||||||||
| Continuous Rated Power (1 kHz, THD 1%) 4Ω | 1200Watts | 450Watts | 600Watts | 900Watts | |||||||||
| Input Sensitivity | +6.6 dBu | +2.2 dBu | +3.1 dBu | +5.1 dBu | |||||||||
| Maximum Bridged Output 8Ω | 2400Watts | 900Watts | 1200Watts | 1800Watts | |||||||||
| Network Control (IRIS-Net) | No | No | No | No | |||||||||
| Maximum Bridged Output 4Ω | 3600Watts | 1300Watts | 1800Watts | 2800Watts | |||||||||
| Topology | Class-H | Class-AB | Class-AB | Class-H | |||||||||
| Amplifier Gain | 32dB | 32dB | 32dB | 32dB | |||||||||
| Total Harmonic Distortion | 0.03% | 0.03% | 0.03% | 0.03% | |||||||||
| Impedance | 8Ω () | 2/4/8Ω | 2/4/8Ω | 2/4/8Ω | 2/4/8Ω | ||||||||
| Maximum Input Voltage | +21 dBu () | +21 dBu () | +21 dBu () | +21 dBu () | |||||||||
| Channels | 2 | 2 | 2 | 2 | |||||||||
| Chassis Size | 203.2mm (8") | 304.8 mm | 203.2mm (8") | 457.2mm (18") | |||||||||
| Cooling | Front-to-Rear, 3-stage fans | Front-to-Rear, 3-stage fans | Front-to-Rear, 3-stage fans | Front-to-Rear, 3-stage fans | |||||||||
| Internal Passive Crossover Frequency | 1600Hz | ||||||||||||
| Mains Voltage | 100 V, 120 V, 230 V or 240 V; 50-60 Hz (factory configured) | 100 V, 120 V, 230 V or 240 V; 50-60 Hz (factory configured) | |||||||||||
| Maximum SPL | 143dB | ||||||||||||
| Transducer size | 50 | ||||||||||||
| Configuration | Passive, Bi-amp | ||||||||||||
| LF Axial Sensitivity | 98 | ||||||||||||
| HF Axial Sensitivity | 110 dB (1 W/1 m) | ||||||||||||
| Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More |
