HF Transducer

35 mm Compression Driver

Frequency Range (-10 dB)¹

40 Hz – 20 kHz

LF Transducer

200 mm (8 in)

Grille

Color matched steel grille with fabric

Nominal Coverage (Conical)

120°

Power Handling (Direct Coupled)

200 W Program, 100 W Pink Noise as per EN54-24 standard

Max Calculated SPL per EN54-24 standard

60 watt Transformer coupled @ 4 meters: 92 dB 100 watt Direct coupled @ 4 meters: 95 dB

Impedance

Direct Coupled: 8 Ohms 70V Transformer Coupled: 60 watt/83Ω, 30 watt/167Ω, 15 watt/ 333Ω, 7.5 watt/667Ω 100v Transformer Coupled: 60watt/167Ω, 30 watt/333Ω, 15 watt/667Ω

Transformer Taps

70V: 60W, 30W, 15W, 7.5W, 8 ohm 100V: 60W, 30W, 15W, 8 ohm

Connectors

Removable locking 4-pin (Phoenix) 2.5 mm (12 AWG) max wire size

Enclosure

ABS Plastic (UL94V-O) Baffle, steel back can

Color

White

Dimensions (H x Dia)

354 mm x 327 mm (13.94 in x 12.87 in)

Cutout Size

294.3 mm (11.59 in)

Net Weight

8.19 kg (18.05 lb)

Shipping Weight:(pair)

20.91 kg (46.1 lb)

Support Hardware

C Ring, Tile Bridge, Weatherized Terminal Cover

Approvals

UL1480, 2043; CE,EN54-24:2008

Sensitivity per EN54-24 standard (SPL 1 W / 4 m)

74.5 dB

Frequency Range (-10 dB)

75 Hz – 20 k

Weatherized

Yes

Minimum Impedance

6.4

HF Transducer

0.75 inch (20 mm)

Frequency Response (-3 dB)¹

100 Hz – 20 k

Max. SPL/1m (calc)²

103

Coverage (Nominal -6 dB) H

110

Coverage (Nominal -6 dB) V

110

LF Transducer

4 inch (102 mm)

Power Rating

160

Connector Type

Captive screws on wall bracket. Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm)

Available Color

Black or White

Sensitivity 1 W/1 m

87

Recommended High-Pass Frequency

70

Depth

118

Weight Net

1.5

Shipping Weight

5

Environmental Specs

IP54 (per IEC-60529)

Nominal Impedance

8

Power Handling (Continuous / Peak)

40 W/160

Frequency Range (-10 dB)

75 Hz – 20 k

Weatherized

Yes

HF Transducer

0.75 inch (20 mm)

Frequency Response (-3 dB)¹

100 Hz – 20 k

Max. SPL/1m (calc)²

104.5

Coverage (Nominal -6 dB) H

110

Coverage (Nominal -6 dB) V

110

LF Transducer

4 inch (102 mm)

Power Rating

60

Connector Type

Captive screws on wall bracket. Max. wire size 12AWG (2.5mm).

Available Color

Black or White

Sensitivity 1 W/1 m

86.5

Recommended High-Pass Frequency

70

Depth

118

Weight Net

1.8

Shipping Weight

5.4

Transformer

70V/100V (15W)

Environmental Specs

IP54 (per IEC-60529)

Power Handling (Continuous / Peak)

15 W/60

Frequency Range (-10 dB)

65 - 20000

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

1-inch

Speaker Type

Full-Range, Mid-High, Two-Way

Max. SPL/1m (calc)²

115

Coverage (Nominal -6 dB) H

120

Coverage (Nominal -6 dB) V

80

LF Transducer

Two 4-inch

Power Rating

400

System Power Handling (Continuous/Program/Peak)

100//400

LF Power Handling

Two 4-inch

HF Power Handling

1-inch

Available Color

Black or white

Sensitivity 1 W/1 m

89

Height

309.89

Width

175.26

Internal Crossover

Yes

Depth

215.9

Weight Net

3.9

Input Connections

Spring Terminal

Transformer Taps (Transformer Version Only)

70 V: 3.75 W, 70 V/100 V:7.5 W, 15 W,30 W,8ω Bypass

Chassis Size

101.6

Frequency Range (-10 dB)

65 - 20000

Weatherized

No

HF Transducer

0.75-inch (19 mm) Ti Mylar Laminate Dome

Speaker Type

Ported cabinet, internally damped, two-way

LF Transducer

4-inch polypropylene cone

Power Rating

200

System Power Handling (Continuous/Program/Peak)

50

Enclosure Material

Steel enclosure and UL94V-0 rated baffle and bezel

Grille

Powder-coated steel

Sensitivity 1 W/1 m

86

Available Color

White (paintable surface)

Height

176

Weight Net

2.7

Input Formats

8ω, 70 V, 100 V

Coverage (Nominal -6 dB)

130

Mounting Systems

Integrated 3-point toggle anchors

Regulatory Approvals

UL1480; UL2043

Chassis Size

101.6

Diameter (Max)

181

Transformer Taps (Transformer Version Only)

(1.88 - 70 V only), 3.75, 7.5, 15, 30

Transformer

Yes

Frequency Range (-10 dB)

60 Hz – 20 k

Weatherized

Yes

Minimum Impedance

6

HF Transducer

0.75 inch (20 mm)

Frequency Response (-3 dB)¹

85 Hz – 20

Max. SPL/1m (calc)²

109

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

90

LF Transducer

5.25 inch (133 mm)

Connector Type

Captive screws on wall bracket. Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm)

Sensitivity 1 W/1 m

90

Available Color

Black or White

Height

255

Width

180

Recommended High-Pass Frequency

60

Depth

151

Weight Net

2.7

Shipping Weight

6.7

Environmental Specs

IP54 (per IEC-60529)

Nominal Impedance

8

Frequency Range (-10 dB)

60 Hz – 20 k

Weatherized

Yes

Minimum Impedance

6

HF Transducer

0.75 inch (20 mm)

Frequency Response (-3 dB)¹

85 Hz – 20

Max. SPL/1m (calc)²

109

Coverage (Nominal -6 dB) H

90

LF Transducer

5.25 inch (133 mm)

Coverage (Nominal -6 dB) V

90

Connector Type

Captive screws on wall bracket. Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm)

Available Color

Black or White

Sensitivity 1 W/1 m

90

Height

255

Width

180

Recommended High-Pass Frequency

60

Depth

151

Weight Net

3.2

Shipping Weight

7.9

Transformer

70V/100V (30W)

Environmental Specs

IP54 (per IEC-60529)

Nominal Impedance

8

Frequency Range (-10 dB)

50 - 20

HF Transducer

35 mm compression driver

LF Transducer

165 mm (6.5 in)

Power Rating

200

HF Power Handling

200 W program, 100 W pink noise

Connector Type

Removable locking 4-Pin (Phoenix) 12AWG (2.5 mm) max wire size

Enclosure Material

ABS plastic (UL94V-0) baffle, steel back can

Grille

Color-matched steel grille with fabric

Sensitivity 1 W/1 m

87

Available Color

White

Height

260

Weight Net

7

Shipping Weight

16.83

Maximum SPL

107 dB avg, 113 pk

Cutout Size

248

Regulatory Approvals

UL1480; UL2043

Diameter (Max)

280

Transformer Taps (Transformer Version Only)

70V: 60W, 30W, 15W, 7.5W, 8Ω, 100V: 60W, 30W, 15W, 8Ω

Coverage (Nominal -6 dB)

120°

Mounting Systems

C ring, tile bridge

Impedance

8

Frequency Range (-10 dB)

55 Hz – 20 k

Weatherized

Yes

Minimum Impedance

6

HF Transducer

0.75 inch (20 mm)

Frequency Response (-3 dB)¹

90 Hz – 20

Max. SPL/1m (calc)²

108

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

90

LF Transducer

5.25 inch (122 mm)

Connector Type

Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm)

Sensitivity 1 W/1 m

90

Available Color

Black or White

Height

255

Width

180

Recommended High-Pass Frequency

60

Depth

148

Weight Net

3.2

Shipping Weight

9.5

Transformer

70V/100V (60W)

Environmental Specs

IP-65 (per IEC-60529)

Nominal Impedance

8

Frequency Range (-10 dB)

62 - 20000

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

1-inch

Speaker Type

Full-Range, Mid-High, Two-Way

Max. SPL/1m (calc)²

122

Coverage (Nominal -6 dB) H

100

Coverage (Nominal -6 dB) V

80

LF Transducer

Two 6-inch

System Power Handling (Continuous/Program/Peak)

150//600

Power Rating

600

LF Power Handling

Two 6-inch

HF Power Handling

1-inch

Sensitivity 1 W/1 m

94

Available Color

Black or white

Height

419

Width

228

Depth

298

Internal Crossover

Yes

Weight Net

5.3

Input Connections

Spring Terminal

Chassis Size

152.4

Transformer Taps (Transformer Version Only)

70 V/100 V: 15 W, 30 W, 60 W, 8ω Bypass

Frequency Range (-10 dB)

50 - 20000

Weatherized

No

HF Transducer

1-inch (25 mm) Ti Mylar Laminate Dome

Speaker Type

Ported cabinet, internally damped, two-way (passive crossover included)

LF Transducer

8-inch polypropylene cone

System Power Handling (Continuous/Program/Peak)

100

Power Rating

300

Enclosure Material

Steel enclosure and UL94V-0 rated baffle and bezel

Grille

Powder-coated steel

Sensitivity 1 W/1 m

91

Available Color

White (paintable surface)

Height

178

Weight Net

5

Regulatory Approvals

UL1480; EN54-24; UL2043

Chassis Size

203.2

Diameter (Max)

270

Transformer Taps (Transformer Version Only)

(1.88 - 70 V only), 3.75, 7.5, 15, 30

Transformer

Yes

Input Formats

8ω, 70 V, 100 V

Coverage (Nominal -6 dB)

110

Mounting Systems

Integrated 3-point toggle anchors

LP Height

255

Frequency Range (-10 dB)

45 - 20000

Suspension

EVA Grid (Sold Separately)

Minimum Impedance

12

Nominal Impedance (Passive)

16

HF Transducer

(4) DH2005, 1.25 In (32mm) Diaphragm Compression Driver

Speaker Type

Full-Range, Line-array

Frequency Response (-3 dB)¹

60 - 19000

Max. SPL/1m (calc)²

135

Coverage (Nominal -6 dB) H

120

Coverage (Nominal -6 dB) V

20

LF Transducer

(2) EVS2008, 8 In (203mm) Driver

System Power Handling (Continuous/Program/Peak)

350, 700, 1400

Crossover Frequency

1740

Enclosure Material

Birch plywood

Grille

16 GA Galvanneal, Powder-coated (PI Version - Stainless Steel with Hydrophobic Cloth

Sensitivity 1 W/1 m

104

Height

512.2

Width

596.9

Recommended High-Pass Frequency

50

Depth

369.1

Weight Net

36.8

Input Connections

Phoenix/Euroblock style screw terminals

Passive Power Handling

1400

Weatherized

No

HF Transducer

35 mm compression driver

Frequency Range (-10 dB)¹

40 - 20kHz

Max. SPL/1m (calc)²

108 db avg, 114 pk

LF Transducer

200 mm (8 in)

Power Rating

200

HF Power Handling

200W program, 100W pink noise

Connector Type

Removable locking 4-Pin (Phoenix) 12AWG (2.5 mm) max wire size

Enclosure Material

ABS plastic (UL94V-0) baffle, steel back can

Grille

Color-matched steel grille with fabric

Sensitivity 1 W/1 m

88

Available Color

White

Height

324

Weight Net

8

Shipping Weight

20.23

Diameter (Max)

327

Transformer Taps (Transformer Version Only)

70V: 60W, 30W, 15W, 7.5W, 8Ω, 100V: 60W, 30W, 15W, 8Ω

Coverage (Nominal -6 dB)

100°

Mounting Systems

C ring, tile bridge

Impedance

8

Cutout Size

294.3

Regulatory Approvals

UL1480; UL2043

Frequency Range (-10 dB)

50 Hz – 20 k

Weatherized

Yes

Minimum Impedance

6

HF Transducer

1 inch (25 mm)

Frequency Response (-3 dB)¹

70 Hz – 20 k

Max. SPL/1m (calc)²

110

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

90

LF Transducer

8 inch (203 mm)

Connector Type

Captive screws on wall bracket. Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm)

Available Color

Black or White

Height

390

Width

250

Recommended High-Pass Frequency

50

Depth

223

Weight Net

5.1

Shipping Weight

13

Environmental Specs

IP54 (per IEC-60529)

Nominal Impedance

8

Power Handling (Continuous / Peak)

90W/360

Frequency Range (-10 dB)

45 - 20000

Suspension

EVA Grid (Sold Separately)

Minimum Impedance

12

Nominal Impedance (Passive)

16

HF Transducer

(4) DH2005, 1.25 In (32mm) Diaphragm Compression Driver

Speaker Type

Full-Range, Line-array

Frequency Response (-3 dB)¹

60 - 19000

Max. SPL/1m (calc)²

135

Coverage (Nominal -6 dB) H

120

LF Transducer

(2) EVS2008, 8 In (203mm) Driver

Coverage (Nominal -6 dB) V

6

System Power Handling (Continuous/Program/Peak)

350, 700, 1400

Crossover Frequency

1740

Enclosure Material

Birch plywood

Grille

16 GA Galvanneal, Powder-coated (PI Version - Stainless Steel with Hydrophobic Cloth

Sensitivity 1 W/1 m

104

Height

514.4

Width

596.9

Recommended High-Pass Frequency

50

Depth

358.2

Weight Net

37.1

Passive Power Handling

1400

Input Connections

Phoenix/Euroblock style screw terminals

Frequency Range (-10 dB)

50 - 20000

Weatherized

No

HF Transducer

1-inch (25 mm) Ti Mylar Laminate Dome

Speaker Type

Ported cabinet, internally damped, two-way (passive crossover included)

LF Transducer

8-inch polypropylene cone plus waveguide

Power Rating

300

System Power Handling (Continuous/Program/Peak)

100

Enclosure Material

Steel enclosure and UL94V-0 rated baffle and bezel

Grille

Powder-coated steel

Available Color

White (paintable surface)

Sensitivity 1 W/1 m

93

Height

303

Weight Net

6

Input Formats

8ω, 70 V, 100 V

Coverage (Nominal -6 dB)

75

Chassis Size

203.2

Mounting Systems

Integrated 3-point toggle anchors

Regulatory Approvals

UL1480; UL2043

Diameter (Max)

320

Transformer Taps (Transformer Version Only)

(7.5 - 70 V only), 15, 30, 60

Transformer

Yes

Frequency Range (-10 dB)

50 Hz – 20 k

Weatherized

Yes

Minimum Impedance

6

HF Transducer

1 inch (25 mm)

Frequency Response (-3 dB)¹

70 Hz – 20 k

Max. SPL/1m (calc)²

110

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

90

LF Transducer

8 inch (203 mm)

Power Rating

360

Connector Type

Captive screws on wall bracket. Removable locking 4-pin connector (Euroblock) – (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm)

Available Color

Black or White

Height

390

Width

250

Recommended High-Pass Frequency

50

Depth

223

Weight Net

5.8

Shipping Weight

14.8

Transformer

70V/100V (60W)

Environmental Specs

IP54 (per IEC-60529)

Nominal Impedance

8

Power Handling (Continuous / Peak)

90W/360

Regulatory Approvals

IP54

Frequency Range (-10 dB)

45 - 20000

Suspension

EVA Grid (Sold Separately)

Minimum Impedance

12

Nominal Impedance (Passive)

16

HF Transducer

(4) DH2005, 1.25 In (32mm) Diaphragm Compression Driver

Speaker Type

Full-Range, Line-array

Frequency Response (-3 dB)¹

60 - 19000

Max. SPL/1m (calc)²

135

Coverage (Nominal -6 dB) H

90

LF Transducer

(2) EVS2008, 8 In (203mm) Driver

Coverage (Nominal -6 dB) V

20

System Power Handling (Continuous/Program/Peak)

350, 700, 1400

Crossover Frequency

1740

Enclosure Material

Birch plywood

Grille

16 GA Galvanneal, Powder-coated (PI Version - Stainless Steel with Hydrophobic Cloth

Sensitivity 1 W/1 m

104

Height

512.2

Width

596.9

Recommended High-Pass Frequency

50

Depth

369.1

Weight Net

36.8

Input Connections

Phoenix/Euroblock style screw terminals

Passive Power Handling

1400

Max Calculated SPL

60 watt Transformer coupled @ 4 meters: 92 dB 100 watt Direct coupled @ 4 meters: 95 dB

HF Transducer

1 in (25 mm) Ti Mylar laminate

LF Transducer

8 in. (200 mm) Polypropylene cone

Grille

Perforated powder coated steel wit safety tether

Net Weight

11.0 lbs (5.0 kg)

Shipping Weight:(pair)

24.0 lbs (11.0 kg)

Support Hardware

Tile bridge, backing plate support cutout template, paint shield

Freq. Response (-10 dB)

50 Hz - 20 kHz

Coverage (Conical)

110°

Power Handling

75 W Cont. / 300 W Peak

Sensitivity (SPL 1W/1m)

91 dB

Network

Network and transducers protected 12 dB/oct 2.6 kHz

Safety Agency Ratings

UL 1480 Safe for use in air handling spaces per UL 2043

Impedance

8 Ohms nominal (transformer bypass)

Transformer Taps

70V: 1.88, 3.75, 7.5, 15 or 30 100V: 3.75, 7.5, 15 or 30W Bypass: 8 Ohms

Connectors

Phoenix type removable, with scre terminals and "loop-thru", accepts 12 ga wire

Enclosure

Baffle- UL 94V-O rated AB Backcan-Zinc plated steel

Dimensions (H x Dia)

7.0" x 10.6 (178mm x 270mm)

Cutout Size

10.75" (272mm)

Shipping Weight:(pair)

17.51 kg (38.6 lb)

Support Hardware

C Ring, Tile Bridge, Weatherized Terminal Cover

Approvals

UL1480, 2043; CE,EN54-24:2008

Frequency Range (-10 db)

50 Hz – 20 kHz

Nominal Coverage (Conical)

100°

Power Handling (Direct Coupled)

200 W Program, 100 W Pink Noise as per EN54-24 standard

Sensitivity per EN54-24 standard (SPL 1 W/4 m)

75 dB

Max Calculated SPL per EN54-24 standard

60 watt Transformer coupled @ 4 meters: 92 dB 100 watt Direct coupled @ 4 meters: 95 dB

Impedance

Direct Coupled: 8 ohms 70V Transformer Coupled: 60 watt/83Ω, 30 watt/167Ω, 15 watt/ 333Ω, 7.5 watt/667Ω 100v Transformer Coupled: 60watt/167Ω, 30 watt/333Ω, 15 watt/667Ω

LF Transducer

165 mm (6.5 in)

HF Transducer

35 mm Compression Driver

Transformer Taps

70V: 60W, 30W, 15W, 7.5W, 8 ohm 100V: 60W, 30W, 15W, 8 ohm

Connectors

Removable locking 4-pin (Phoenix) 2.5 mm (12 AWG) max wire size

Enclosure

ABS Plastic (UL94V-O) Baffle, steel back can

Color

White

Grille

Color matched steel grille with fabric

Dimensions (H x Dia)

294 mm x 280 mm (11.57 in x 11.0 in)

Cutout Size

248 mm (9.76 in)

Net Weight

7.33 kg (16.15 lb)

Frequency Range (-10 dB)

45 - 20000

Suspension

EVA Grid (Sold Separately)

Minimum Impedance

12

Nominal Impedance (Passive)

16

HF Transducer

(4) DH2005, 1.25 In (32mm) Diaphragm Compression Driver

Speaker Type

Full-Range, Line-array

Frequency Response (-3 dB)¹

60 - 19000

Max. SPL/1m (calc)²

135

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

6

LF Transducer

(2) EVS2008, 8 In (203mm) Driver

System Power Handling (Continuous/Program/Peak)

350, 700, 1400

Crossover Frequency

1740

Enclosure Material

Birch plywood

Grille

16 GA Galvanneal, Powder-coated (PI Version - Stainless Steel with Hydrophobic Cloth

Sensitivity 1 W/1 m

104

Height

514.4

Recommended High-Pass Frequency

50

Width

596.9

Depth

358.2

Weight Net

37.1

Input Connections

Phoenix/Euroblock style screw terminals

Passive Power Handling

1400

HF Transducer

1-inch (25 mm)

Speaker Type

Ported cabinet, internally damped two-way

Frequency Response (-3 dB)¹

65 - 20,000

Max. SPL/1m (calc)²

126

LF Transducer

12-inch EVID 920-8B

System Power Handling (Continuous/Program/Peak)

100

Power Rating

64

Crossover Frequency

2000

Enclosure Material

Steel enclosure and UL94V-0 rated baffle and bezel

Grille

Powder-coated steel

Sensitivity 1 W/1 m

100

Available Color

White (paintable surface)

Height

333

Weight Net

12.3

Diameter (Max)

414

Transformer Taps (Transformer Version Only)

4 (70 V only), 8, 16, 32, 64 W ASC protected

Input Formats

8ω / 70V / 100V

Coverage (Nominal -6 dB)

90

Mounting Systems

Integrated 3-point toggle anchors

Frequency Range (-10 dB)

28 - 200

Suspension

EVA grid (sold separately)

Minimum Impedance

2.8

Nominal Impedance (Passive)

4

Speaker Type

Subwoofer, Line-array

Frequency Response (-3 dB)¹

200

Max. SPL/1m (calc)²

136

Coverage (Nominal -6 dB) H

360

LF Transducer

2 x DVX3159A

Coverage (Nominal -6 dB) V

omnidirectional

System Power Handling (Continuous/Program/Peak)

1000/2000/4000

Crossover Frequency

100

Enclosure Material

Birch Plywood

Grille

16 GA Galvanneal, powder-coated; PI Version: stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

100

Height

930.4

Width

597

Recommended High-Pass Frequency

32

Depth

792.5

Weight Net

80.8

Input Connections

Phoenix Euroblock

Passive Power Handling

4000

Frequency Range (-10 dB)

33 Hz – 500

Weatherized

Yes

Max. SPL/1m (calc)²

120

LF Transducer

Two 10 inch (254 mm)

Connector Type

Two removable locking 4-pin connector (Euroblock) – Input and output. Max. wire size 12 AWG (2.5 mm).

Available Color

Black or White

Sensitivity 1 W/1 m

94

Height

356

Width

651

Recommended High-Pass Frequency

40

Depth

491

Weight Net

17.9

Shipping Weight

21

Transformer Taps (Transformer Version Only)

Optional Accessory

Environmental Specs

IP-54 (per IEC-60529); IP-65 with port covers

Nominal Impedance

Stereo Mode: (2) 8ω; Mono Mode: (1) 4

Power Handling (Continuous / Peak)

400W/1600

Frequency Range (-10 dB)

49 Hz – 21

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

3" DH7N diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

57 Hz – 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

120

Coverage (Nominal -6 dB) V

60

LF Transducer

12" DVX3121A woofer

System Power Handling (Continuous/Program/Peak)

600 , 1200 , 2400

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

97

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Available Coverage Patterns (Nominal -6 dB) HxV

120 x 60

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26" x 16.00" x 16.27" (768.6 x 406.3 x 413.3 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

120

Coverage (Nominal -6 dB) V

60

LF Transducer

DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Available Coverage Patterns (Nominal -6 dB) HxV

120 x 60

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Frequency Range (-10 dB)

49 Hz – 21

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

3" DH7N diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

57 Hz – 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

60

Coverage (Nominal -6 dB) V

40

LF Transducer

12" DVX3121A woofer

System Power Handling (Continuous/Program/Peak)

600 , 1200 , 2400

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

97

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Available Coverage Patterns (Nominal -6 dB) HxV

60 x 40

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26" x 16.00" x 16.27" (768.6 x 406.3 x 413.3 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

60

Coverage (Nominal -6 dB) V

40

LF Transducer

DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Available Coverage Patterns (Nominal -6 dB) HxV

60 x 40

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Frequency Range (-10 dB)

49 Hz – 21

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

3" DH7N diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

57 Hz – 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

60

Coverage (Nominal -6 dB) V

60

LF Transducer

12" DVX3121A woofer

System Power Handling (Continuous/Program/Peak)

600 , 1200 , 2400

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

97

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Available Coverage Patterns (Nominal -6 dB) HxV

60 x 60

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26" x 16.00" x 16.27" (768.6 x 406.3 x 413.3 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

60

Coverage (Nominal -6 dB) V

60

LF Transducer

DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Available Coverage Patterns (Nominal -6 dB) HxV

60 x 60

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Frequency Range (-10 dB)

49 Hz – 21

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

3" DH7N diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

57 Hz – 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

40

LF Transducer

12" DVX3121A woofer

System Power Handling (Continuous/Program/Peak)

600 , 1200 , 2400

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

97

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 40

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26" x 16.00" x 16.27" (768.6 x 406.3 x 413.3 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

40

LF Transducer

DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 40

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Frequency Range (-10 dB)

49 Hz – 21

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

3" DH7N diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

57 Hz – 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

60

LF Transducer

12" DVX3121A woofer

System Power Handling (Continuous/Program/Peak)

600 , 1200 , 2400

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

97

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 60

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26" x 16.00" x 16.27" (768.6 x 406.3 x 413.3 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

60

LF Transducer

DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 60

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Frequency Range (-10 dB)

49 Hz – 21

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

3" DH7N diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

57 Hz – 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

90

LF Transducer

12" DVX3121A woofer

System Power Handling (Continuous/Program/Peak)

600 , 1200 , 2400

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

97

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 90

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26" x 16.00" x 16.27" (768.6 x 406.3 x 413.3 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

90

LF Transducer

DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

29.7

Shipping Weight

34.4

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 90

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Frequency Range (-10 dB)

49 Hz – 19

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

58 Hz – 16

Max. SPL/1m (calc)²

131 dB

Coverage (Nominal -6 dB) H

120

LF Transducer

12" SMX2121 driver

Coverage (Nominal -6 dB) V

60

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

98 dB

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

28.6

Available Coverage Patterns (Nominal -6 dB) HxV

120 x 60

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Net Weight

63.1 lb (28.6 kg)

Dimensions (H x W x D)

30.26" x 16" x 16.27" (768.6 x 406.3 x 413.3 )

Frequency Range (-10 dB)

49 Hz – 19

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

58 Hz – 16

Max. SPL/1m (calc)²

131 dB

Coverage (Nominal -6 dB) H

60

LF Transducer

12" SMX2121 driver

Coverage (Nominal -6 dB) V

40

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

98 dB

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

28.6

Available Coverage Patterns (Nominal -6 dB) HxV

60 x 40

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Net Weight

63.1 lb (28.6 kg)

Dimensions (H x W x D)

30.26" x 16" x 16.27" (768.6 x 406.3 x 413.3 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

49 Hz – 19

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

58 Hz – 16

Max. SPL/1m (calc)²

131 dB

Coverage (Nominal -6 dB) H

60

Coverage (Nominal -6 dB) V

60

LF Transducer

12" SMX2121 driver

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

98 dB

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

28.6

Available Coverage Patterns (Nominal -6 dB) HxV

60 x 60

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Net Weight

63.1 lb (28.6 kg)

Dimensions (H x W x D)

30.26" x 16" x 16.27" (768.6 x 406.3 x 413.3 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

49 Hz – 19

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

58 Hz – 16

Max. SPL/1m (calc)²

131 dB

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

40

LF Transducer

12" SMX2121 driver

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

98 dB

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

28.6

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 40

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Net Weight

63.1 lb (28.6 kg)

Dimensions (H x W x D)

30.26" x 16" x 16.27" (768.6 x 406.3 x 413.3 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

49 Hz – 19

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

58 Hz – 16

Max. SPL/1m (calc)²

131 dB

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

60

LF Transducer

12" SMX2121 driver

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

98 dB

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

28.6

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Net Weight

63.1 lb (28.6 kg)

Dimensions (H x W x D)

30.26" x 16" x 16.27" (768.6 x 406.3 x 413.3 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 60

Frequency Range (-10 dB)

49 Hz – 19

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

58 Hz – 16

Max. SPL/1m (calc)²

131 dB

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

90

LF Transducer

12" SMX2121 driver

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

98 dB

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

28.6

Passive Power Handling

2000

Net Weight

63.1 lb (28.6 kg)

Dimensions (H x W x D)

30.26" x 16" x 16.27" (768.6 x 406.3 x 413.3 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 90

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Frequency Range (-10 dB)

46–124 Hz

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

Nominal Impedance (Passive)

Passive: 4 , Biamp: 8

HF Transducer

Speaker Type

Subwoofer

Frequency Response (-3 dB)¹

67–95 Hz

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

360

LF Transducer

15" EVS15SB driver

System Power Handling (Continuous/Program/Peak)

400 , 800 , 1600

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

99

Height

768.6

Width

470

Recommended High-Pass Frequency

35

Depth

467

Weight Net

28.4

Internal Passive Crossover Frequency

Internal Passive Low-Pass Filter

100

Coverage (Nominal -6 dB)

Omnidirectional in normal operating range

Passive Power Handling

1600

Net Weight

62.6 lb (28.4 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.4" (768.6 x 470 x 467 )

Input Connections

Euroblock; PI and FG versions include dual gland nut input panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

Omnidirectional in normal operating range

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Frequency Range (-10 dB)

40 Hz – 21

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

3" DH7N diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 Hz – 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

134

Coverage (Nominal -6 dB) H

40

Coverage (Nominal -6 dB) V

30

LF Transducer

15" DVX3151A woofer

System Power Handling (Continuous/Program/Peak)

600 , 1200 , 2400

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

100

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

34.4

Shipping Weight

39.1

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

40 x 30

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Net Weight

75.7 lb (34.4 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6 )

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

40

Coverage (Nominal -6 dB) V

30

LF Transducer

- DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

469.8

Recommended High-Pass Frequency

65

Depth

466.6

Weight Net

34.4

Shipping Weight

39.1

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Available Coverage Patterns (Nominal -6 dB) HxV

40 x 30

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

60

Coverage (Nominal -6 dB) V

40

LF Transducer

- DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

469.8

Recommended High-Pass Frequency

65

Depth

466.6

Weight Net

34.4

Shipping Weight

39.1

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Available Coverage Patterns (Nominal -6 dB) HxV

60 x 40

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Frequency Range (-10 dB)

40 Hz – 21

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

3" DH7N diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 Hz – 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

134

Coverage (Nominal -6 dB) H

60

Coverage (Nominal -6 dB) V

60

LF Transducer

15" DVX3151A woofer

System Power Handling (Continuous/Program/Peak)

600 , 1200 , 2400

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

100

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

34.4

Shipping Weight

39.1

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

60 x 60

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Net Weight

75.7 lb (34.4 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6 )

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

60

Coverage (Nominal -6 dB) V

60

LF Transducer

- DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

469.8

Recommended High-Pass Frequency

65

Depth

466.6

Weight Net

34.4

Shipping Weight

39.1

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Available Coverage Patterns (Nominal -6 dB) HxV

60 x 60

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Frequency Range (-10 dB)

40 Hz – 21

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

3" DH7N diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 Hz – 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

134

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

40

LF Transducer

15" DVX3151A woofer

System Power Handling (Continuous/Program/Peak)

600 , 1200 , 2400

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

100

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

34.4

Shipping Weight

39.1

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 40

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Net Weight

75.7 lb (34.4 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6 )

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

40

LF Transducer

- DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

469.8

Recommended High-Pass Frequency

65

Depth

466.6

Weight Net

34.4

Shipping Weight

39.1

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 40

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Frequency Range (-10 dB)

40 Hz – 21

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

3" DH7N diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 Hz – 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

134

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

60

LF Transducer

15" DVX3151A woofer

System Power Handling (Continuous/Program/Peak)

600 , 1200 , 2400

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

100

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

34.4

Shipping Weight

39.1

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 60

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Net Weight

75.7 lb (34.4 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6 )

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

60

LF Transducer

- DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

469.8

Recommended High-Pass Frequency

65

Depth

466.6

Weight Net

34.4

Shipping Weight

39.1

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 60

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Frequency Range (-10 dB)

40 Hz – 21

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

3" DH7N diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 Hz – 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

134

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

90

LF Transducer

15" DVX3151A woofer

System Power Handling (Continuous/Program/Peak)

600 , 1200 , 2400

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

100

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

34.4

Shipping Weight

39.1

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 90

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Net Weight

75.7 lb (34.4 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6 )

Frequency Range (-10 dB)

66 Hz - 21

Suspension

(22) M10 threaded suspension points

Weatherized

Yes

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N, 3” (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

118 Hz - 18

LF Nominal Impedance

8

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

90

LF Transducer

- DVX3121A, 12” (305 mm) driver

System Power Handling (Continuous/Program/Peak)

600 continuous, 2400 peak

Crossover Frequency

1300

Enclosure Material

13-ply weather-resistant birch with fiberglass finish

Grille

18 GA stainless steel with hydrophobic cloth

Sensitivity 1 W/1 m

97 (1 W/1 m)

Height

768.6

Width

469.8

Recommended High-Pass Frequency

65

Depth

466.6

Weight Net

34.4

Shipping Weight

39.1

Input Connections

Dual four-pin 10 AWG Phoenix/Euro Block screw-terminals, CDG dual-gland-nut input panel cover included for weatherizing

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 90

Environmental Specs

IEC 60529 IP55

Internal Passive Crossover Frequency

1300 Hz

Passive Power Handling

2400

Net Weight

65.5 lb (29.7 kg)

Dimensions (H x W x D)

30.26” x 16.00” x 16.27” (768.6 x 406.3 x 413.3 )

Frequency Range (-10 dB)

41 Hz – 18

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 Hz – 14

Max. SPL/1m (calc)²

134 dB

Coverage (Nominal -6 dB) H

40

LF Transducer

15" SMX2151 driver

Coverage (Nominal -6 dB) V

30

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

101 dB

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

32.1

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

40 x 30

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Net Weight

70.9 lb (32.1 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6 )

Frequency Range (-10 dB)

41 Hz – 18

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 Hz – 14

Max. SPL/1m (calc)²

134 dB

Coverage (Nominal -6 dB) H

60

LF Transducer

15" SMX2151 driver

Coverage (Nominal -6 dB) V

40

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

101 dB

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

32.1

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

60 x 40

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Net Weight

70.9 lb (32.1 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6 )

Frequency Range (-10 dB)

41 Hz – 18

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 Hz – 14

Max. SPL/1m (calc)²

134

Coverage (Nominal -6 dB) H

60

LF Transducer

15" SMX2151 driver

Coverage (Nominal -6 dB) V

60

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

101

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

32.1

Available Coverage Patterns (Nominal -6 dB) HxV

60 x 60

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Net Weight

70.9 lb (32.1 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

41 Hz – 18

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 Hz – 14

Max. SPL/1m (calc)²

134

Coverage (Nominal -6 dB) H

90

LF Transducer

15" SMX2151 driver

Coverage (Nominal -6 dB) V

40

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

101

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

32.1

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 40

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Net Weight

70.9 lb (32.1 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

41 Hz – 18

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 Hz – 14

Max. SPL/1m (calc)²

134

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

60

LF Transducer

15" SMX2151 driver

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

101

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

32.1

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 60

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Net Weight

70.9 lb (32.1 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

41 Hz – 18

Suspension

22 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

2" ND2B diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 Hz – 14

Max. SPL/1m (calc)²

134

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

90

LF Transducer

15" SMX2151 driver

System Power Handling (Continuous/Program/Peak)

500 , 1000 , 2000

Crossover Frequency

1450

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

101

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

32.1

Available Coverage Patterns (Nominal -6 dB) HxV

90 x 90

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Net Weight

70.9 lb (32.1 kg)

Dimensions (H x W x D)

30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6 )

Input Connections

Euroblock; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

28–650 Hz

Suspension

28 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

Passive: N/A, Biamp: 6

Nominal Impedance (Passive)

Passive: N/A, Biamp: 8

HF Transducer

Speaker Type

Subwoofer

Frequency Response (-3 dB)¹

35–100 Hz

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

360

LF Transducer

18" EVS18SB driver

System Power Handling (Continuous/Program/Peak)

400 , 800 , 1600

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

99

Height

768.6

Width

675.6

Recommended High-Pass Frequency

33

Depth

726.4

Weight Net

45.9

Coverage (Nominal -6 dB)

Omnidirectional in normal operating range

Passive Power Handling

1600

Net Weight

101.2 lb (45.9 kg)

Dimensions (H x W x D)

30.26" x 26.6" x 28.6" (768.6 x 675.6 x 726.4 )

Input Connections

Euroblock; PI and FG versions include dual gland nut input panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

Omnidirectional in normal operating range

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Nominal Impedance

Passive: N/A, Bi-amp: 8

Internal Passive Crossover Frequency

Frequency Range (-10 dB)

30 Hz – 3.2

Suspension

28 M10 threaded suspension points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

Passive: N/A, Biamp: 2.7

Nominal Impedance (Passive)

Passive: N/A, Biamp: 4

HF Transducer

Speaker Type

Subwoofer

Frequency Response (-3 dB)¹

40 Hz – 2.6

Max. SPL/1m (calc)²

137

Coverage (Nominal -6 dB) H

360

Coverage (Nominal -6 dB) V

Omnidirectional

LF Transducer

Two 15" DVX3159A drivers

System Power Handling (Continuous/Program/Peak)

1000 , 2000 , 4000

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16 ga Galvanneal, Powdercoat with screen behind PI and FG versions: 18 ga Stainless, Powdercoat with hydrophobic cloth behind

Sensitivity 1 W/1 m

101

Height

768.6

Width

675.6

Recommended High-Pass Frequency

35

Depth

726.4

Weight Net

53.1

Available Coverage Patterns (Nominal -6 dB) HxV

Omnidirectional in normal operating range

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Nominal Impedance

4

Internal Passive Crossover Frequency

Coverage (Nominal -6 dB)

Omnidirectional in normal operating range

Passive Power Handling

4000

Net Weight

117 lb (53.1 kg)

Dimensions (H x W x D)

30.26" x 26.6" x 28.6" (768.6 x 675.6 x 726.4 )

Input Connections

Euroblock; PI and FG versions include dual gland nut input panel cover

Frequency Range (-10 dB)

49 - 21

Suspension

(22) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N 3-inch (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

57 - 18000

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

120

LF Transducer

DVX3121A 12-inch (305 mm) woofer

System Power Handling (Continuous/Program/Peak)

600, 1200, 2400

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind

Sensitivity 1 W/1 m

97

Recommended High-Pass Frequency

65

Input Connections

Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

60x40, 60x60, 90x40, 90x60, 90x90, 120x60

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Frequency Range (-10 dB)

40 - 21

Suspension

(22) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

DH7N 3-inch (76 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 - 18000

Max. SPL/1m (calc)²

134

Coverage (Nominal -6 dB) H

90

LF Transducer

DVX3151A 15-inch (381 mm) woofer

System Power Handling (Continuous/Program/Peak)

600, 1200, 2400

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind

Sensitivity 1 W/1 m

100

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

34.4

Input Connections

Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

40x30, 60x40, 60x60, 90x40, 90x60, 90x90

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1300

Passive Power Handling

2400

Frequency Range (-10 dB)

49 - 19

Suspension

(22) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

ND2B 2-inch (51 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

58 - 16000

Max. SPL/1m (calc)²

131

Coverage (Nominal -6 dB) H

120

LF Transducer

SMX2121 12-inch (305 mm) driver

System Power Handling (Continuous/Program/Peak)

500, 1000, 2000

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind

Sensitivity 1 W/1 m

98

Height

768.6

Width

406.3

Recommended High-Pass Frequency

65

Depth

413.3

Weight Net

28.6

Available Coverage Patterns (Nominal -6 dB) HxV

60x40, 60x60, 90x40, 90x60, 90x90, 120x60

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Input Connections

Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover

Frequency Range (-10 dB)

41 - 18

Suspension

(22) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included)

Weatherized

No

Minimum Impedance

6

Nominal Impedance (Passive)

8

HF Transducer

ND2B 2-inch (51 mm) diaphragm compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

70 - 14000

Max. SPL/1m (calc)²

134

Coverage (Nominal -6 dB) H

90

LF Transducer

SMX2151 15-inch (381 mm) driver

System Power Handling (Continuous/Program/Peak)

500, 1000, 2000

Enclosure Material

13-ply weather-resistant birch

Grille

Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind

Sensitivity 1 W/1 m

101

Height

768.6

Width

469.8

Recommended High-Pass Frequency

45

Depth

466.6

Weight Net

32.1

Input Connections

Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover

Available Coverage Patterns (Nominal -6 dB) HxV

40x30, 60x40, 60x60, 90x40, 90x60, 90x90

Environmental Specs

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

Internal Passive Crossover Frequency

1450

Passive Power Handling

2000

Frequency Range (-10 dB)

45 - 180

Weatherized

No

Flying

No

Speaker Type

Dual ported cabinet, internally damped

Max. SPL/1m (calc)²

122

LF Transducer

10-inch polypropylene cone

System Power Handling (Continuous/Program/Peak)

150

Power Rating

600

Enclosure Material

Steel enclosure and UL94V-0 rated baffle and bezel

Grille

Powder-coated steel

Available Color

White (paintable surface)

Sensitivity 1 W/1 m

94

Height

303

Weight Net

7

Diameter (Max)

320

Transformer Taps (Transformer Version Only)

(7.5 - 70 V only), 15, 30, 60

Transformer

Yes

Input Formats

8ω, 70 V, 100 V

Coverage (Nominal -6 dB)

180

Mounting Systems

Integrated 3-point toggle anchors

Chassis Size

254

Frequency Range (-10 dB)

40Hz - 140

Weatherized

Yes

Speaker Type

Subwoofer

Max. SPL/1m (calc)²

127

LF Transducer

12 inch (305 mm)

Connector Type

Spring loaded

Available Color

Black or White

Height

413

Width

584

Depth

303

Weight Net

17.8

Shipping Weight

22.4

Sensitivity (LF/MF/HF)

104

Nominal Impedance

8

Power Handling (Continuous / Peak)

200W/800

Weatherized

No

Minimum Impedance

3.7

Nominal Impedance (Passive)

4

HF Transducer

1-inch softdome

Speaker Type

Monitor

Woofer Size

5.25

Powered or Passive

Passive

Max. SPL/1m (calc)²

113

Coverage (Nominal -6 dB) H

100

Coverage (Nominal -6 dB) V

100

LF Transducer

5.25-inch

System Power Handling (Continuous/Program/Peak)

120/480

Power Rating

120

Crossover Frequency

3500

Enclosure Material

High Impact Polystyrene Composite

Sensitivity 1 W/1 m

85

Height

249

Width

178

Depth

150

Weight Net

2.6

Frequency Response (-3 dB)

85 - 20000

Chassis Size

133.35

Input Connections

Spring Terminal

Directivity Index

9.8

Passive Power Handling

30

Frequency Range (-10 dB)

50 - 20000

Weatherized

No

Nominal Impedance (Passive)

8

System Power Handling (Continuous/Program/Peak)

200

Sensitivity 1 W/1 m

100

Available Color

Black

Chassis Size

304.8

Input Connections

Screw Terminal

Height

88.1

Width

482.6

Depth

421.5

Frequency Response (-3 dB)

10 Hz - 40 kHz

Weight Net

17.7

Amplifier Gain

32

Analog Inputs

2, electronically balanced, Phoenix-type

Maximum Input Voltage

+21 dBu (8.69 Vrms)

Mains Voltage

240 V, 230 V, 120 V or 100 V; 50 Hz - 60 Hz (factory configured)

CAN Bus Interface

Optional (RCM-810 card)

Cooling

Front-to-Rear, 3-stage-fans

Audio Network

No

Variable Load Drive (VLD)

No

Topology

Class-H

Continuous Rated Power (1 kHz, THD 1%) 4Ω

1200

Impedance

2/4/8

Crossover Type

Modular

Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω

1100

Electronics Type

Amplifier

Continuous Rated Power (1 kHz, THD 1%) 2Ω

1800

Continuous Rated Power (1 kHz, THD 1%) 8Ω

750

Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω

550

Maximum Bridged Output 8Ω

2400

Maximum Bridged Output 4Ω

3600

Total Harmonic Distortion

0.03

Slew Rate

30

Intermodulation Distortion (SMPTE)

0.1

DIM 30

0.05

Input Impedance (Balanced)

20

Input Sensitivity

+6.6 dBu (1.66 Vrms)

Network Control (IRIS-Net)

Optional (RCM-810 card)

Height

88.1

Width

482.6

Depth

421.5

Frequency Response (-3 dB)

10 Hz - 40 kHz

Weight Net

12.6

Amplifier Gain

32

Analog Inputs

2, electronically balanced, Phoenix-type

Maximum Input Voltage

+21 dBu

Mains Voltage

240 V, 230 V, 120 V or 100 V; 50 Hz - 60 Hz (factory configured)

CAN Bus Interface

Optional (RCM-810 card)

Cooling

Front-to-Rear, 3-stage fans

Audio Network

No

Variable Load Drive (VLD)

No

Topology

Class-AB

Impedance

2/4/8

Continuous Rated Power (1 kHz, THD 1%) 4Ω

450

Crossover Type

Optional Modules

Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω

400

Electronics Type

Amplifier

Continuous Rated Power (1 kHz, THD 1%) 2Ω

650

Continuous Rated Power (1 kHz, THD 1%) 8Ω

270

Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω

200

Maximum Bridged Output 8Ω

900

Maximum Bridged Output 4Ω

1300

Total Harmonic Distortion

0.03

Slew Rate

25

Intermodulation Distortion (SMPTE)

0.1

DIM 30

0.05

Input Impedance (Balanced)

20

Input Sensitivity

2.2 dBu (1.0V)

Network Control (IRIS-Net)

Optional (RCM-810 card)

Height

88.1

Width

482.6

Depth

421.5

Frequency Response (-3 dB)

10 Hz - 40 kHz

Weight Net

14.8

Amplifier Gain

32

Analog Inputs

2, electronically balanced, Phoenix-type

Maximum Input Voltage

+21 dBu

Mains Voltage

240 V, 230 V, 120 V or 100 V; 50 Hz - 60 Hz (factory configured)

CAN Bus Interface

Optional (RCM-810 card)

Cooling

Front-to-Rear, 3-stage fans

Audio Network

No

Variable Load Drive (VLD)

No

Topology

Class-AB

Impedance

2/4/8

Continuous Rated Power (1 kHz, THD 1%) 4Ω

600

Crossover Type

Optional Modules

Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω

500

Electronics Type

Amplifier

Continuous Rated Power (1 kHz, THD 1%) 2Ω

900

Continuous Rated Power (1 kHz, THD 1%) 8Ω

380

Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω

250

Maximum Bridged Output 8Ω

1200

Maximum Bridged Output 4Ω

1800

Total Harmonic Distortion

0.03

Slew Rate

26

Intermodulation Distortion (SMPTE)

0.05

DIM 30

0.02

Input Impedance (Balanced)

20

Input Sensitivity

+3.1 dBu (1.11Vrms)

Network Control (IRIS-Net)

Optional

Height

88.1

Width

482.6

Depth

421.5

Frequency Response (-3 dB)

10 Hz - 40 kHz

Weight Net

16.3

Amplifier Gain

32

Analog Inputs

2, electronically balanced, Phoenix-type

Maximum Input Voltage

+21 dBu (8.69 Vrms)

Mains Voltage

240 V, 230 V, 120 V or 100 V; 50 Hz - 60 Hz (factory configured)

CAN Bus Interface

Optional (RCM-810 card)

Cooling

Front-to-Rear, 3-stage-fans

Audio Network

No

Variable Load Drive (VLD)

No

Topology

Class-H

Impedance

2/4/8

Continuous Rated Power (1 kHz, THD 1%) 4Ω

900

Crossover Type

Modular

Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω

800

Electronics Type

Amplifier

Continuous Rated Power (1 kHz, THD 1%) 2Ω

1250

Continuous Rated Power (1 kHz, THD 1%) 8Ω

550

Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω

400

Maximum Bridged Output 8Ω

1800

Maximum Bridged Output 4Ω

2800

Total Harmonic Distortion

0.03

Slew Rate

27

Intermodulation Distortion (SMPTE)

0.1

DIM 30

0.05

Input Impedance (Balanced)

20

Input Sensitivity

+5.1 dBu (1.39 Vrms)

Network Control (IRIS-Net)

Optional (RCM-810 card)

Height

88.1

Width

482.6

Depth

421.5

Frequency Response (-3 dB)

15 Hz-30 kHz

Weight Net

11.1

Continuous Rated Power (20-20 kHz, THD<0,2%) 70v

900

Analog Inputs

4, electronically balanced, Phoenix-type

Maximum Input Voltage

+22

Mains Voltage

220 - 240 V, 50 - 60 Hz or 120 V, 50 - 60 Hz, 50 - 60 Hz

CAN Bus Interface

Optional (RCM-810 card)

Cooling

Front-to-Rear, continuously variable fans

Audio Network

No

Variable Load Drive (VLD)

Yes

Topology

Class-D

Continuous Rated Power (1 kHz, THD 1%) 4Ω

1000

Impedance

2/4/8/8 VLD/70 V/100V

Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω

900

Electronics Type

Amplifier

Continuous Rated Power (1 kHz, THD 1%) 2Ω

1000

Continuous Rated Power (1 kHz, THD 1%) 8Ω

500

Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω

450

Maximum Bridged Output 8Ω

2000

Maximum Bridged Output 4Ω

2000

Total Harmonic Distortion

0.05

Slew Rate

28

Intermodulation Distortion (SMPTE)

0.05

DIM 30

0.02

Signal-to-Noise Ratio (A-weighted)

103

Input Impedance (Balanced)

20

Input Sensitivity

0 dBu (.775V)-2ω, +3 dBu (1.1V)-4/8ω, +6 dBu (1.55) 70V/100V

Network Control (IRIS-Net)

Optional (RCM-810 card)

Amplifier Gain

32 dB (Lo-Z), 33 dB (70V), 36

Continuous Rated Power (1 kHz, THD 1%) 100v

1000

Continuous Rated Power (1 kHz, THD 1%) 70v

1000

Continuous Rated Power (20-20 kHz, THD<0,2%) 100v

900

Height

88.1

Width

482.6

Depth

421.5

Weight Net

11.1

Frequency Response (-3 dB)

15 Hz-30 kHz

Mains Voltage

220 - 240 V, 50 - 60 Hz or 120 V, 50 - 60 Hz, 50 - 60 Hz

CAN Bus Interface

Optional (RCM-810 card)

Cooling

Front-to-Rear, continuously variable fans

Audio Network

No

Variable Load Drive (VLD)

Yes

Topology

Class-D

Continuous Rated Power (1 kHz, THD 1%) 4Ω

500

Impedance

2/4/8/8 VLD/70 V/100V

Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω

450

Electronics Type

Amplifier

Continuous Rated Power (1 kHz, THD 1%) 2Ω

500

Continuous Rated Power (1 kHz, THD 1%) 8Ω

250

Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω

225

Maximum Bridged Output 8Ω

1000

Maximum Bridged Output 4Ω

1000

Total Harmonic Distortion

0.05

Slew Rate

28

Intermodulation Distortion (SMPTE)

0.05

DIM 30

0.02

Signal-to-Noise Ratio (A-weighted)

100

Input Impedance (Balanced)

20

Input Sensitivity

0 dBu (.775V)-2ω, +3 dBu (1.1V)-4/8ω, +6 dBu (1.55) 70V/100V

Network Control (IRIS-Net)

Optional (RCM-810 card)

Amplifier Gain

32 dB (Lo-Z), 33 dB (70V), 36

Continuous Rated Power (1 kHz, THD 1%) 100v

500

Continuous Rated Power (1 kHz, THD 1%) 70v

500

Continuous Rated Power (20-20 kHz, THD<0,2%) 100v

450

Continuous Rated Power (20-20 kHz, THD<0,2%) 70v

450

Analog Inputs

4, electronically balanced, Phoenix-type

Maximum Input Voltage

+22

Height

88.1

Width

482.6

Depth

421.5

Weight Net

13.9

Frequency Response (-3 dB)

15 Hz-30,000 Hz

Variable Load Drive (VLD)

Yes

Topology

Class-D

Impedance

2/4/8/8 VLD/71 V/100V

Continuous Rated Power (1 kHz, THD 1%) 4Ω

500

Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω

450

Electronics Type

Amplifier

Continuous Rated Power (1 kHz, THD 1%) 2Ω

500

Continuous Rated Power (1 kHz, THD 1%) 8Ω

250

Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω

225

Maximum Bridged Output 8Ω

1000

Maximum Bridged Output 4Ω

1000

Total Harmonic Distortion

0.05

Slew Rate

28

DIM 30

0.02

Signal-to-Noise Ratio (A-weighted)

100

Input Impedance (Balanced)

20

Input Sensitivity

0 dBu (.775V)-2ω, +3 dBu (1.1V)-4/8ω, +6 dBu (1.55) 70V/100V

Network Control (IRIS-Net)

Optional (RCM-810 card)

Amplifier Gain

32 dB (Lo-Z), 33 dB (70V), 36

Continuous Rated Power (1 kHz, THD 1%) 100v

500

Continuous Rated Power (1 kHz, THD 1%) 70v

500

Continuous Rated Power (20-20 kHz, THD<0,2%) 100v

500

Continuous Rated Power (20-20 kHz, THD<0,2%) 70v

450

Analog Inputs

8, electronically balanced, Phoenix-type

Maximum Input Voltage

+22 (9.76 Vrms)

Mains Voltage

220 - 240 V, 50 - 60 Hz or 120 V, 50 - 60 Hz, 50 - 60 Hz

CAN Bus Interface

Optional (RCM-810 card)

Cooling

Front-to-Rear, continuously variable fans

Audio Network

No

Max Calculated SPL

120

Rotatable coverage

100° x 100°

Frequency Range (-10 dB)

55Hz-25

Suspension

eight M10 Suspension Points, optional U Bracket or pan/tilt wall mount

Minimum Impedance

6

HF Transducer

DH-2005

Frequency Response (-3 dB)¹

75Hz-20k

LF Transducer

EVS-2008

Grille

18 GA cold-rolled steel with rotatable logo (18 GA stainless steel with hydrophobic cloth on PI models)

Weight Net

11.2

Shipping Weight

12.7

Environmental Specs

IEC 60529, IP44 (IP55 for PI versions)

Nominal Impedance

8

Axial Sensitivity (SPL, 1 W @ 1 m)

91

Power Handling (Continuous / Peak)

200/400/800

Connectors

Dual four-pin 10 AWG (6 mm) Phoenix/Euro Block screw-terminals

Enclosure

15mm weather-resistant plywood with EV Coat

Color

Black or White

Dimensions (H x W x D)

492 x 248 x 277

Passive crossover frequency

1.8

Rec. high-pass frequency, 4th Order

50 Hz for 8Ω (50 Hz with TK-150 transformer)

Max Calculated SPL

120

Rotatable coverage

90° x 60°

Frequency Range (-10 dB)

55Hz-25

Suspension

eight M10 Suspension Points, optional U Bracket or pan/tilt wall mount

Minimum Impedance

6

HF Transducer

DH-2005

Frequency Response (-3 dB)¹

75Hz-21k

LF Transducer

EVS-2008

Grille

18 GA cold-rolled steel with rotatable logo (18 GA stainless steel with hydrophobic cloth on PI models)

Weight Net

11.2

Shipping Weight

12.7

Axial Sensitivity (SPL, 1 W @ 1 m)

91

Power Handling (Continuous / Peak)

200/400/800

Connectors

Dual four-pin 10 AWG (6 mm) Phoenix/Euro Block screw-terminals

Enclosure

15mm weather-resistant plywood with EV Coat

Color

Black or White

Dimensions (H x W x D)

492 x 248 x 277

Passive crossover frequency

1.8

Rec. high-pass frequency, 4th Order

50 Hz for 8Ω (50 Hz with TK-150 transformer)

Environmental Specs

IEC 60529, IP44 (IP55 for PI versions)

Nominal Impedance

8

Max Calculated SPL

126

Rotatable coverage

60° x 45°

Frequency Range (-10 dB)

50Hz-25

Suspension

eight M10 Suspension Points, optional U Bracket or pan/tilt wall mount

Minimum Impedance

7

HF Transducer

DH-3

Frequency Response (-3 dB)¹

70Hz-20k

LF Transducer

EVS-12M

Grille

18 GA cold-rolled steel with rotatable logo (18 GA stainless steel with hydrophobic cloth on PI models)

Weight Net

20.3

Shipping Weight

22.7

Environmental Specs

IEC 60529, IP44 (IP55 for PI versions)

Nominal Impedance

8

Axial Sensitivity (SPL, 1 W @ 1 m)

95

Power Handling (Continuous / Peak)

300/600/1200

Connectors

Dual four-pin 10 AWG (6 mm) Phoenix/Euro Block screw-terminals

Enclosure

15mm weather-resistant plywood with EV Coat

Color

Black or White

Dimensions (H x W x D)

616 x 395 x 401

Passive crossover frequency

1.6

Rec. high-pass frequency, 4th Order

45 Hz for 8Ω (50 Hz with TK-150 transformer)

Max Calculated SPL

126

Rotatable coverage

90° x 55°

Frequency Range (-10 dB)

50Hz-25

Suspension

eight M10 Suspension Points, optional U Bracket or pan/tilt wall mount

Minimum Impedance

7

HF Transducer

DH-3

Frequency Response (-3 dB)¹

70Hz-22k

LF Transducer

EVS-12M

Grille

18 GA cold-rolled steel with rotatable logo (18 GA stainless steel with hydrophobic cloth on PI models)

Weight Net

20.3

Shipping Weight

22.7

Environmental Specs

IEC 60529, IP44 (IP55 for PI versions)

Nominal Impedance

8

Axial Sensitivity (SPL, 1 W @ 1 m)

95

Power Handling (Continuous / Peak)

300/600/1200

Connectors

Dual four-pin 10 AWG (6 mm) Phoenix/ Euro Block screw-terminals

Enclosure

15mm weather-resistant plywood with EV Coat

Color

Black or white

Dimensions (H x W x D)

616 x 395 x 401

Passive crossover frequency

1.6

Rec. high-pass frequency, 4th Order

45 Hz for 8Ω (50 Hz with TK-150 transformer)

Max Calculated SPL

126

Frequency Range (-10 dB)

50Hz-25

Suspension

eight M10 Suspension Points, optional U Bracket or pan/tilt wall mount

Minimum Impedance

7

Frequency Response (-3 dB)¹

70Hz-20k

Weight Net

21.8

Shipping Weight

24.4

Environmental Specs

IEC 60529, IP44 (IP55 for PI versions)

Nominal Impedance

8

Axial Sensitivity (SPL, 1 W @ 1 m)

95

Power Handling (Continuous / Peak)

300/600/1200

LF Transducer

EVS-12M

HF Transducer

DH-3

Connectors

Dual four-pin 10 AWG (6 mm) Phoenix/Euro Block screw-terminals

Enclosure

15mm weather-resistant plywood with EV Coat

Color

Black or white

Grille

18 GA cold-rolled steel with rotatable logo (18 GA stainless steel with hydrophobic cloth on PI models)

Dimensions (H x W x D)

528 x 411 x 648

Passive crossover frequency

1.6

Rec. high-pass frequency, 4th Order

45 Hz for 8Ω (50 Hz with TK-150 transformer)

Max Calculated SPL

129

Rotatable coverage

60° x 45°

Frequency Range (-10 dB)

50Hz-25

Suspension

eight M10 Suspension Points, optional U Bracket or pan/tilt wall mount

Minimum Impedance

6.7

HF Transducer

DH-3

Frequency Response (-3 dB)¹

70Hz-20k

LF Transducer

EVS-15M

Grille

18 GA cold-rolled steel with rotatable logo (18 GA stainless steel with hydrophobic cloth on PI models)

Weight Net

25

Shipping Weight

27.7

Environmental Specs

IEC 60529, IP44 (IP55 for PI versions)

Nominal Impedance

8

Axial Sensitivity (SPL, 1 W @ 1 m)

98

Power Handling (Continuous / Peak)

350/700/1400

Connectors

Dual four-pin 10 AWG (6 mm) Phoenix/Euro Block screw-terminals

Enclosure

15mm weather-resistant plywood with EV Coat

Color

Black or White

Dimensions (H x W x D)

684 x 433 x 451

Passive crossover frequency

1.6

Rec. high-pass frequency, 4th Order

40 Hz for 8Ω (50 Hz with TK-150 transformer)

Max Calculated SPL

129

Rotatable coverage

90° x 55°

Frequency Range (-10 dB)

50Hz-25

Suspension

eight M10 Suspension Points, optional U Bracket or pan/tilt wall mount

Minimum Impedance

6.7

HF Transducer

DH-3

Frequency Response (-3 dB)¹

70Hz-21k

LF Transducer

EVS-15M

Grille

18 GA cold-rolled steel with rotatable logo (18 GA stainless steel with hydrophobic cloth on PI models)

Weight Net

25

Shipping Weight

27.7

Nominal Impedance

8

Axial Sensitivity (SPL, 1 W @ 1 m)

98

Power Handling (Continuous / Peak)

350/700/1400

Connectors

Dual four-pin 10 AWG (6 mm) Phoenix/Euro Block screw-terminals

Enclosure

15mm weather-resistant plywood with EV Coat

Color

Black or White

Dimensions (H x W x D)

684 x 433 x 451

Passive crossover frequency

1.6

Rec. high-pass frequency, 4th Order

40 Hz for 8Ω (50 Hz with TK-150 transformer)

Environmental Specs

IEC 60529, IP44 (IP55 for PI versions)

Max Calculated SPL

129

Frequency Range (-10 dB)

30Hz-135

Suspension

four M10 inserts

Minimum Impedance

6.3

Frequency Response (-3 dB)¹

38Hz-95k

LF Transducer

EVS-18L

Grille

18 GA cold-rolled steel with rotatable logo (18 GA stainless steel with hydrophobic cloth on PI models)

Weight Net

32.6

Shipping Weight

36.5

Environmental Specs

IEC 60529, IP44 (IP55 for PI versions)

Nominal Impedance

8

Axial Sensitivity (SPL, 1 W @ 1 m)

97

Power Handling (Continuous / Peak)

400/800/1600

Connectors

Dual four-pin 10 AWG (6 mm) Phoenix/Euro Block screw-terminals

Enclosure

15mm weather-resistant plywood with EV Coat

Color

Black or White

Dimensions (H x W x D)

503 x 554 x 718

Rec. high-pass frequency, 4th Order

35 Hz for 8Ω (40 Hz with TK-150 transformer)

Frequency Range (-10 dB)

52 - 20000

HF Transducer

1 inch Titanium dome tweeter

Max. SPL/1m (calc)²

110

Coverage (Nominal -6 dB) H

150

LF Transducer

4 inch with 4 inch passive radiator

Coverage (Nominal -6 dB) V

150

Power Rating

200

System Power Handling (Continuous/Program/Peak)

50//200

LF Power Handling

4-inch, plus 4-inch passive

HF Power Handling

1-inch (Titanium dome)

Enclosure Material

Zinc Plated Metal

Available Color

White

Sensitivity 1 W/1 m

87

Height

350

Width

188.3

Depth

95.6

Weight Net

2.9

Input Connections

4-pin Phoenix

Transformer Taps (Transformer Version Only)

1.75, 3.75, 7.5, 15, 30 at 70 v

Nominal Impedance

8

Frequency Range (-10 dB)

52 - 20000

Nominal Impedance (Passive)

8

HF Transducer

1 inch Titanium dome tweeter

Max. SPL/1m (calc)²

115

Coverage (Nominal -6 dB) H

120

Coverage (Nominal -6 dB) V

120

LF Transducer

6 inch with 6 inch passive radiator

System Power Handling (Continuous/Program/Peak)

75//300

Power Rating

300

LF Power Handling

6 inch, plus 6-inch passive

HF Power Handling

1-inch (Titanium dome)

Enclosure Material

Zinc Plated Metal

Sensitivity 1 W/1 m

90

Available Color

White

Height

465

Width

256

Depth

100.3

Weight Net

5.8

Input Connections

4-pin Phoenix

Transformer Taps (Transformer Version Only)

7.5, 15, 30, 60 w at 70 v

Frequency Range (-10 dB)

80 - 7000

Weatherized

No

Nominal Impedance (Passive)

8

Speaker Type

Components

Max. SPL/1m (calc)²

125

System Power Handling (Continuous/Program/Peak)

300//1200

Power Rating

1200

Sensitivity 1 W/1 m

100

Available Color

Black

Depth

133.4

Weight Net

8.6

Cone Diameter

305

Coil Diameter

63.5

Efficiency

5.9

Frame front diameter

309.6

Magnet diameter

190.5

Mounting bolt circle diameter

293.7

Baffle cutout diameter

281

Impedance

8

Frequency Range (-10 dB)

80 – 5000

Weatherized

No

Max. SPL/1m (calc)²

100

Power Rating

200

System Power Handling (Continuous/Program/Peak)

200

Sensitivity 1 W/1 m

100

Available Color

Unfinished

Depth

133.4

Weight Net

8.6

Cone Diameter

305

Coil Diameter

63.5

Efficiency

5.9

Frame front diameter

309.6

Magnet diameter

190.5

Mounting bolt circle diameter

293.7

Baffle cutout diameter

281

Impedance

8

Frequency Range (-10 dB)

65 - 20000

Suspension

(6) M8 threaded points

Weatherized

No

Minimum Impedance

6

HF Transducer

One 1.3-inch (33 mm) diaphragm ICT-1-8 compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

110 - 16000

Max. SPL/1m (calc)²

120

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

50

LF Transducer

One 6.5-inch (165 mm) ICT-6.5-8 woofer

System Power Handling (Continuous/Program/Peak)

160//640

Power Rating

640

Connector Type

4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire)

Enclosure Material

9-ply hardwood plywood

Grille

18-gauge steel with cloth behind

Available Color

Black or white

Height

209

Width

370

Recommended High-Pass Frequency

90

Depth

207

Weight Net

6.53

Shipping Weight

9.12

Finish

Textured paint

Nominal Impedance

8

Waveguide

6 in. x 6 in., rotatable

Axial Sensitivity (SPL, 1 W @ 1 m)

92

Passive Power Handling

640

Frequency Range (-10 dB)

65 - 20000

Suspension

(6) M8 threaded points

Weatherized

No

Minimum Impedance

6

HF Transducer

One 1.3-inch (33 mm) diaphragm ICT-1-8 compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

110 - 16000

Max. SPL/1m (calc)²

123

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

50

LF Transducer

One 8-inch (203 mm) ICT-8-8 woofer

System Power Handling (Continuous/Program/Peak)

175//700

Power Rating

700

Connector Type

4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire)

Enclosure Material

9-ply hardwood plywood

Grille

18-gauge steel with cloth behind

Available Color

Black or white

Height

247

Recommended High-Pass Frequency

90

Width

409

Depth

237

Weight Net

7.4

Shipping Weight

10.3

Finish

Textured paint

Nominal Impedance

8

Waveguide

6 in. x 6 in., rotatable

Axial Sensitivity (SPL, 1 W @ 1 m)

95

Passive Power Handling

700

Frequency Range (-10 dB)

70 - 20000

Suspension

Six M8 threaded points

Weatherized

No

Minimum Impedance

6

HF Transducer

One 1.3-inch (33 mm) diaphragm ICT-1-8 compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

100 - 16000

Max. SPL/1m (calc)²

125

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

50

LF Transducer

Two 6.5-inch (165 mm) ICT-6.5-8 woofers

System Power Handling (Continuous/Program/Peak)

300//1200

Power Rating

1200

Connector Type

4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire)

Enclosure Material

9-ply hardwood plywood

Grille

18-gauge steel with cloth behind

Available Color

Black or white

Height

209

Recommended High-Pass Frequency

90

Width

533

Depth

207

Weight Net

11.3

Shipping Weight

14.2

Finish

Textured paint

Nominal Impedance

8

Waveguide

6 in. x 6 in., rotatable

Axial Sensitivity (SPL, 1 W @ 1 m)

94

Passive Power Handling

1400

Frequency Range (-10 dB)

60 - 20000

Suspension

Six M8 threaded points

Weatherized

No

Minimum Impedance

6

HF Transducer

One 1.3-inch (33 mm) diaphragm ICT-1-8 compression driver

Speaker Type

Full-Range, Two-Way

Frequency Response (-3 dB)¹

100 - 16000

Max. SPL/1m (calc)²

126

Coverage (Nominal -6 dB) H

90

Coverage (Nominal -6 dB) V

50

LF Transducer

Two 8-inch (203 mm) ICT-8-8 woofers

System Power Handling (Continuous/Program/Peak)

350//1400

Power Rating

1400

Connector Type

4-pin Phoenix/Euroblock screw terminals (up to 10 AWG wire)

Enclosure Material

9-ply hardwood plywood

Grille

18-gauge steel with cloth behind

Available Color

Black or white

Sensitivity 1 W/1 m

95

Height

247

Width

615

Recommended High-Pass Frequency

90

Depth

237

Weight Net

12.8

Shipping Weight

16

Nominal Impedance

8

Waveguide

6 in. x 6 in., rotatable

Axial Sensitivity (SPL, 1 W @ 1 m)

95

Passive Power Handling

1400

Finish

Textured paint

Weatherized

No

Speaker Type

Paging Horns

Power Rating

60

Available Color

Unfinished

Regulatory Approvals

UL1480; EN54-24; UL2043

Weatherized

Yes

Speaker Type

Paging Horns

Power Rating

10

Available Color

Unfinished

Weatherized

Yes

Speaker Type

Paging Horns

Power Rating

25

Available Color

Unfinished

Height

88

Width

483

Depth

406

Frequency Response (-3 dB)

65Hz-20kHz

Weight Net

16.5

DIM 30

< 0.1

Signal-to-Noise Ratio (A-weighted)

103

Input Impedance (Balanced)

> 20

Input Sensitivity

0 dBu

Number of Channels

1

Network Control (IRIS-Net)

No

Continuous Rated Power (1 kHz, THD 1%) 100v

270

Continuous Rated Power (1 kHz, THD 1%) 70v

270

Continuous Rated Power (20-20 kHz, THD<0,2%) 100v

250

Continuous Rated Power (20-20 kHz, THD<0,2%) 70v

250

Crosstalk

< -75

Channels

1

Continuous Rated Power (1 kHz, THD 1%) 2Ω

270

Total Harmonic Distortion

< 0.1

Slew Rate

41/61

Intermodulation Distortion (SMPTE)

< 0.1

Height

88

Width

483

Depth

406

Frequency Response (-3 dB)

65Hz - 40kHz

Weight Net

23.5

Amplifier Gain

34.3

Continuous Rated Power (1 kHz, THD 1%) 100v

270

Continuous Rated Power (1 kHz, THD 1%) 70v

270

Continuous Rated Power (20-20 kHz, THD<0,2%) 100v

250

Continuous Rated Power (20-20 kHz, THD<0,2%) 70v

250

Impedance

4/8

Crosstalk

< -75

Rated output power (*rated load) THD < 1%, 1kHz

270/135

Rated output power (*rated load) THD < 0.2%, 20Hz – 20kHz

250/125

Channels

2

Continuous Rated Power (1 kHz, THD 1%) 4Ω

270

Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω

250

Continuous Rated Power (1 kHz, THD 1%) 2Ω

270

Continuous Rated Power (1 kHz, THD 1%) 8Ω

135

Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω

125

Total Harmonic Distortion

< 0.1

Slew Rate

18

Intermodulation Distortion (SMPTE)

< 0.1

DIM 30

< 0.1

Signal-to-Noise Ratio (A-weighted)

103

Input Impedance (Balanced)

> 20

Input Sensitivity

0 dBu (775mV)

Number of Channels

2

Network Control (IRIS-Net)

No

Height

88

Width

483

Depth

406

Frequency Response (-3 dB)

65Hz - 40kHz

Weight Net

26

Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω

200

Total Harmonic Distortion

< 0.1

Slew Rate

25

Intermodulation Distortion (SMPTE)

< 0.1

DIM 30

< 0.1

Signal-to-Noise Ratio (A-weighted)

103

Input Impedance (Balanced)

> 20

Input Sensitivity

0 dBu (775mV)

Number of Channels

2

Network Control (IRIS-Net)

No

Amplifier Gain

34

Continuous Rated Power (1 kHz, THD 1%) 100v

430

Continuous Rated Power (1 kHz, THD 1%) 70v

430

Continuous Rated Power (20-20 kHz, THD<0,2%) 100v

400

Continuous Rated Power (20-20 kHz, THD<0,2%) 70v

400

Impedance

4/8

Crosstalk

< -75

Rated output power (*rated load) THD < 1%, 1kHz

430/215

Rated output power (*rated load) THD < 0.2%, 20Hz – 20kHz

400/200

Channels

2

Continuous Rated Power (1 kHz, THD 1%) 4Ω

430

Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω

400

Continuous Rated Power (1 kHz, THD 1%) 2Ω

430

Continuous Rated Power (1 kHz, THD 1%) 8Ω

215

Height

88

Width

483

Depth

406

Frequency Response (-3 dB)

< 10Hz - 40kHz

Weight Net

16.5

Slew Rate

28

Intermodulation Distortion (SMPTE)

< 0.1

DIM 30

< 0.1

Signal-to-Noise Ratio (A-weighted)

104

Input Impedance (Balanced)

> 20

Input Sensitivity

0 dBu

Number of Channels

2

Network Control (IRIS-Net)

No

Amplifier Gain

34.3

Impedance

4/8

Crosstalk

< -75

Rated output power (*rated load) THD < 1%, 1kHz

450/220

Rated output power (*rated load) THD < 0.2%, 20Hz – 20kHz

400/200

Channels

2

Continuous Rated Power (1 kHz, THD 1%) 4Ω

450

Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω

400

Continuous Rated Power (1 kHz, THD 1%) 2Ω

450

Continuous Rated Power (1 kHz, THD 1%) 8Ω

220

Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω

200

Total Harmonic Distortion

< 0.1

Height

88

Width

483

Depth

406

Weight Net

18

Frequency Response (-3 dB)

< 10Hz - 40kHz

Continuous Rated Power (1 kHz, THD 1%) 4Ω

160

Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω

150

Continuous Rated Power (1 kHz, THD 1%) 2Ω

160

Continuous Rated Power (1 kHz, THD 1%) 8Ω

100

Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω

75

Total Harmonic Distortion

< 0.1

Slew Rate

16

Intermodulation Distortion (SMPTE)

< 0.1

DIM 30

< 0.1

Signal-to-Noise Ratio (A-weighted)

101

Input Impedance (Balanced)

> 20

Input Sensitivity

0 dBu (775mV)

Number of Channels

4

Network Control (IRIS-Net)

No

Amplifier Gain

30

Impedance

4/8

Crosstalk

< -75

Rated output power (*rated load) THD < 1%, 1kHz

160/100

Rated output power (*rated load) THD < 0.2%, 20Hz – 20kHz

150/75

Channels

4

Network Control (IRIS-Net)

Yes

Internal Processing

None

Network Interface

CAN Bus

CAN Bus Interface

10 - 500 kbaud, 2x RJ-45 (IRIS-Net Control)

GPIO Control Ports

2 x 3-pole Euro block 2 Control Inputs 2 Control Outputs 2 Reference Outputs (+5 V, 200 mA / GND)

Audio Network

No

Variable Load Drive (VLD)

Yes

FIR-Drive

No

Frequency Range (-10 dB)

70 - 16000

Weatherized

Yes

Flying

Yes

Minimum Impedance

3.5

Nominal Impedance (Passive)

4

HF Transducer

2-inch DH2T

Speaker Type

Full-Range, Two-Way

Woofer Size

12

MF Transducer

ND12A

Max. SPL/1m (calc)²

139

Coverage (Nominal -6 dB) H

65

Coverage (Nominal -6 dB) V

65

LF Transducer

One 12-inch DL12BFH (LF), one 12-inch ND12 (MB)

Power Rating

2400

System Power Handling (Continuous/Program/Peak)

600//2400

Crossover Frequency

1800

Enclosure Material

High Density Polymer (Composite)

Sensitivity 1 W/1 m

105

Available Color

Black

Height

1163

Width

429

Recommended High-Pass Frequency

90 @Q=1.6

Depth

312

Internal Crossover

Yes

Weight Net

36.3

Family

Sx

Axial Sensitivity (SPL, 1 W @ 1 m)

105

Passive Power Handling

2400

Chassis Size

304.8

Input Connections

SJO cable/gland nut

Directivity Index

11.3

Weatherized

Yes

Nominal Impedance (Passive)

8

System Power Handling (Continuous/Program/Peak)

30

Power Rating

30

Available Color

White

Height

183

Width

66

Weight Net

1.8

Input Connections

Waterproof cable
