EVOLVE 50

便携式音柱系统

Specifications

Speaker TypeFull-Range
Powered or PassivePowered
Frequency Response (-3 dB)¹43 Hz – 20 k
Frequency Range (-10 dB)¹37 Hz – 20 kHz
Max. SPL/1m (calc)²127
Coverage (Nominal -6 dB) H120

Coverage (Nominal -6 dB) V40
Power Rating1000
LF Power Handling500
HF Power Handling500
Crossover Frequency200
Connector Type2x XLR/TRS combo jack input 1x 3.5 mm Input 1x Stereo RCA input 1x Wireless Bluetooth® audio input 1x XLR THRU output 1x XLR MIX OUT output
Enclosure Materialsub – 15mm plywood, column – poly composite, pole – aluminum
GrilleSteel with powder coat
Available ColorBlack or White
Height2045
Width345
Depth471
Weight Net26.25
Shipping Weight31.3
Power Consumption³100 - 240 V AC, 50 - 60 Hz, 1.5 - 0.6A
FamilyEVOLVE
Transducer sizeColumn array: 8 x 3.5" Neodymium drivers
Subwoofer: 1 x 12” Neodymium drivers
Notes¹Half-space measurement using live DSP preset.
²Maximum SPL is measured at 1 m using broadband pink noise at maximum output.
³Current rating is ⅛ power.
