Portable Passive Full-Range

Models

ZLX G2 Powered
Powered loudspeaker

ELX200-10
10" passive loudspeaker

ELX200-12
12" passive loudspeaker

ELX200-15
15" passive loudspeaker

ZLX-12
12" passive loudspeaker

ELX112
12" passive loudspeaker

ELX115
15" passive loudspeaker

ELX215
Dual 15" 2‑way passive full‑range loudspeaker

EKX-12
12" passive loudspeaker

EKX-15
15" passive loudspeaker

Sx300PI
Weather‑resistant 12" 2‑way passive full‑range loudspeaker

Sx300PIX
Weather‑resistant 12" 2‑way passive full‑range loudspeaker

Sx100+
12" passive loudspeaker

Sx300E
12" passive loudspeaker

ZX1
8" 2‑way passive full‑range composite loudspeaker

ZX3
12" passive loudspeaker

ZX4
15" passive loudspeaker

ZX5
15" passive loudspeaker available in PI weatherized

TX1122
12" passive loudspeaker

TX1152
15" passive loudspeaker

TX2152
Dual 15" 2‑way passive full‑range loudspeaker

S-40
Ultracompact 5.25" 2‑way passive full‑range loudspeaker

ZLX-15
15" passive loudspeaker


	ZLX G2 Powered Powered loudspeaker	ELX200-10 10" passive loudspeaker	ELX200-12 12" passive loudspeaker	ELX200-15 15" passive loudspeaker	ZLX-12 12" passive loudspeaker	ELX112 12" passive loudspeaker	ELX115 15" passive loudspeaker	ELX215 Dual 15" 2‑way passive full‑range loudspeaker	EKX-12 12" passive loudspeaker	EKX-15 15" passive loudspeaker	Sx300PI Weather‑resistant 12" 2‑way passive full‑range loudspeaker	Sx300PIX Weather‑resistant 12" 2‑way passive full‑range loudspeaker	Sx100+ 12" passive loudspeaker	Sx300E 12" passive loudspeaker	ZX1 8" 2‑way passive full‑range composite loudspeaker	ZX3 12" passive loudspeaker	ZX4 15" passive loudspeaker	ZX5 15" passive loudspeaker available in PI weatherized	TX1122 12" passive loudspeaker	TX1152 15" passive loudspeaker	TX2152 Dual 15" 2‑way passive full‑range loudspeaker	S-40 Ultracompact 5.25" 2‑way passive full‑range loudspeaker	ZLX-15 15" passive loudspeaker
Frequency Range (-10 dB)						55 - 20000kHz	50 - 20000kHz	38 - 20000kHz	55 Hz - 20 kkHz (Full Space Measurement)	50 Hz - 20 kkHz (Full Space Measurement)	50 - 20000kHz	50 - 20000kHz	60 - 25000kHz	50 - 20000kHz	48 - 20000kHz	48 - 20000kHz	42 - 20000kHz	39 - 20000kHz	45 - 20000kHz	45 - 20000kHz	50 - 18000kHz
Suspension		(3) M10 suspension points	(3) M10 suspension points	(3) M10 suspension points					(8) M10 threaded mounting points	(8) M10 threaded mounting points									(6) 3/8-inch threaded inserts	(6) 3/8-inch threaded inserts	(6) 3/8-inch threaded inserts
Weatherized											Yes	Yes	No	No	No	Yes	No	Yes				No
Flying											Yes	Yes	Yes	Yes	No	Yes	Yes	Yes	Yes	Yes	Yes
Minimum Impedance		7.2Ω	7.5Ω	7.0Ω	7Ω	7.0Ω	7.4Ω	3.7Ω	7.5Ω	7.2Ω	5Ω	5Ω	5.6Ω	5Ω	6Ω	6.2Ω	6.5Ω	6.5Ω	6.4Ω	6.2Ω	3.1Ω	3.7Ω	7Ω
Nominal Impedance (Passive)						8Ω	8Ω	4Ω			8Ω	8Ω	8Ω	8Ω	8Ω		8Ω	8Ω	8Ω	8Ω	4Ω	4Ω
HF Nominal Impedance																		8Ω
HF Transducer		DH-1L 1-inch titanium compression driver	DH-1L 1-inch titanium compression driver	DH-1L 1-inch titanium compression driver	DH-1K	DH-1K, 39mm (1.5") Titanium Diaphragm Compression Driver	DH-1K, 39mm (1.5") Titanium Diaphragm Compression Driver	DH-1K, 39mm (1.5") Titanium Diaphragm Compression Driver	DH-1M 1-inch titanium compression driver	DH-1M 1-inch titanium compression driver	1.25-inch DH3/2010A	1.25-inch DH3/2010A	1.25-inch DH3/2010A	1.25-inch DH3/2010A	1.25-inch DH2005	2-inch ND2	1.25-inch DH3/2010A	2-inch ND2	1.25-inch DH3/2010A	1.25-inch DH3/2010A	2-inch ND2	1-inch softdome	DH-1K
Speaker Type	Full-Range	Full-Range	Full-Range	Full-Range	Full-Range	Full-Range, two-way, wedges	Full-Range, mid-high, two-way	Full-Range, mid-high, two-way	Full-Range, two-way	Full-Range, two way	Full-Range, Two-Way	Full-Range, Mid-High, Two-Way	Full-Range, Mid-High, Two-Way	Full-Range, Mid-High, Two-Way	Full-Range, Mid-High, Two-Way, Wedges	Full-Range	Full-Range, Mid-High, Two-Way, Wedges	Full-Range, Mid-High, Two-Way, Wedges	Full-Range	Full-Range	Full-Range	Monitor	Full-Range, two-way
Woofer Size	8 12 15inch	10inch	12inch	15inch	12inch	12inch	15inch	15inch	12inch	15inch	12inch	12inch	12inch	12inch	8inch	12inch	15inch	15inch	12inch	15inch	15inch	5.25inch	15inch
Powered or Passive	Powered	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive	Passive
Frequency Response (-3 dB)¹		65 Hz - 20 kHz	77 Hz - 17 kHz	77 Hz - 16 kHz		82 - 18000Hz	75 - 18000Hz	62 - 18000Hz	82 Hz - 18 kHz ()	75 Hz - 18 kHz ()					60 - 20000Hz	58 - 15000Hz	60 - 20000Hz	58 - 18000Hz	70 - 20000Hz	65 - 20000Hz	55 - 13000Hz
Frequency Range (-10 dB)¹		49 Hz - 22 kHz	51 Hz - 20 kHz	52 Hz - 19 kHz	55 Hz - 20 kHz																		44 Hz - 20 kHz
LF Nominal Impedance																		8Ω
Max. SPL/1m (calc)²		127dB	128dB	130dB	125dB	132dB ()	134dB ()	137dB	131dB	132dB	131/123dB ()	131/123dB ()	127dB	131/123dB ()	123dB	131dB	132dB	132dB	132dB	133dB	139dB	113dB	126dB
Coverage (Nominal -6 dB) H		90°	90°	90°	90°	90°	90°	90°	90°	90°	65° ()	65° ()	65° ()	65° ()	90° ()	90/60°	90°	90/60°	90°	60°	60°	100°	90°
LF Transducer		EVS-10M 254 mm (10 in)	EVS-12M 300 (12 in)	EVS-15M 381 mm (15 in)	EVS-12K, 300 mm (12 in) Woofer	(1) EVS-12K, 305mm (12") Woofer	(1) EVS-15K, 381mm (15") Woofer	(2) EVS-15K, 381mm (15") Woofers	EVS-12M 300 mm (12 in)	EVS-15M 381 mm (15 in)	12-inch DL12BFH	12-inch DL12BFH	12-inch	12-inch DL12BFH	8-inch EV8L	12-inch DVX3121A	15-inch EVS15-SF	15-inch DVX3150A	12-inch SMX2121	15-inch SMX2151	Two 15-inch SMX2151	5.25-inch	EVS-15L, 380 mm (15 in) Woofer
Coverage (Nominal -6 dB) V		60°	60°	60°	60°	50°	50°	50°		60°	65° ()	65° ()	65° ()	65° ()	50° ()	50/60°	50°	50/60°	50°	40°	40°	100°	60°
Power Rating		1200W	1200W	1200W	1000W				1400W	1600W	300W	300W	800W		800W	2400W	1600W	2400W	2000W	2000W	4000W	120W	1000W
System Power Handling (Continuous/Program/Peak)						250//1000Watts	400//1600Watts	600//2400Watts			300//1200Watts	300//1200Watts ()	200//800Watts ()	300/1200Watts ()	200//800Watts	600//2400Watts	400//1600Watts	600//2400Watts	500//2000Watts	500//2000Watts	1000//4000Watts	120/480Watts ()
Rotatable Horn															Yes				No	Yes	Yes
LF Power Handling																500Watts		500Watts
HF Power Handling																40Watts		40Watts
Crossover Frequency		2 kHz	1.7 kHz	1.6 kHz	2100Hz	21000Hz	17000Hz	1.7 kHz	1.6 kHz	1.6 kHz	1500Hz	1500Hz	1500Hz	1500Hz	1700Hz	2000Hz	1500Hz	1500Hz	1600Hz	1750Hz	1750Hz	3500Hz	1700Hz
Connector Type		Dual NL4	Dual NL4	Dual NL4	Dual NL4	Parallel Neutrik® NL4	Parallel Neutrik® NL4	Parallel Neutrik® NL4	Dual NL4	Dual NL4													Dual NL4
Maximum SPL (1% THD)																							0dB
Enclosure Material	Composite	Polypropylene Composite	Polypropylene composite	Polypropylene composite	Polypropylene Composite	9-ply plywood	9-ply plywood	9-ply plywood	15 mm, plywood with EVCoat	15 mm, plywood with EVCoat	Polypropylene Composite	Polypropylene Composite	Copolymer Composite	Copolymer Composite	High Impact Polystyrene Composite	High Impact Polystyrene Composite	High Impact Polystyrene Composite	High Impact Polystyrene Composite	Ply Wood and MDF with EVCOAT	Plywood and MDF with EVCOAT	Plywood and MDF with EVCOAT	High Impact Polystyrene Composite	Polypropylene Composite
Grille		18 AWG steel with powdercoat	18 AWG steel with powdercoat	18 AWG steel with powdercoat	18 Gauge Steel with Black Powder Coat	18GA Steel with Black Powdercoat	18GA Steel with Black Powdercoat	18GA Steel with Black Powdercoat	18 AWG steel with powdercoat	18 AWG steel with powdercoat					Polyester Powder Coated, 18GA Galvanized Steel	Polyester Powder Coated, 18GA Galvanized Steel	Polyester Powder Coated, 18GA Galvanized Steel	Polyester Powder Coated, 18GA Galvanized Steel					18 Gauge Steel with Black Powder Coat
Available Color		Black or White	Black or White	Black or White		Black	Black	Black			Black or white	Black or white	Black or white	Black or white	Black	Black or white	Black	Black or white	Black	Black	Black
Sensitivity 1 W/1 m											99dB	99dB	98dB	99dB	94dB	97dB	100dB	98dB	97dB ()	100dB	103dB	85dB
Height		20.91" (531mm)	24.76" (629mm)	27.95" (710mm)	24.02" (610mm)	23.9" (607mm)	27.87" (708mm)	45.43" (1154mm)	23.9" (607mm)	26.97" (685mm)	23.07" (586mm)	23.07" (586mm)	23.07" (586mm)	23.07" (586mm)	17.99" (457mm)	24.13" (613mm)	27.01" (686mm)	27.24" (692mm)	17.32" (440mm)	18.7" (475mm)	45.43" (1154mm)	9.8" (249mm)	26.97" (685mm)
Width		12.99" (330mm)	14.29" (363mm)	16.65" (423mm)	14.02" (356mm)	14.25" (362mm)	17.01" (432mm)	17.01" (432mm)	14.76" (375mm)	17.01" (432mm)	16.89" (429mm)	16.89" (429mm)	16.89" (429mm)	16.89" (429mm)	11.1" (282mm)	15.63" (397mm)	17.52" (445mm)	17.56" (446mm)	14.33" (364mm)	17.28" (439mm)	20" (508mm)	7.01" (178mm)	16.65" (423mm)
Recommended High-Pass Frequency		55Hz	50 Hz	42Hz	40Hz	45Hz	40Hz	35Hz	55Hz	50Hz					40Hz	50Hz	42Hz	36Hz	45Hz	40Hz	40Hz		40Hz
Internal Crossover						Yes	Yes	Yes			Yes	Yes	Yes	Yes	Yes	Yes	Yes	Switchable biamp or passive crossover	Yes	Yes	Yes
Depth		12.56" (319mm)	13.54" (344mm)	15.12" (384mm)	14.02" (356mm)	13.39" (340mm)	15.04" (382mm)	19.72" (501mm)	14.02" (356mm)	16.89" (429mm)	12.28" (312mm)	12.28" (312mm)	12.28" (312mm)	12.28" (312mm)	10.39" (264mm)	14.25" (362mm)	15.98" (406mm)	16.18" (411mm)	22.56" (573mm)	25.79" (655mm)	18.54" (471mm)	5.91" (150mm)	15.08" (383mm)
Weight Net		29.54lbs (13.4kg)	33.51lbs (15.2kg)	41.23lbs (18.7kg)	32.85lbs (14.9kg)	35.27lbs (16kg)	48.28lbs (21.9kg)	89.73lbs (40.7kg)	38.36lbs (17.4kg)	51.15lbs (23.2kg)	39.02lbs (17.7kg)	39.02lbs (17.7kg)	31.97lbs (14.5kg)	39.02lbs (17.7kg)	18.52lbs (8.4kg)	43.65lbs (19.8kg)	44.53lbs (20.2kg)	48.94lbs (22.2kg)	43.65lbs (19.8kg)	60.85lbs (27.6kg)	94.36lbs (42.8kg)	5.73lbs (2.6kg)	36.6lbs (16.6kg)
Frequency Response (-3 dB)					82 Hz - 18 kHz																	85 - 20000 ()	56 Hz - 18 kHz
Shipping Weight		33.73lbs (15.3kg)	37.7lbs (17.1kg)	47.18lbs (21.4kg)	39.68lbs (18kg)			114.64lbs (52.0kg)	47.18lbs (21.4kg)	62.17lbs (28.2kg)													48.5lbs (22kg)
Family	ZLX	ELX200	ELX200	ELX200	ZLX	ELX	ELX	ELX	EKX	EKX	Sx	Sx	Sx	Sx	ZxZxA	ZxZxA	ZxZxA	ZxZxA	Tour X	Tour X	Tour X		ZLX
Nominal Impedance		8Ω	8Ω	8Ω	8Ω				8Ω	8Ω						8Ω							8Ω
Chassis Size											12" (304.8mm)	12" (304.8mm)	304.8 mm	304.8 mm	203.2 mm		381 mm	381 mm				5.25" (133.35mm)
Input Connections											2 four-pin Speakon	2 four-pin Speakon	Parallel Neutrik® NL4	2 four-pin Speakon	Parallel Neutrik® NL4	2 conductor SJO cable and gland nut	Parallel Neutrik® NL4	Parallel Neutrik® NL4	Parallel Neutrik® NL4	Parallel Neutrik® NL4	Parallel Neutrik® NL4	Spring Terminal
Power Handling (Continuous / Peak)		300 W/1200W	300W/1200W	300W/1200W	250 / 1000W				350 W/1400W	400 W/1600W													250 / 1000W
Axial Sensitivity (SPL, 1 W @ 1 m)		90dB	93dB	95dB	95dB	94dB	95dB	96dB	95dB	96dB ()	99dB	99dB	98dB	99dB									96dB
Directivity Index											11.1dB ()	11.1dB ()	11.1dB ()	11.1dB ()								9.8dB ()
Maximum SPL					125dB				131dB ()	132dB ()													126dB
Passive Power Handling					1000W peak				1400W peak	1600W peak												30W peak	1000W peak
Coverage (Nominal -6 dB)								Omnidirectional
Case Material						9-ply, 15mm Plywood, Internally Braced, with Textured Paint	9-ply, 15mm Plywood, Internally Braced, with Textured Paint	9-ply, 15mm Plywood, Internally Braced, with Textured Paint
Transformer												Yes
	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More	Learn More

Show more specs

Downloads

Technical Documentations

Certification/Regulatory

Name	Language & Download
EKX Passive UKCA Declaration of Conformity (2022-May)	EN
Ekx Passives Series, EC Declaration of Conformity	EN
ELX Passive Speakers EU Declaration of Conformity (2023-Sep)	EN
ELX Passive Speakers UKCA Declaration of Conformity (2023-Sep)	EN
ELX200 Passive EU Declaration of Conformity (2023-Sep)	EN
ELX200 Passive UKCA Declaration of Conformity (2023-Sep)	EN
Portable Passive Loudspeaker Family EC Declaration of Conformity	EN
Powered loudspeakers Safety and security information	EN
TOUR-X EU Declaration of Conformity (2023-Sep)	EN
TOUR-X UKCA Declaration of Conformity (2023-Sep)	EN
ZLX G2 Powered Safety and security information	EN
ZLX PASSIVE EU Declaration of Conformity (2023-Feb)	EN
ZLX PASSIVE UKCA Declaration of Conformity (2023-Feb)	EN
ZLX-12P-G2-EU, Cambodia-TRC, RF / Bluetooth Cert (2023)	EN
ZLX-12P-G2-EU, China-SRRC, Equipment Type Approval (2024)	EN
ZLX-12P-G2-EU, Japan-MIC, RF, Equipment Type Approval (2024)	EN
ZLX-12P-G2-EU, Kuwait-KSMD, Cert of Conformity (2024)	EN
ZLX-12P-G2-EU, Malaysia-SIRIM, RF / Bluetooth Cert (2024)	EN
ZLX-12P-G2-EU, Pakistan-PTA, RF / Bluetooth Cert (2024)	EN
ZLX-12P-G2-EU, Singapore-IMDA, RF / Bluetooth Cert (2023)	EN
ZLX-12P-G2-EU, Thailand-NBTC, RF / Bluetooth Cert (2023)	EN
ZLX-15P-G2-EU, Cambodia-TRC, RF / Bluetooth Cert (2023)	EN
ZLX-15P-G2-EU, China-SRRC, Equipment Type Approval (2024)	EN
ZLX-15P-G2-EU, Japan-MIC, RF, Equipment Type Approval (2024)	EN
ZLX-15P-G2-EU, Kuwait-KSMD, Cert of Conformity (2024)	EN
ZLX-15P-G2-EU, Malaysia-SIRIM, RF / Bluetooth Cert (2024)	EN
ZLX-15P-G2-EU, Pakistan-PTA, RF / Bluetooth Cert (2024)	EN
ZLX-15P-G2-EU, Singapore-IMDA, RF / Bluetooth Cert (2023)	EN
ZLX-15P-G2-EU, Thailand-NBTC, RF / Bluetooth Cert (2023)	EN
ZLX-8P-G2-EU, Cambodia-TRC, RF / Bluetooth Cert (2023)	EN
ZLX-8P-G2-EU, China-SRRC, Equipment Type Approval (2024)	EN
ZLX-8P-G2-EU, Japan-MIC, RF, Equipment Type Approval (2024)	EN
ZLX-8P-G2-EU, Kuwait-KSMD, Cert of Conformity (2024)	EN
ZLX-8P-G2-EU, Malaysia-SIRIM, RF / Bluetooth Cert (2024)	EN
ZLX-8P-G2-EU, Pakistan-PTA, RF / Bluetooth Cert (2024)	EN
ZLX-8P-G2-EU, Singapore-IMDA, RF / Bluetooth Cert (2023)	EN
ZLX-8P-G2-EU, Thailand-NBTC, RF / Bluetooth Cert (2023)	EN
ZLX-BT, ZLX-G2, CB-Safety Cert (2023)	EN
ZLX-G2 POWERED EU Declaration of Conformity (2023-Nov)	EN
ZLX-G2 POWERED UKCA Declaration of Conformity (2023-Nov)	EN
ZLX-G2, Angola-INACOM, RF / Bluetooth Cert (2024)	EN
ZLX-G2, Bluetooth Listing (2024)	EN
ZLX-G2, Brazil-ANATEL, RF / Bluetooth Cert (2024)	EN
ZLX-G2, Brazil-ANATEL, RF Equipment Authorization (2024)	EN
ZLX-G2, Canada-IC, RF / Bluetooth Cert (2024)	EN
ZLX-G2, Columbia-CRC, Equipment Type Approval (2024)	EN
ZLX-G2, Costa Rica-SUTEL, CERT / Bluetooth Cert (2024)	EN
ZLX-G2, Ecuador-ARCOTEL, RF / Bluetooth Cert (2024)	EN
ZLX-G2, FCC, RF, DSS Grant (2023)	EN
ZLX-G2, FCC, RF, DTS Grant (2023)	EN
ZLX-G2, India-BIS, RF, Registration / License (2024)	EN
ZLX-G2, India-MCDT, RF, Equipment Type Approval (2024)	EN
ZLX-G2, Iraq-CMC, RF, Equipment Type Approval (2024)	EN
ZLX-G2, Kuwait-CITRA, RF, Equipment Type Approval (2024)	EN
ZLX-G2, Mexico-IFT, RF / Bluetooth Cert (2024)	EN
ZLX-G2, Mexico-NOM, Safety Cert (2024)	EN
ZLX-G2, Oman-TRA, RF, Equipment Type Approval (2023)	EN
ZLX-G2, Panama-PNAF, RF / Bluetooth Cert (2024)	EN
ZLX-G2, Paraguay-CONATEL, RF / Bluetooth Cert (2024)	EN
ZLX-G2, Peru-MTC, RF, Equipment Type Approval (2024)	EN
ZLX-G2, Philippines-NTC, RF, Equipment Type Approval (2024)	EN
ZLX-G2, Qatar-CRA, RF / Bluetooth Cert (2023)	EN
ZLX-G2, Serbia-KVALITET, RF / Bluetooth Cert (2023)	EN
ZLX-G2, South Africa-NRCS, Equipment LOA (2024)	EN
ZLX-G2, South Korea-KCC, RF, Equipment Type Approval (2024)	EN
ZLX-G2, Trinidad-Tobago-TATT, RF / Bluetooth Cert (2024)	EN
ZLX-G2, UAE-TDRA, RF / Bluetooth Cert, UAE (2023)	EN
ZLX-G2, Uruguay-URSEC, RF / Bluetooth Cert (2024)	EN
ZLX, ZLX-G2, CSA / UL, Safety Cert (2023)	EN
ZX1-ZX1i Passive Speakers EU Declaration of Conformity (2023-Sep)	EN
ZX1-ZX1i Passive Speakers UKCA Declaration of Conformity (2023-Sep)	EN
ZX3 Passive Speakers EU Declaration of Conformity (2023-Sep)	EN
ZX3 Passive Speakers UKCA Declaration of Conformity (2023-Sep)	EN
ZX4-ZX5 Passive Speakers EU Declaration of Conformity (2023-Sep)	EN
ZX4-ZX5 Passive Speakers UKCA Declaration of Conformity (2023-Sep)	EN
Zx5-60Piw, Sx300Piw, Xlci127Dvx, Evid 6.2T, Evf-1122Spiw, Iec 60529 Dust & Water Intrusion Certificate No. 40471-2-4 Certificate	EN

Engineering Data Sheet

Name	Language & Download
EKX-12 Engineering Data Sheet	EN
EKX-15 Engineering Data Sheet	EN
ELX200-10 Engineering Data Sheet	EN DE ES FR JA KO PT ZH
ELX200-12 Engineering Data Sheet	EN DE ES FR JA KO PT ZH
ELX200-15 Engineering Data Sheet	EN DE ES FR JA KO PT ZH
Live X Passive Engineering Data Sheet	EN
S-40 Engineering Data Sheet	EN
S-40T Engineering Data Sheet	EN
SB122 PI Engineering Data Sheet	EN
Sx100+ Engineering Data Sheet	EN
SX300PI/PIX Engineering Data Sheet	EN
TX1122 Engineering Data Sheet	EN
TX1152 Engineering Data Sheet	EN
TX2152 Engineering Data Sheet	EN
ZLX-12 & ZLX-15 Engineering Data Sheet	EN
ZLX-12P-G2 Engineering Data Sheet	EN DE ES FR JA KO PT ZH
ZLX-15P-G2 Engineering Data Sheet	EN DE ES FR JA KO PT ZH
ZLX-8P-G2 Engineering Data Sheet	EN DE ES FR JA KO PT ZH
ZX1-100 Engineering Data Sheet	EN
ZX1-90 Engineering Data Sheet	EN
ZX3-60 Engineering Data Sheet	EN
ZX3-60PI Engineering Data Sheet	EN
ZX3-90 Engineering Data Sheet	EN
ZX3-90PI Engineering Data Sheet	EN
ZX4 Engineering Data Sheet	EN
ZX5-60 Engineering Data Sheet	EN
ZX5-60PI Engineering Data Sheet	EN
ZX5-90 Engineering Data Sheet	EN
ZX5-90PI Engineering Data Sheet	EN

Manual

Name	Language & Download
CB5 Installation Instructions	EN
EKX Passive Loudspeakers User Manual	EN DE ES FR JA KO PT ZH
ELX200 Full-Range Loudspeaker Accessories Installation Note	EN
ELX200 Passive Loudspeakers Installation Manual	EN DE ES FR JA KO PT ZH
HA-3 Installation Instructions	EN
HA-5 Installation Instructions	EN
Live X Passive Loudspeaker Owners' Manual	EN
MB3 Installation Instructions	EN
MB5 Installation Instructions	EN
RK-Z Installation Instructions	EN
S-40MB Mounting Instructions	EN
S-40T Service Data	EN
SX, Sb-Series Rigging Manual	EN
Sx300 Manual	EN
System 2000 Accessories	EN
Tour-X Series User & Installation Manual	EN
ZLX G2 Powered Quick User Guide	EN DE ES FR JA KO PT ZH
ZLX User Manual	EN
ZLX Wall Mount Bracket Installation Guide	EN
ZLX-G2 User manual	EN DE ES FR JA KO PT ZH
ZLX Series Manual	DE ES JA KO PT ZH

Service Policies

Name	Language & Download
Warranty conditions for Electro-Voice products in North America	EN

White Paper

Name	Language & Download
Audio 101 - Basic Audio Terminology	EN
Audio 101 - Loudspeaker Basics	EN
EASE Data Explanation	EN
PA Bible 02: Power Handling Capacity	EN
PA Bible 06: The Constant Directivity White Horn White Paper	EN
PA Bible 11: Portable Sound Systems for the Small Club	EN
The EV PA Bible	EN
The PA Bible Chapter Zero	EN

Software, Firmware & Design Tools

Drawing

Name	Language & Download
EKX Simplified Cabinet CAD Drawing	Download
EKX-12 EKX-12P CAD Drawing	Download
EKX-15 EKX-15P CAD Drawing	Download
ELX200-10 CAD	Download
ELX200-12 CAD	Download
ELX200-15 CAD	Download
Sx300 CAD Drawing	Download
ZLX-12 CAD	Download
ZLX-12P-G2 CAD	Download
ZLX-15 CAD	Download
ZLX-15P-G2 CAD	Download
ZLX-8P-G2 CAD	Download
ZX3 2D CAD Drawing	Download
ZX5-PI 2D CAD Drawing	Download

EASE/CLF

Name	Language & Download
EKX EASE Data	Download
Sx Series EASE Data	Download
Tour X EASE Data	Download
ZLX G2 GLL	Download
Zx Series EASE Data	Download
Zx4 EASE Data	Download

IRIS-Net

Name	Language & Download
ELX200 Project File Example for IRIS-Net	Download
IRIS-Net Configuration Manual EN	Download
IRIS-Net V4.1.0	Download
IRIS-Net Configuration Manual DE	Download

Preset

Name	Language & Download
Tour X Presets for DX38	Download
Zx3 Presets for DC One	Download
Zx3 Presets for DX38	Download
Zx3 Presets for IRIS-Net	Download
ZX5-60 DX-38 Bi-Amp P3000	Download
ZX5-90 DX-38 Bi-Amp P3000	Download

Marketing Materials

Brochure

Name	Language & Download
Live X BroschÃƒÂ¼re	Download
ZLX Folleto	Download
Live X Folleto	Download
Live X brochura PortuguÃƒÂªs	Download
ZLX Brochura PortuguÃƒÂªs	Download
Live X Brochura PortuguÃƒÂªs	Download
LiveXÃ¤ÂºÂ§Ã¥â€œÂÃ¥Â®Â£Ã¤Â¼Â Ã¥â€ Å’	Download
ZLXÃ¤ÂºÂ§Ã¥â€œÂÃ¥Â®Â£Ã¤Â¼Â Ã¥â€ Å’	Download

Catalog

Name	Language & Download
Portable speakers catalog 2024 NA	Download

Flyer

Name	Language & Download
Live X flyer espaÃƒÂ±ol	Download
ZLX Flyer EspaÃƒÂ±ol	Download
Live X folheto PortuguÃƒÂªs	Download

PR Image

Name	Language & Download
IMG 0764	Download
IMG 0750	Download
W Hotel (6)	Download
IMG 0786	Download
W Hotel (4)	Download
MG 0065edited	Download
MG 7374edited	Download
MG 9732 AA3	Download
ELX App 06	Download
EV ELX200 DJF04 Aug17 4C FullRights FullRes	Download
EV ELX200 DJM09 Aug17 4C FullRights FullRes	Download
IMG 0044	Download
IMG 0801	Download
Rocker Carry	Download
Rocker Unload	Download
Silenci 06	Download
Silenci 08	Download
Silenci 09	Download
Silenci 11	Download
StageArray band	Download
ZLX App 10	Download
