便携式无源全频扬声器
Now available in black and white.
产品
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 | |
ZLX G2 Powered |
ELX200-10 |
ELX200-12 |
ELX200-15 |
ZLX-12 |
ELX112 |
ELX115 |
ELX215 |
EKX-12 |
EKX-15 |
Sx300PI |
Sx300PIX |
Sx100+ |
Sx300E |
ZX1 |
ZX3 |
ZX4 |
ZX5 |
TX1122 |
TX1152 |
TX2152 |
S-40 |
ZLX-15 | |
| 频响范围（- 10分贝） | 55 - 20000 | 50 - 20000 | 38 - 20000 | 55 Hz - 20 k (Full Space Measurement) | 50 Hz - 20 k (Full Space Measurement) | 50 - 20000 | 50 - 20000 | 60 - 25000 | 50 - 20000 | 48 - 20000 | 48 - 20000 | 42 - 20000 | 39 - 20000 | 45 - 20000 | 45 - 20000 | 50 - 18000 | |||||||
| 悬架 | (3) M10 suspension points | (3) M10 suspension points | (3) M10 suspension points | (8) M10 threaded mounting points | (8) M10 threaded mounting points | (6) 3/8-inch threaded inserts | (6) 3/8-inch threaded inserts | (6) 3/8-inch threaded inserts | |||||||||||||||
| 绝缘材料 | Yes | Yes | No | No | No | Yes | No | Yes | No | ||||||||||||||
| 悬吊安装 | Yes | Yes | Yes | Yes | No | Yes | Yes | Yes | Yes | Yes | Yes | ||||||||||||
| 最小阻抗 | 7.2 | 7.5 | 7.0 | 7 | 7.0 | 7.4 | 3.7 | 7.5 | 7.2 | 5 | 5 | 5.6 | 5 | 6 | 6.2 | 6.5 | 6.5 | 6.4 | 6.2 | 3.1 | 3.7 | 7 | |
| 标称阻抗（无源） | 8 | 8 | 4 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 4 | 4 | |||||||||
| 高频标称阻抗 | 8 | ||||||||||||||||||||||
| 高频传感器 | DH-1L 1-inch titanium compression driver | DH-1L 1-inch titanium compression driver | DH-1L 1-inch titanium compression driver | DH-1K | DH-1K, 39mm (1.5") Titanium Diaphragm Compression Driver | DH-1K, 39mm (1.5") Titanium Diaphragm Compression Driver | DH-1K, 39mm (1.5") Titanium Diaphragm Compression Driver | DH-1M 1-inch titanium compression driver | DH-1M 1-inch titanium compression driver | 1.25-inch DH3/2010A | 1.25-inch DH3/2010A | 1.25-inch DH3/2010A | 1.25-inch DH3/2010A | 1.25-inch DH2005 | 2-inch ND2 | 1.25-inch DH3/2010A | 2-inch ND2 | 1.25-inch DH3/2010A | 1.25-inch DH3/2010A | 2-inch ND2 | 1-inch softdome | DH-1K | |
| 扬声器类型 | Full-Range | Full-Range | Full-Range | Full-Range | Full-Range | Full-Range, two-way, wedges | Full-Range, mid-high, two-way | Full-Range, mid-high, two-way | Full-Range, two-way | Full-Range, two way | Full-Range, Two-Way | Full-Range, Mid-High, Two-Way | Full-Range, Mid-High, Two-Way | Full-Range, Mid-High, Two-Way | Full-Range, Mid-High, Two-Way, Wedges | Full-Range | Full-Range, Mid-High, Two-Way, Wedges | Full-Range, Mid-High, Two-Way, Wedges | Full-Range | Full-Range | Full-Range | Monitor | Full-Range, two-way |
| 低音尺寸 | 8 12 15 | 10 | 12 | 15 | 12 | 12 | 15 | 15 | 12 | 15 | 12 | 12 | 12 | 12 | 8 | 12 | 15 | 15 | 12 | 15 | 15 | 5.25 | 15 |
| 有源或无源 | Powered | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive | Passive |
| Frequency Response (-3 dB)¹ | 65 Hz - 20 k | 77 Hz - 17 k | 77 Hz - 16 k | 82 - 18000 | 75 - 18000 | 62 - 18000 | 82 Hz - 18 k () | 75 Hz - 18 k () | 60 - 20000 | 58 - 15000 | 60 - 20000 | 58 - 18000 | 70 - 20000 | 65 - 20000 | 55 - 13000 | ||||||||
| Frequency Range (-10 dB)¹ | 49 Hz - 22 kHz | 51 Hz - 20 kHz | 52 Hz - 19 kHz | 55 Hz - 20 kHz | 44 Hz - 20 kHz | ||||||||||||||||||
| 低频标称阻抗 | 8 | ||||||||||||||||||||||
| Max. SPL/1m (calc)² | 127 | 128 | 130 | 125 | 132 () | 134 () | 137 | 131 | 132 | 131/123 () | 131/123 () | 127 | 131/123 () | 123 | 131 | 132 | 132 | 132 | 133 | 139 | 113 | 126 | |
| 覆盖率（标称- 6分贝）H | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 65 () | 65 () | 65 () | 65 () | 90 () | 90/60 | 90 | 90/60 | 90 | 60 | 60 | 100 | 90 | |
| 低频传感器 | EVS-10M 254 mm (10 in) | EVS-12M 300 (12 in) | EVS-15M 381 mm (15 in) | EVS-12K, 300 mm (12 in) Woofer | (1) EVS-12K, 305mm (12") Woofer | (1) EVS-15K, 381mm (15") Woofer | (2) EVS-15K, 381mm (15") Woofers | EVS-12M 300 mm (12 in) | EVS-15M 381 mm (15 in) | 12-inch DL12BFH | 12-inch DL12BFH | 12-inch | 12-inch DL12BFH | 8-inch EV8L | 12-inch DVX3121A | 15-inch EVS15-SF | 15-inch DVX3150A | 12-inch SMX2121 | 15-inch SMX2151 | Two 15-inch SMX2151 | 5.25-inch | EVS-15L, 380 mm (15 in) Woofer | |
| 覆盖率（标称- 6分贝）V | 60 | 60 | 60 | 60 | 50 | 50 | 50 | 60 | 65 () | 65 () | 65 () | 65 () | 50 () | 50/60 | 50 | 50/60 | 50 | 40 | 40 | 100 | 60 | ||
| 系统功率处理（连续/曲目/峰值） | 250//1000 | 400//1600 | 600//2400 | 300//1200 | 300//1200 () | 200//800 () | 300/1200 () | 200//800 | 600//2400 | 400//1600 | 600//2400 | 500//2000 | 500//2000 | 1000//4000 | 120/480 () | ||||||||
| 额定功率 | 1200 | 1200 | 1200 | 1000 | 1400 | 1600 | 300 | 300 | 800 | 800 | 2400 | 1600 | 2400 | 2000 | 2000 | 4000 | 120 | 1000 | |||||
| 低频功率 | 500 | 500 | |||||||||||||||||||||
| 旋转角 | Yes | No | Yes | Yes | |||||||||||||||||||
| 高频功率 | 40 | 40 | |||||||||||||||||||||
| 分频频率 | 2 k | 1.7 k | 1.6 k | 2100 | 21000 | 17000 | 1.7 k | 1.6 k | 1.6 k | 1500 | 1500 | 1500 | 1500 | 1700 | 2000 | 1500 | 1500 | 1600 | 1750 | 1750 | 3500 | 1700 | |
| 连接器型号 | Dual NL4 | Dual NL4 | Dual NL4 | Dual NL4 | Parallel Neutrik® NL4 | Parallel Neutrik® NL4 | Parallel Neutrik® NL4 | Dual NL4 | Dual NL4 | Dual NL4 | |||||||||||||
| 最大声压级 (1% THD) | 0 | ||||||||||||||||||||||
| 外壳材料 | Composite | Polypropylene Composite | Polypropylene composite | Polypropylene composite | Polypropylene Composite | 9-ply plywood | 9-ply plywood | 9-ply plywood | 15 mm, plywood with EVCoat | 15 mm, plywood with EVCoat | Polypropylene Composite | Polypropylene Composite | Copolymer Composite | Copolymer Composite | High Impact Polystyrene Composite | High Impact Polystyrene Composite | High Impact Polystyrene Composite | High Impact Polystyrene Composite | Ply Wood and MDF with EVCOAT | Plywood and MDF with EVCOAT | Plywood and MDF with EVCOAT | High Impact Polystyrene Composite | Polypropylene Composite |
| Grille | 18 AWG steel with powdercoat | 18 AWG steel with powdercoat | 18 AWG steel with powdercoat | 18 Gauge Steel with Black Powder Coat | 18GA Steel with Black Powdercoat | 18GA Steel with Black Powdercoat | 18GA Steel with Black Powdercoat | 18 AWG steel with powdercoat | 18 AWG steel with powdercoat | Polyester Powder Coated, 18GA Galvanized Steel | Polyester Powder Coated, 18GA Galvanized Steel | Polyester Powder Coated, 18GA Galvanized Steel | Polyester Powder Coated, 18GA Galvanized Steel | 18 Gauge Steel with Black Powder Coat | |||||||||
| 灵敏度1 W/1 m | 99 | 99 | 98 | 99 | 94 | 97 | 100 | 98 | 97 () | 100 | 103 | 85 | |||||||||||
| 可选颜色 | 黑色白色 | 黑色白色 | 黑色白色 | 黑色 | 黑色 | 黑色 | Black or white | Black or white | Black or white | Black or white | 黑色 | Black or white | 黑色 | Black or white | 黑色 | 黑色 | 黑色 | ||||||
| 高度 | 531 | 629 | 710 | 610 | 607 | 708 | 1154 | 607 | 685 | 586 | 586 | 586 | 586 | 457 | 613 | 686 | 692 | 440 | 475 | 1154 | 249 | 685 | |
| 宽度 | 330 | 363 | 423 | 356 | 362 | 432 | 432 | 375 | 432 | 429 | 429 | 429 | 429 | 282 | 397 | 445 | 446 | 364 | 439 | 508 | 178 | 423 | |
| 推荐高通频率 | 55 | 50 | 42 | 40 | 45 | 40 | 35 | 55 | 50 | 40 | 50 | 42 | 36 | 45 | 40 | 40 | 40 | ||||||
| 深度 | 319 | 344 | 384 | 356 | 340 | 382 | 501 | 356 | 429 | 312 | 312 | 312 | 312 | 264 | 362 | 406 | 411 | 573 | 655 | 471 | 150 | 383 | |
| 内置分频频率 | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Switchable biamp or passive crossover | Yes | Yes | Yes | |||||||||
| 净重 | 13.4 | 15.2 | 18.7 | 14.9 | 16 | 21.9 | 40.7 | 17.4 | 23.2 | 17.7 | 17.7 | 14.5 | 17.7 | 8.4 | 19.8 | 20.2 | 22.2 | 19.8 | 27.6 | 42.8 | 2.6 | 16.6 | |
| 响应频率 (-3 dB) | 82 Hz - 18 kHz | 85 - 20000 () | 56 Hz - 18 kHz | ||||||||||||||||||||
| 装船重量 | 15.3 | 17.1 | 21.4 | 18 | 52.0 | 21.4 | 28.2 | 22 | |||||||||||||||
| 家族 | ZLX | ELX200 | ELX200 | ELX200 | ZLX | ELX | ELX | ELX | EKX | EKX | Sx | Sx | Sx | Sx | ZxZxA | ZxZxA | ZxZxA | ZxZxA | Tour X | Tour X | Tour X | ZLX | |
| 功率（连续/峰值） | 300 W/1200 | 300W/1200 | 300W/1200 | 250 / 1000 | 350 W/1400 | 400 W/1600 | 250 / 1000 | ||||||||||||||||
| 标称阻抗 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | |||||||||||||||
| 变压器 | Yes | ||||||||||||||||||||||
| 无源功率 | 1000 | 1400 | 1600 | 30 | 1000 | ||||||||||||||||||
| 最大声压级 | 125 | 131 () | 132 () | 126 | |||||||||||||||||||
| 轴向灵敏度(SPL, 1 W @ 1 m) | 90 | 93 | 95 | 95 | 94 | 95 | 96 | 95 | 96 () | 99 | 99 | 98 | 99 | 96 | |||||||||
| 底盘尺寸 | 304.8 | 304.8 | 304.8 | 304.8 | 203.2 | 381 | 381 | 133.35 | |||||||||||||||
| 覆盖率（标称- 6分贝） | Omnidirectional | ||||||||||||||||||||||
| 输入连接 | 2 four-pin Speakon | 2 four-pin Speakon | Parallel Neutrik® NL4 | 2 four-pin Speakon | Parallel Neutrik® NL4 | 2 conductor SJO cable and gland nut | Parallel Neutrik® NL4 | Parallel Neutrik® NL4 | Parallel Neutrik® NL4 | Parallel Neutrik® NL4 | Parallel Neutrik® NL4 | Spring Terminal | |||||||||||
| 指向性指数 | 11.1 () | 11.1 () | 11.1 () | 11.1 () | 9.8 () | ||||||||||||||||||
| 箱体材料 | 9-ply, 15mm Plywood, Internally Braced, with Textured Paint | 9-ply, 15mm Plywood, Internally Braced, with Textured Paint | 9-ply, 15mm Plywood, Internally Braced, with Textured Paint | ||||||||||||||||||||
| 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 | 更多 |
Show more specs
